Starlink Performance (Gen 3) Kit – Setup Guide

StarlinkPerformance

Helpful Tools

The Starlink Performance (Gen 3) Kit has a white film on the front face that should not be removed.

Setup Guide PDF
Starlink Performance Durability Guide
Starlink Performance Specs Guide (PDF) / Starlink Performance Specs (webpage)
Accessory Guide PDF
Where is the Starlink Performance Kit available?
How can I upgrade to the Starlink Performance Kit?
Does Starlink Performance come with a separate router?
What happened to the Actuated High Performance and Flat High Performance names?
Wall Mount: Install Guide PDF
Flat Mount: Install Guide PDF
Wedge Mount: Install Guide PDF
Pipe Adapter: Install Guide PDF
Performance Gen 3 Router Kit: Install Guide PDF

What’s included with my Starlink Performance Kit?

Starlink Performance
Advanced Power Supply
25m Starlink Performance Cable
5m Ethernet Cable
1.5m AC Power Cable
1.5m DC Power Cable

1. Download the Starlink App

Download the Starlink App and scan the QR code to step through the install process

StandardDownloadApp

2. Plug in Cables and Connect to Power

Align the Performance Connector end of the Starlink cable indicated by the red notch and plug into your Starlink by holding the end of the plug and firmly inserting into the dish. When the cable is properly inserted, it will audibly click into place.

Connect the other end of the Starlink cable to the power supply. Install either the AC (2A) or DC (2B) Power Cable into the power supply, depending on your power source, and plug into a power outlet. Ensure all cables are fully plugged in until the plug face is flush with the surface.

If needed, to remove the Starlink cable, rotate the collar counterclockwise and pull out to disconnect from your Starlink

3. Find Mounting Location and Align Starlink

Your Starlink needs a clear view of the sky so it can stay connected with satellites as they move overhead. Objects that obstruct the connection between your Starlink and the satellite, such as a tree branch, pole, or roof, will cause service interruptions. Use the obstruction tool in the App to ensure you have selected a suitable mounting location.

An alert on the App will show if you need to rotate Starlink to be properly aligned. Tap the alert to use the alignment tool.

Ensure to check for obstructions and your Starlink is properly aligned before permanently installing your Starlink.

4. Connect Starlink

If using a Starlink Router, connect the Router to the Advanced Power Supply using the cable provided in the router kit. Step through the Starlink install process on the Starlink App. You can utilize the Starlink App to view statistics, access terminal settings and contact support.

If using a third-party router, use the provided ethernet cable in the Performance Kit. After you have set up your 3rd party router and connected to Starlink with the WAN port, open the Starlink app. If the app says “Starlink unreachable”, create a static route in your router configuration settings.

Please refer to your router’s documentation for instructions on setting a static route.

Network destination: 192.168.100.0
Subnet Mask: 255.255.255.0
Gateway: 192.168.100.1
Interface: WAN

Note: These options may differ depending on your specific hardware and network configuration.

ADVANCED POWER SUPPLY UNIT

1. Remove Mount

Remove the power supply from the mount by pulling and twisting the quick release pins in either direction. The pins will lock in place to allow for easy removal of the power supply

2. Mark Pilot Holes

Select a mount location no more than 1.5 m (5ft) away from your power source.

Mark the location of the four holes on your power supply mount using a pen or pencil.

3. Drill the Pilot Holes

Drill the holes with a 8 mm (5/16 in) drill bit.

4. Install Anchors and Mount

Push anchors into holes until flush with the wall. Place the wall mount over the anchors and screw the mount into the wall until securely attached.

5. Plug In Cables and Install Power Supply

Plug in the Starlink, ethernet and AC or DC cables into the power supply by removing the waterproof plugs and ensure the cables are fully inserted. Slide the power supply into the mount, making sure both locking pins snaps into place.

Finish installation by routing the Ethernet cable to your router install location, connect to router and plug in router and power supply into your power source.

Order Now

Get Starlink email updates here.

Can’t find what you’re looking for? Contact Support.

Download Name
Starlink STLXX01126 Performance (Gen 3) Kit Datasheet
Starlink STLXX01126 Performance (Gen 3) Kit Installation Guide
Starlink Availability Map
LEO Orbit Constellations

Versions Comparison

	Starlink Performance (Gen 3) Kit	Starlink Performance (Gen 2) Kit	Starlink Enterprise Kit	Starlink Standard Kit
Peak Throughput	475 Mbps Download / 75 Mbps Upload	450 Mbps Download / 60 Mbps Upload		475 Mbps Download / 70 Mbps Upload
Field of View	140°	140°	110°	110°
Starlink Environmental Rating	IP69K (with cables installed) / IP68 (no cables installed)	IP56 (with cables installed) / Not Rated (no cables installed)	IP67 Type 4	IP67 Type 4 (with cables installed) / Not Rated (no cables installed)
Power Supply Environmental Rating	IP68 (with cables installed or plugged)	IP66	IP66	IP66 Type 4
Starlink Operating Temperature	-40°C to 60°C (-40°F to 140°F)	-30°C to 50°C (-22°F to 122°F)	-30°C to 50°C (-22°F to 122°F)	-30°C to 50°C (-22°F to 122°F)
Snow Melt Capability	Up to 85mm / hour (3.5 in / hour)	Up to 75mm / hour (3in / hour)	Up to 40 mm / hour (1.5 in / hour)	Up to 40 mm / hour (1.5 in / hour)
Wind Speed Rating	Survivable: 280 kph+ (174 mph+)	Survivable: 280 kph+ (174 mph+)	Operational: 96 kph+ (60 mph+)	Survivable: 177 kph+ (110 mph+)
Power Specifications	100-240VAC, 12V-56VDC	100-240V AC	100-240V AC	100-240V AC
Average Power Draw	70 W	110 W	75 – 100 W	62 W
Router Compatibility	Third-party compatible	Third-party compatible	Third-party compatible	Requires Advanced Power Supply to support third-party routers
Available Cable Lengths	5m, 25m, 50m, 50m LSZH ( included in kit)	2m, 8m, 25m* (* included in kit)		15m, 50m ( included in kit)
Cable Connectors	Starlink Performance to Starlink RJ45 / Able to field terminate	High Performance Starlink Connector to Starlink Gen2 Router Connector		Starlink RJ45 to Starlink RJ
Warranty Length	3 Years	2 Years	1 Year	1 Year
