Johansson 8701 Compact headers TITANIUM 8 DVBS to 4 DVBT CI
KSh423,138.00
Compact headend with 8 tuners and 4 output MUXs (DVB-T/C) / 2CI slots
Titanium is our newest compact headend solution that is suitable for small to medium-sized budget-friendly projects.
The transmodulator with 8 tuners allows for very fast installation.
Features
Standalone frame with built-in power supply
8 tuners
2 CI slots for CAM cards
4 output MUXs (DVB-T/C)
RF In & RF Out
This is what the customers value most about the TITANIUM
Selectable reference tuner for each CAM
User friendly web interface, see attached user manual.
SID remapping
Local Channel Numbering (LCN)
Full matrix flexibility between input, DVB-S(2) tuners, CAM modules, DVB-T/C multiplexes
EPG support (EPG is only processed for forwarded services)
PID filtering of e.g. Audio channels
Possibility to block all private data PIDs to save bandwidth
Possibility to prioritize important TV channels
Watchdog feature to guarantee uptime
Easily upgradable firmware
Specifications
Input: QPSK/8PSK (DVB-S/-S2)
Inputs – 4 satellite bands
1 x RF in
Tuners – 8 tuners (8 transponders)
Frequency range MHz 950-2150
Level dB?V 44 – 84
Bandwidth MHz 36
Modulation – DVB-S2: QPSK, 8PSK / DVB-S: QPSK
DC remote power at RF input – 13 V/18 V/22 kHz
Integrated multiswitch – Yes, allows flexible routing of satellite proframs to multiplexes
(QAM or QOFDM)
Configuration – Built-in webserver accessible via management port
Encoded programs – From all 8 tuners.
Can be routed through 1 or 2 CAMs and can be decoded
using multi-service CAMs
Max current per input to feed LNB mA 350 per input
Output: RF
Outputs – 1 with 4 MUXs (DVB-T or DVB-C)
DVB-T output Mbps Up to 31.7 / MUX
DVB-C output Mbps Up to 51.3 / MUX
Output level dB?V 69 – 84 (adjustable)
Output MER dB ? 43
General
Power consumption W 22 (excl. external LNBs)
Dimensions cm 34.5 x 7 x 18.2
Operating temperature ?C 0 to +50
Downloads / Documents
USER MANUAL
