Ikusi ATP-290-C48 Amplifier 1 input 2 outputs…
KSh8,132.00
IKUSI ATP-290-C48. Apartament amplifiers ATP290 series. Models for terrestrial and satellite signals, adapted to the 1st and 2nd Digital Dividend.
Features
Models adapted to the 1st and 2nd Digital Dividend.
Terrestrial and satellite outputs.
Gain adjustment potentiometers.
Return path.
DC transit OUT1.
Technical specifications
Model? ATP290-C60
ATP290-C48 Ref.? ATP290 series
3592 Frequencies MHz 47 – 790 950 – 2400
3593 47 – 694
Input 1
Outputs 2
Gain dB Terr: >14 Sat: >18
Gain adjustment dB Terr: >10 –
Output level dB?V Terr: 102
IMD3 -60dB (DIN 45004B) Sat: 108
IMD3 -35dB (EN 50083-3)
Return path frequency MHz 5 – 30 (OUT1)
Noise figure dB <5 <6
Mains supply voltage VAC 100 - 240
DC transit mA 500 (OUT1)
Consumption W <3
Dimensions mm 135 x70 x 30
?
MANUAL/DATASHEET
