Derivator 8 outputs (Easy clema connection) 16db EST 8-16 Triax

Derivator 8 outputs (Easy clema connection) 16db EST 8-16 Triax

KSh2,330.00

Derivator 8 outputs (Easy clema connection) 16db EST 8-16.

Specifications
Model ? EST 8-16
Code ? 349816
Frequency range MHz 5 – 2400
No. of outputs pcs 8
Lost in step (typical) 5 – 40 MHz dB 04
40 – 1000 MHz dB 4.5
1000 – 1750 MHz dB 05
1750 – 2150 MHz dB 5.5
2150 – 2400 MHz dB 06
Lost in shunt 5 – 40 MHz dB 16.0 (? 1.5)
40 – 1000 MHz dB 16.0 (? 2.0)
1000 – 1750 MHz dB 17.0 (? 2.0)
1750 – 2150 MHz dB 17.0 (? 2.5)
2150 – 2400 MHz dB 18.0 (? 3.0)
Decoupling dB 22
Missed return (input / output) dB 12
Lost of return (derivation) dB 14
Protection of the shield dB ? 110.0
Current passage ? Input / Output
Impedance Ohm 75
Measurements?(h x d x w) mm 124 x 40 x 20
