Alcad SP-245 Frame d47 for 2 psu and 8 modules
KSh5,870.00
Alcad SP-245 – Serie 912: Frame d47 for 2 psu and 8 modules.
Support frame for 912-series headends with redundant power supplies. It can hold up to 2 power supplies, one amplifier and 7 modules, or 2 power supplies and 8 modules. There is a 47 mm distance between modules to allow for better heat disipation.
Downloads
Technical specification
Technical specification
Catalogues
CATALOGUE_ALCAD_EN_MULTIMEDIA_TV pdf 5.42 MB
