Housing Amplifier Auto-LTE 1e/(2s+TV) F 47…694/782MHz USOS…
KSh21,214.00
“F” domestic amplifier
3 outputs (2+TV): VHF/UHF – Auto LTE
Domestic amplifier with 3 outputs (2+TV) and automatic level adjustment to extend the terrestrial television domestic network.
The TV output provides a lower gain in order to be directly connected to the television set (no outlet installation).?
Equipped with selectable LTE and input power supply for pre-amplifier or BOSS system feeding.
?
Highlights
Equipped with USOS (User Selectable Output Signal) technology: the installer selects the desired output level, which remains stable. The device automatically adjustsgain according to the input signal variation.
Low-impact visual design and limited size
Fully automated manufacturing, subject to the most stringent quality controls
Features
Can be wall-mounted using screws
?F? connectors
Specifications
Outputs 3 (2 + 1TV)
Frequency margin MHz 47…68/174…400 470…694/790 (AUTO)
Gain dB 10 (0 @TV) 20 (11 @TV)
Gain regulation margin dB 0 … 30
AUTO
Output level EN50083 (1) dB?V 101 109
DIN45004B 92 101
10Ch DVB-T – 92
2Ch DVB-T 96 –
Output level regulation margin dB 0 … 12
MANUAL
Figure of noise ? 4,5 6
Voltage / Network frequency V~/Hz 193-253 / 50-60
Total AC consumption W/mA <2,8 / 28
DC current pass Vdc/mA 12 / 100
Operating temperature range ?C -5 ... +45
Protection index IP 20
(1) IMD3 2CH -35dB
