Ikusi APB-112-M Micro 12 V 200 mA power supply unit, 1 output
KSh4,210.00
IKUSI APB-112-M. Power supplies ?micro? APB series. Switch mode power supplies for mast amplifiers. Smaller size with terrestrial and satellite inputs.
Features
The smallest on the market.
It allows installation in any junction box.
Optimum power consumption. Low power switch mode.
Mounting without tools.
1RF input connector + DC output port / 1 or 2 RF outputs ports.
Technical specifications
REF. 3436
Regulation type switch mode
Output 1
Mains voltage (50 Hz) VAC 100 – 240
Output voltage VDC +12 (?5%)
Output voltage mA 200
Frequency range MHz 47 – 2400
RF insertion loss dB ? 1.5
Current pass through mA 300
Efficiency % >70
Dimensions mm 50 x 50 x 25
?
MANUAL/DATASHEET
