Johansson 4512 Shunt 1 way 20dB

Johansson 4512 Shunt 1 way 20dB

KSh692.00

1-way broadband tap
Low insertion loss
Silver zinc housing
“F” type connectors
Passage of DC current in all outputs (with protection diode) Frequency: 5-2300 MHz
Derivative losses: 20 dB
Step losses: < 3 dB Isolation: > 25dB
loss return: > 10dB
Specifications
Frequency MHz 5-2400
Insertion Loss @ 5-862MHz dB < 3 Insertion Loss @ 950-1550MHz dB < 3 Insertion Loss @ 1551-2150MHz dB < 3 Insertion Loss @ 2151-2400MHz dB < 4 Tap?loss @ 5-862MHz dB < 20 Tap?loss @ 950-1550MHz dB < 20 Tap?loss @ 1551-2150MHz dB < 21 Tap?loss @ 2151-2400MHz dB < 22 Isolation @ 5-1550MHz dB > 30
Isolation @ 1551-2400MHz dB > 30
Return loss in/out/touch dB 10
DC power pass through (out/in) – 1
Dimensions mm 47x56x21
