Inverto Inverto LNB Pro Wideband 40mm whit…
Especificamente projetado para atender a crescente demanda de operadores de DTH para instala??es MDU e Multi-Tuner Home Gateway de baixo custo, este LNB profissional ? baseado em um ?nico oscilador local de 10.4GHz que oferece desempenho RF excepcional em toda a faixa de freq??ncia (banda L) ao longo de dois portas de sa?da (vertical e horizontal).
Features
Low-phase noise, compatible with DVB-S2 (HDTV)
Low Noise Figure
Low power consumption
High cross polarization insulation
High-frequency stability
Enhanced 4G interference immunity
Specifications
Technical specifications
Input frequency range 10.7 GHz ~ 12.75 GHz
Frequency range IF 300 ~ 2350 MHz
noise figure from 0.7 dB tip. (1 dB maximum)
LO frequency accuracy at 25 ? C from 10.4 GHz ? 1 MHz
temperature drift LO at 25 ? C from 10.4 GHz ? 2 MHz
LO phase noise at 10 kHz from -80 dBc / Hz max.
conversion gain from 50 dB ~ 60 dB min.
Gain variation (full band) ? 0.5dB @ 27MHz
image rejection from 40 dB min. (8.05 GHz to 10.1 GHz)
1 dB compression point (@ output) 0.0 dBm min.
Cross polarization isolation 22 dB min.
Polarization Selection – LHCP 16.0 V ~ 20.0 V
Polarization Selection – RHCP 10.0 V ~ 14.0 V
Output VSWR from 2.5: 1 & nbsp;
At the spurious band level -60 dBc max.
current consumption from 150 mA max. @ 11 V ~ 20 V
Operating temperature from -30 ? C & nbsp; & nbsp; ~ & nbsp; & nbsp; +60 ? C
Output Impedance from 75 ?
Output Connector Type from F-Type (female)
Weight 110 g
Related products
-
-
Read moreSpecifically designed to address the demand of the global DTH market for a competitive and 4G/LTE protected solution, this LNB provides optimized reception capabilities using the latest chipset technology and waveguide design for satellite signal reception. It enables the reception of satellite TV from a single satellite and its distribution to 8 set top boxes (or four twin tuner PVR) without the need of external multiswitch. The LNB supports HD and UHD transmissions, delivers excellent RF performances, very low power consumption and importantly engineered to mitigate interferences from 4G/LTE transmissions. Manufactured to the highest industry quality standards and engineered to meet strict specifications, this LNB is an ideal solution for DTH operators and satellite broadcast reception across the world.
Features
Low Phase Noise, DVB-S2 (HD and UHD) compliant
Low Noise Figure
Low power consumption
High Cross Polarization Isolation
High Frequency stabilitySpecifications
Input frequency range 10.7 GHz ~ 12.75 GHz
Output frequency range 950 MHz ~ 1950 MHz
Low band LO frequency 9.75 GHz
High band LO frequency 10.6 GHz
Noise figure 0.7 dB typ. (1 dB max.)
LO frequency accuracy @ 25? C ?400 kHz max.
LO temperature drift ?800 MHz max.
LO phase noise @ 10 kHz -90 dBc/Hz max.
Conversion gain 55 dB min.
Gain ripple (over 26 MHz bandwidth) ?0.6 dB
Gain variation (over full band) ?4 dB
Image rejection 40 dB min.
3th order intermodulation – ICP3 10 dBm min.
1 dB compression point (@ output) 0 dBm min.
Cross polarization isolation 22 dB typ.,
Control signal Ca (V) 10.0 V ~ 14.0 V
Control signal Cb (H) 16.0 V ~ 20.0 V
Control signal Cc (band switching) 22 kHz ?4 kHz
Output VSWR 2.3 : 1
In band spurious level -60 dBm max.
Current consumption 210 mA max. @ 11 VDC ~ 20 VDC
Operating temperature -30 ?C ~ +60 ?C
Output impedance (LNB2) 75 ?
Output connector type F-type (female)
Dish F/D ratio 0.6
Weight 299 g -
Inverto Inverto LNB Pro Wideband 40mm whit…
KSh5,980.00Add to cartSpecifically designed to meet DTH operators’ growing demand for lower cost MDU and Multi-tuner Home Gateway installations. This professional LNB is based on a single 10.40 GHz local oscillator that delivers exceptional RF performance across the entire frequency range (L-band) on two output ports (vertical and horizontal) combined with increased immunity against terrestrial/4G interference. .
Manufactured to the highest industry quality standards and designed to meet strict specifications, this LNB is an ideal solution for cost-effective reception of a satellite and its distribution to home gateways with multiple tuners or multiple switches with LNB inputs. compatible broadband.
Features
Local oscillator: 10.40 GHz
Low phase noise, compatible with DVB-S2 (HDTV)
Low noise design
Low energy consumption
High cross polarization isolation
High frequency stability (PLL)
Greater immunity against 4G interference
Specifications
Technical specifications
Input frequency range 10.7GHz ~ 12.75GHz
IF frequency range 300~2350MHz
noise figure 0.7 dB typ. (1 dB maximum)
Low Frequency 10.40GHz
LO frequency accuracy at 25? ?0.5MHz
LO temperature drift ?1MHz
LO phase noise at 10 kHz – 80 dBc / Hz max.
conversion gain 50dB ~ 60dB min.
Gain Variation (Bandwide) ?0.5dB @ 27MHz
Image rejection 40 dB min. (8.05 GHz to 10.1 GHz)
1 dB compression point (@ output) 0.0 dBm min.
Cross polarization isolation 25 dB min.
VSWR output 2.5:1
At the spurious band level -60 dBm max
Current consumption 100mA max @11V~20V
Operating temperature -30?C ~ +60?C
Output impedance 75?
Output connector type F-Type (female)
Weight 98g -
Add to cartThe LNB is supplied with a 40 mm plastic ring adaptor to allow mounting onto a standard 40mm LNB holder.
Specifically designed for the European DTH markets, this Monoblock LNB allows for dual satellite reception from orbital positions 13?E and 19.2?E over a single 80cm offset satellite dish antenna with F/D = 0.6 and their distribution to up to four independent receivers.
The LNB receives satellite broadcasts with horizontal and vertical polarizations within the 10.7 ~ 12.75 GHz frequency range. It provides four universal output ports with 950 ~ 2150 MHz IF frequency range. Each output port (F-type) carries also power supply and control signals. DiSEqC 1.0 commands allow selecting the orbital satellite position. As long as no DiSEqC command has been received, the default feed is of the “Sat A” position (i.e. 13?E). Polarization (vertical/horizontal) and band (low/high) are selected using 13/18VDC and 0/22kHz control signals.
The LNB is optimized for Ultra High Definition (4K/8K) transmissions and provides excellent Cross polarization isolation, Phase Noise and Noise Figure performances. Designed to meet strict specifications and manufactured to the highest industry quality standards, this LNB is an ideal solution for satellite broadcast reception of Hotbird 13?E and Astra 19.2?E across Europe.
Features
Low Phase Noise, DVB-S2 (HDTV) compliant
Low Noise Figure
Low Power consumption
Very high Cross Polarization Isolation
Very high Frequency stabilitySpecifications
Technical specifications
Low band input frequency range 10.7 GHz ~ 11.7 GHz
Low band output frequency range 950 MHz ~ 1950 MHz
Low band LO frequency 9.75 GHz
High band input frequency range 11.7 GHz ~ 12.75 GHz
High band output frequency range 1100 MHz ~ 2150 MHz
High band LO frequency 10.6 GHz
Noise figure 0.6 dB typ., 1.0 dB max.
LO frequency accuracy @ 25? C ?0.5 MHz max.
LO temperature drift ?1 MHz max.
LO initial accuracy ?0.5 MHz max.
LO phase noise @ 1 kHz -75 dBc/Hz
LO phase noise @ 10 kHz -80 dBc/Hz
LO phase noise @ 100 kHz -90 dBc/Hz
Conversion gain 55 dB ~ 65 dB
Gain ripple (over 26 MHz bandwidth) ?0.75 dB max.
Gain variation (over full band) 6 dBpp max.
Image rejection 50 dB min.
1 dB compression point (@ output) 0 dBm min.
Cross talk 22 dB min.
Control, Satellite A/B/C/D Selection DiSEqC 1.0: Sat A* = Hotbird 13?E, Sat B = Astra 19.2?E* Default Satellite Reception
Polarity info Horizonatal polarization: 18 VDC
Vertical polarization: 13 VDC
Low band: 0 kHz
High band: 22 ?4kHz
Output VSWR 2.0 : 1 max.
In band spurious level -65 dBm max.
Current consumption 180 mA max. per port (10 VDC ~ 20 VDC)
Operating temperature -30 ?C ~ +60 ?C
Output impedance 75 ?
Output connector type F-Type (female)
Recommended Dish Size 80 cm (F/D = 0.6)
Weight 311.6 g -
Add to cartRange of universal LNBs low noise figure and high gain that allow capturing signals in the KU band.
