U / UTP Data Cable Cat.-6 Dca Cu LSFH ? 6.2mm Violet 305m…
KSh66,430.00
Cable consisting of 4 pairs of copper wires, entangled pairs, housed in cavities.
Category 6 and Euroclass Dca data cable, type U/UTP (unshielded), with copper conductor and LSFH sheath. Its use is recommended for installations in which it is required to certify the network.
Stands out for
U/UTP type data cable
Solid copper center conductor (23AWG)
Compatible with PoE/PoE+ (Power over Ethernet) technology, allowing network devices to be powered through the cable itself
Features
Insulation of the copper conductor PE (Polyethylene) of 1.02mm diameter
LSFH (Low Smoke Free Of Halogen) outer sheath with 0.50mm thickness and 6.2mm diameter
72% rated speed
Specifications
Reference 2123
Guy UTP Cat 6 LSFH
External cover LSFH
External diameter hmm 6.2?0.2
cover color Violet
number of pairs 4
Driver Cu
conductor diameter hmm 0.57
conductor insulation PE
Maximum conductor resistance ?/100m 6.8
rated impedance ? 100
meters / spool m 305
