Black outdoor chest – small model Televes
KSh1,614.00
External black box where you can enter the shunts, distributors and other elements that, by the design of your installation are outside your home, so you need protection from the weather. Televes 4177
External casing for shunts and distributors. Televes 4177
Black box for outdoor, where you can introduce the shunts, distributors and other elements that, by the design of your installation are outside of your home, so you need protection against the weather inclemency. Ideal for distributors or distributors with flange: TEL5435, TEL5436, TEL5437, TEL5438. and flanged shunts: TEL5425, TEL5426, TEL5427, TEL5428, TEL5448
Features
Outside chest
Color Black
Small model
Weatherproof cases made of ABS plastic.
They can be installed on both the mast (using a nylon flange provided) or onto the wall.
Specifications
Reference? ?4177
Inner Dimensions (Wid x Hei x Dep) ?mm ?92 x 66 x 27
Outter Dimensions (Wid x Hei x Dep) 113 x 88 x 35
