Alcad TM-112 2xdvb-s/s2/t/t2 to dvb-t/c transmod ci
KSh259,478.00
Alcad TM-112 – Serie 912: 2xdvb-s/s2/t/t2 to dvb-t/c transmod ci.
himalaya transmodulator of DVB-S/S2 satellite digital television services or DVB-T/T2 terrestrial digital television to DVB-T or DVB-C. Each module selects services from two DVB-S/S2 satellite transponders or DVB-T/T2 terrestrial channels and includes them in a DVB-T or DVB-C channel. Can be configured using a web browser in a computer conected via ethernet cable.
Equipped with a Common Interface slot for insertion of the CAM and the subscriber’s card for encripted services. Can be configured using a web browser in a computer conected via ethernet cable.
Downloads
Technical specification
Technical specification
Manuals
TM-112 Manual pdf 2.85 MB
Catalogues
CATALOGUE_ALCAD_EN_MULTIMEDIA_TV pdf 5.42 MB
Certificates
CE Declaration – 912-TM pdf 61.42 KB
Firmware
Firmware TM-112 v3.06 zip 26.51 MB
Other documents
TECHNICAL INFORMATION pdf 325.27 KB
Technical specifications
