Pigtail Patch Cord (900?m) FO Singlemode for Indoor LSFH…
KSh726.00
Pigtail Single-mode (SM) fiber optic patch cord. It has one end pre-terminated with an LC/UPC connector, and the other end without connector. This allows easy fusion of the pigtail against a fiber cable. The 900?m cover is LSFH type and is recommended for indoor use.
Pigtail Single-mode (SM) fiber optic patch cord. It has one end pre-terminated with an LC/UPC connector, and the other end without connector. This allows easy fusion of the pigtail against a fiber cable.
The 900?m cover is LSFH type and is recommended for indoor use.
Main features
ITU-T G.657.A2 fiber type
LSFH sheath, white colour
LC/UPC connectors
1m long
Specifications
Fiber core type Single-mode (ITU-T-G.657A2)
Fiber core diameter ?m 9
Fiber cladding diameter ?m 125
Coating buffer diameter ?m 250
Cable structure Tight buffer
Outer sheath Diameter mm 0.9
Outer sheath Material LSFH
Blocking jelly No
Attenuation 1310nm dB/km < 0.5
Attenuation 1550nm dB/km < 0.5
Insertion losses in connector 1 dB < 0.5
Return losses in connector 1 dB > 50
Optical connector type 1 LC
Polishing type (Optical connector 1) UPC
Operating temperature ?C -20 … 70
