Transmodulator with remultiplexado Twin DVBS/S2 – DVBT with…

Transmodulator that generates two COFDM multiplexes from the multiplexing of services available in up to 3 different TV SAT transponders. These can be extracted from 2 different satellites (2 independent SAT-IF inputs), by means of the input loop to the header itself.

Stands out for
Total or selective elimination of the services present in the received transponder, so that they are not detected (and memorized) by the receivers (STB)
Editable TS_ID, which facilitates the detection of programs / services in the receiver (STB) because they perform the scanning of channels based on this identifier
LCN (Logical Channel Number), allows to assign to the services present in the output an LCN, which facilitates the ordering of the channels in the receivers (STB)
It provides information about the occupation of each service and the total occupation of the output, which allows to optimize the distributed services
Remotely controllable with the CDC (Head Control)
Features
Insertion of null packages (“Stuffing”), allows faster scanning by the receiver (STB)
Filtering PID, allows to eliminate within a multiplex, those services that do not interest (use of occupation), very interesting with the use of CAM
S_ID editable, to avoid retuning of the receivers (STB) of an installation when the services of the output multiplex are changed
Network_ID, Original Network_ID and Cell_ID editable, allows to control the network identifiers
Through the CI interface and the corresponding CAM module, the coded satellite channels are transformed into free DTT services. Depending on the CAM used (standard / professional), one or several services can be opened for open viewing
Specifications
Reference 564301
SAT INPUT SAT Input frequency range MHz 950…2150
Frequency steps 1
Input level dB?V 42 – 82
Loop-through losses dB ? 1.5
LNB powering Vdc 13V/17V/ OFF – 22KHz (ON/OFF)
Input return losses (typ.) dB > 10?
Input impedance ? 75
DVB-S Symbol rate (Modulation) Mbaud 2 – 42.5 (QPSK)
FEC inner code Viterbi (1/2, 2/3, 3/4, 5/6, 7/8)
FEC outer code RS (188/204)
Roll-Off factor % 35
DVB-S2 Symbol rate (Modulation) Mbaud 10 – 30 (QPSK, 8PSK)
FEC inner code LDPC (1/2, 1/3, 1/4, 2/3, 2/5, 3/4, 3/5, 4/5, 5/6, 8/9, 9/10)
FEC outer code BCH (Bose-Chaudhuri-Hocquenghem)
Roll-Off factor % 20, 25, 35
DVB-C OUTPUT QAM Modulation (Constellation) QPSK, 16QAM, 64QAM
Guard interval ?s 1/4, 1/8, 1/16, 1/32
Scrambling DVB EN 300744
Interleaving DVB EN 300744
FEC outer code Viterbi (1/2, 2/3, 3/4, 5/6, 7/8)
PCR Correction Yes
Services deleting Yes
Network_ID Yes
Original Network_ID Yes
TS_ID Yes
LCN Yes
Spectral inversion Normal, Inverted
Channel bandwidth Mhz 7.8
RF Output frequency 46…862
Frequency steps KHz 166…125 (selectable by user)
Output level (max. typ.) dB?V >80 ? 5
Output level regulation margin dB >15
Output loop-through losses

? 1.5

Output return losses (typ.) > 12
Impedance ? 75
GENERAL Powering voltage Vdc 24
Consumption mA 530 (0 LNB – 0 CAM)
630 (0 LNB – 1 CAM)
880 (1 LNB* – 1 CAM)
1130 (2 LNBs* – 1 CAM)
Protection index IP 20
