UAP-AC-PRO-E
– Ubiquiti bestseller less the PoE adapter
One of the most popular Ubiquiti – UAP-AC-PRO models is now available in a
new form. What is the difference between UAP-AC-PRO and UAP-AC-PRO-E? It’s
very small: the latter is not equipped with a PoE adapter, which translates
into a lower price. You can nonetheless count on uncompromising quality and
reliable performance.

UAP-AC-PRO-E offers high performance wireless networks and the ability to
work indoors as well as outdoors. The solution is based on 802.11ac
technology.

Proven quality

UAP-AC-PRO has very quickly become a bestseller. The model suports speeds
up to 450 Mbps for 2.4 GHz and 1000 Mbps for 5 GHz. It is compatible with the
POE-48-24W-G power supply or PoE switches.

Key features
works inside and outside of buildings
high efficiency
intuitive use
3×3 11AC MIMO technology
scalability

Use

UAP-AC-PRO-E proves itself in any environment where wireless network
performance is the top priority. It facilitates high quality of connections
for multiple users using the network at the same time.

Comparison

UAP-AC-LITE UAP-AC-LR UAP-AC-EDU UAP-AC-PRO UAP-AC-Outdoor
Environment Indoor Indoor Indoor Indoor/Outdoor Outdoor
Simultaneous Dual-Band

2.4 GHz Speed* 300 Mbps 450 Mbps 450 Mbps 450 Mbps 450 Mbps
2.4 GHz MIMO 2×2 3×3 3×3 3×3 3×3
5 GHz Speed* 867 Mbps 867 Mbps 1300 Mbps 1300 Mbps 1300 Mbps
5 GHz MIMO 2×2 2×2 3×3 3×3 3×3
Range* 122 m (400 ft) 183 m (600 ft) 122 m (400 ft) 122 m (400 ft) 183 m
(600 ft)
Secondary Ethernet Port

Loudspeaker

PoE Mode 24V Passive PoE 24V Passive PoE 802.3at PoE+

802.3af PoE

802.3at PoE+

48V Passive POE or UniFi Switch
Ceiling Mount

Wall Mount

Pole Mount

Wireless Uplink

* Speed and Range values may vary and are based on optimal
environments.

See video

PoE Switch Compatibility for UAPs and UVCs
AP/Camera
Model US-8 US-8-60W US-8-150W US-16-150W US-24-250W US-24-500W US-48-500W US-48-750W
UVC-G3

âœ“ âœ“ âœ“ âœ“ âœ“ âœ“
UVC-G3-DOME âœ“ âœ“ âœ“ âœ“ âœ“ âœ“ âœ“ âœ“
UAP

âœ“ âœ“ âœ“ âœ“ âœ“ âœ“
UAP-LR

âœ“ âœ“ âœ“ âœ“ âœ“ âœ“
UAP-PRO âœ“ âœ“ âœ“ âœ“ âœ“ âœ“ âœ“ âœ“
UAP-AC-LITE¹ âœ“ âœ“ âœ“ âœ“ âœ“ âœ“ âœ“ âœ“
UAP-AC-LR¹ âœ“ âœ“ âœ“ âœ“ âœ“ âœ“ âœ“ âœ“
UAP-AC-PRO âœ“ âœ“ âœ“ âœ“ âœ“ âœ“ âœ“ âœ“
UAP-AC-M âœ“ âœ“ âœ“ âœ“ âœ“ âœ“ âœ“ âœ“
UAP-AC-M-PRO âœ“ âœ“ âœ“ âœ“ âœ“ âœ“ âœ“ âœ“
UAP-AC-IW² âœ“ âœ“ âœ“ âœ“ âœ“ âœ“ âœ“ âœ“
UAP-AC-IW-PRO² âœ“ âœ“ âœ“ âœ“ âœ“ âœ“ âœ“ âœ“
UAP-AC-HD

âœ“ âœ“ âœ“ âœ“ âœ“ âœ“

âœ“ Compatible with the UniFi switch.

Requires Instant 802.3af Gigabit PoE Converter:
INS-3AF-I-G
or INS-3AF-O-G
.

Requires 802.3at power; switch provides 802.3af only.

Note:

¹ UAP-AC-LITE and UAP-AC-LR models manufactured before September 2016
require the Instant 802.3af Gigabit PoE Converter.

² For the UAP-AC-IW and UAP-AC-IW-PRO PoE passthrough is supported by all
of the switches listed above except for models US-8 and US-8-60W.

Manufacturer’s content

Read more in the manufacturer’s documentation

Read the manual

Specifications

Ubiquiti Networks UAP-AC-PRO-E wireless access point 1300 Mbit/s White Power over Ethernet (PoE)
