Cahors BIG BISAT Multisatellite antenna fiber 91cm 36 dB 4…
KSh45,980.00
The BIG BISAT antenna is the latest addition to the SMC range. It has been specially developed to allow the simultaneous reception of several satellites (up to 6 satellites). Thanks to a new generation of rear mounting, each satellite receives the same quality of reception. The simplicity of installation makes it easy to install the BIG BISAT.
Fiberglass-reinforced polyester disc that allows it to withstand the most adverse atmospheric conditions, offering high performance in all cases, galvanized steel frame, individual packaging.
4 LNB brackets are included for quick and easy installation. (Without LNB)
Optimal dimensional stability.
Very high efficiency and high gain.
Perfect for receiving digital signals.
Optimal dimensional stability, high gain and very high efficiency.
High durability. They are insensitive to ultraviolet radiation, atmospheric pollution and saline environments.
They withstand the most adverse atmospheric conditions, offering high performance in all cases.
The quality reference
CAHORS is committed to providing a 10-year anti-corrosion manufacturer’s warranty on the reflectors in its range of SMC antennas. Its quality system has been certified by ISO 9001 by AFAQ since 1993.
Specifications
LNB brackets
Support for 4 LNB included
Vertical axis / Horizontal axis
91 cm / 70 cm
Frequency range 10.7 – 12.75 GHz
Multi-satellite capability
+/- 20? orbital (total 40?)
Gain (dB) +/- 20 ? 36 dB
Beamwidth at 3 dB 2.3 ?
G / T (12.5 GHz) 16 dBK
Elevation 0 ? to 90 ?
Tube mount ? 40 ? 60 mm
Weight 11 kg
Packaging dimensions 840x925x160 mm
Related products
-
Televes ISD Offset dish 83cm Aluminum 39dBi Orange
KSh19,116.00Add to cartThis new range of satellite dishes is built using aluminium and stainless steel to guarantee the protection against rust.
-
Televes ISD Offset dish 83cm Aluminum 39dBi White
KSh19,116.00Add to cartThis new range of satellite dishes is built using aluminium and stainless steel to guarantee the protection against rust.
-
Antenna aluminum focus center 1800 White Televes
KSh354,046.00Add to cartParabolic center focus 1800 aluminum kit. Gain 42.5dB.Iincludes LNB support, orthomode feeder, and a support for the floor. White color. Televes 7489
-
Add to cartThis product is not sent to some countries or areas, if the cart does not have available carriers, you can contact us here
TRIAX TD Dishes?The difference is clear
Manufactured and tested to the highest standards of precision and quality, TRIAX?s easy-to-install dishes offer outstanding performance, durability and reliability.
TDS: Steel???? TDA: Aluminium
Features
Unrivaled build quality, whether Steel or Aluminium
– Hot-dip galvanized steel OR long lasting Aluminium – for extra corrosion protection?
– TRIAX?s unique cable protection system?
– Every part, every accessory is weatherproofed
– 2 years corrosion warranty
– 5 years functionality warranty
Outstanding performance
– High gain for an exceptional signal
Quick and easy installation
– One-click mounting system
– Self-locking screw & nuts
Logistic friendly
-?Single or Bulk packaging, according to customer needsTRIAX is your reliable partner, with?comprehensive service and support.?
Specifications
ORDER INFORMATION
EAN Number 5702661205156
CHARACTERISTICS
Elevation range 0…90 ?
Offset angle 25.6 ?
F/D ratio 0,62
FREQUENCY
Frequency range 10.7…12.75 GHz
GAIN
Gain @ 11.7 GHz 36.5 dBi
Gain @ 10.70 GHz 38.5 dBi
Gain @ 12.75 GHz 37 dBi
MECHANICAL
Main material Aluminium
Colour RAL 7035 – Light grey
Arm Colour Raw
Total Weight 4,640 kg
LNB holder 40
Net Weight 3,250 kg
Packing QTY 1
Reflector type Offset
Width (cm) 71 cm
Height (cm) 79 cm
Packaging Depth 0,100 m
Packaging Height 0,870 m
Packaging Width 0,832 m
Tara Weight 1,390 kg
Packaging Volume 0,072 m3 -
Add to cartThis product is not sent to some countries or areas, if the cart does not have available carriers, you can contact us here
TRIAX TD Dishes?The difference is clear
Manufactured and tested to the highest standards of precision and quality, TRIAX?s easy-to-install dishes offer outstanding performance, durability and reliability.
TDS: Steel???? TDA: Aluminium
Features
Unrivaled build quality, whether Steel or Aluminium
– Hot-dip galvanized steel OR long lasting Aluminium – for extra corrosion protection?
– TRIAX?s unique cable protection system?
– Every part, every accessory is weatherproofed
– 2 years corrosion warranty
– 5 years functionality warranty
Outstanding performance
– High gain for an exceptional signal
Quick and easy installation
– One-click mounting system
– Self-locking screw & nuts
Logistic friendly
-?Single or Bulk packaging, according to customer needsTRIAX is your reliable partner, with?comprehensive service and support.?
Specifications
ORDER INFORMATION
EAN Number 5702661205040
CHARACTERISTICS
Elevation range 0…90 ?
Offset angle 26 ?
F/D ratio 0,62
FREQUENCY
Frequency range 10.7…12.75 GHz
GAIN
Gain @ 11.7 GHz 35 dBi
Gain @ 10.70 GHz 37 dBi
Gain @ 12.75 GHz 34 dBi
MECHANICAL
Main material Aluminium
Colour RAL 7016 – Anthracite grey
Arm Colour Raw
Total Weight 3,750 kg
LNB holder 40
Net Weight 2,700 kg
Packing QTY 1
Reflector type Offset
Width (cm) 60 cm
Height (cm) 66 cm
Packaging Depth 0,100 m
Packaging Height 0,734 m
Packaging Width 0,684 m
Tara Weight 1,050 kg
Packaging Volume 0,050 m3
