3 km wooden drum 2-fiber single-mode cable LSFH interior…
KSh450,120.00
Plastic coil of 750m.?2-fibre cable with LSFH sheath for indoor installation. Each fibre has its own individual LSFH sheath and is identified with a specific colour. This provides a better organization and makes identification easier.
2-fibre cable with LSFH sheath for indoor installation. Each fibre has its own individual LSFH sheath and is identified with a specific colour. This provides a better organization and makes identification easier.
Highlights
Low attenuation
Includes aramid fibres (kevlar) to reinforce its structure
Features
9/125, ITU-T G.657A2 fibre type
Coating diameter adapted to the fibre: 900 ?m
LSFH sheath, orange colour
Length of 3 km
Specifications
Euroclass Dca
Euroclass: Smoke Production s2
Euroclass: Flaming droplets d0
Euroclass: Acidity a1
Fiber core type Single-mode (ITU-T-G.657A2)
Fiber core diameter ?m 9
Fiber cladding diameter ?m 125
Coating buffer diameter ?m 250
Cable structure Tight buffer
Plastic buffer diameter mm 0.9
Outer sheath Diameter mm 3.5
Outer sheath Material LSFH
Blocking jelly No
Attenuation 1310nm dB/km < 0.4
Attenuation 1490nm dB/km < 0.4
Attenuation 1550nm dB/km < 0.3
Short tension N 500
Structure reinforcement element Aramid fibers
Short crush (@100mm) N 500
Minimum bending radius mm 17.5
Operating temperature ?C -20 ... 70
