Description

Hikvision DS-2CS54C8T-PH 1 MP WDR Covert Camera

MAKE Hikvision
MANUFACTURER Hikvision USA Inc.
MODEL CODE DS-2CS54C8T-PH
COLOR TYPE Color / Monochrome
RESOLUTION TVL 1MP
DIGITAL (DSP) Yes
AUTO IRIS Yes
SENSITIVITY LUX 0.005
ELECTRICAL SPECIFICATIONS Voltage: 12 V DC Power Consumption: 1.5 W
FOCAL LENGTH MM 2.8
WIDE DYNAMIC RANGE Yes
PICTURE ELEMENTS HXV 1280 x 720
BACK LIGHT COMPENSATION Yes
AUTO GAIN CONTROL Yes
WHITE BALANCE Yes
ELECTRONIC SHUTTER RANGE 1/25 ~ 1/50, 000 s
SYNCHRONISATION Internal
SIGNAL MODE PAL, NTSC
VIDEO OUTPUT 1 HD analog output/1 CVBS output (75?/BNC)
PHYSICAL SPECIFICATIONS Dimension mm: 32 x 32 x 22 Weight g: 200
ENVIRONMENTAL SPECIFICATIONS Operating Temperature oC: -40 ~ +60 C (-40 ~ +140 F) Operating Humidity %: 0 ~ 90
ADDITIONAL INFO
1 MP high performance CMOS
Ultra-low light
1280 × 720 resolution
2.8 mm fixed focal lens
120 dB true WDR, 3D DNR
Switchable TVI/CVBS
Up the coax (HIKVISION-C)
