Alcad EM-211 Custom front plate for bs (not bs-112)
KSh314.00
Alcad EM-211 – Serie 907: Custom front plate for bs (not bs-112).
TV-R/TV-R customised front plate for all BS outlet models except BS-100 and BS-112.
Downloads
Technical specification
Technical specification
Catalogues
CATALOGUE_ALCAD_EN_MULTIMEDIA_TV pdf 5.42 MB
Technical specifications
Related products
-
Read moreAlcad PT-620 – Serie 907: If user acces point, if splitter 6 out.
User access point for terrestrial and satellite TV. It has two inputs and six outputs. One of the inputs remains connected to the outputs while the other input is permanently connected to a 75 ohm load. Designed for the 5-2,400 MHz frequency range. Also available in 2-, 3-, 4-, 5- and 8-output models.
Applications
Designed for TV installations with two coaxial cables in which distribution to the houses is performed with a single coaxial cable. The signal which is distributed to the house is selected by changing the connections of the coaxial cables at the user access point.
Characteristics
Voltage blockage in the output connectors. No return path. Shielded zamak and metal plate chassis. F type connectors in machined zamak which form part of the chassis. Reduced dimensions.
Downloads
Technical specification
Technical specification
Catalogues
CATALOGUE_ALCAD_EN_MULTIMEDIA_TV pdf 5.42 MB
Technical specifications
-
Identification cover 10 pairs (Box 20 units) Televes
KSh16,020.00Add to cartIdentifying cover. For strip of 10 pairs. Cover that allows to identify each one of the pairs independently. Supplied in boxes of 20 units.
-
Mininode F.O. FiberKom CATV OLC (2 fibres) Televes
KSh81,152.00Add to cartOur range of FiberKom? includes units which operate in different return channel bands and/or modules that comprise one or two fibres
-
Read moreAlcad DI-803 – Serie 906: If splitter 8 out with dc path.
8-way splitter for terrestrial and satellite TV, covering all frequencies from 5MHz to 2,400MHz. It distributes all the input signal in equal parts among the 8 outputs. It has a feed path through any of its 8 outputs to the input. The response of the outputs is flat. Also available in 2-, 3-, 4- or 6-way models.
Applications
Individual and collective installations of terrestrial and satellite TV with a star-shaped distribution. They permit power to be fed from a preamplifier or LNB through any of the outputs. In installations with multiswitches, a control voltage can be sent through their outputs.
Characteristics
Protection diodes in all the outputs. Shielded zamak chassis and metal plate. Zamak F-type connectors which form part of splitter chassis.
Downloads
Technical specification
Technical specification
Manuals
DI-803 Manual pdf 923.93 KB
Catalogues
CATALOGUE_ALCAD_EN_MULTIMEDIA_TV pdf 5.42 MB
Certificates
CE Declaration – 906-DI_20210426 pdf 70.31 KB
Technical specifications
-
Read moreAlcad BS-102 – Serie 907: If terminal outlet, 2 db, 3 connectors.
Outlets for terrestrial and satellite TV with three male IEC connectors, an IEC female connector and an F-type female connector. They cover frequencies up to 2,300MHz. They allow a feed path via the female F-type connector to the input.
Applications
Outlets for terrestrial and satellite TV with three male IEC connectors, an IEC female connector and an F-type female connector. They cover frequencies up to 2,300MHz. They allow a feed path via the female F-type connector to the input.
Characteristics
Shielded zamak and metal plate chassis. Connection of the coaxial cable by means of screw terminal. Includes TV/R/SAT frontplate, surface box and screws for fixing to a wall.
Downloads
Technical specification
Technical specification
Catalogues
CATALOGUE_ALCAD_EN_MULTIMEDIA_TV pdf 5.42 MB
Technical specifications
