2-Way EasyF DTT-SAT 20dB Tap Televes
2-way EasyF DTT-SAT Mini-tap Televes 542703
Very compact tap with EasyF (Flange) type connections with 2 outputs and 20dB attenuation, to distribute DTT and Satellite signals (5-2400MHz).
The tap are equipment with 1 pass output for mounting in cascade, this through output has very low attenuation. They are passive distribution equipment, intended primarily for multi-dwelling installations, which are governed by ICT regulations.
Its ultra-reduced size (57x46x11mm) and its EasyF system, makes the installation of this equipment easy and comfortable. Due to its high losses, this shunt is designed to be installed between floors 4 and 6 of the building.
For indoor installation, being able to be installed outdoors always inside a chest.
Televes mini-tap with 2 flange or EasyF outputs with 20dB attenuation for DTT and SAT (5-2400MHz).
What are the main characteristics of the Televes 542703 tap?
EasyF connection system: easy to install, savings on mounting
Made of Zamak, high shielding
Outstanding reliability: automated manufacturing using new generation micro-components
Improves through losses
Outstanding electrical behaviour: impulsive noise reduction
Grounding screw provided
Bidirectional DC pass between input and pass output
What technical specifications does the Televes 542703 tap have?
Frequency range MHz 5-2400
5-862 950-2400
Number of outputs 2
Floors 4 & 5 & 6
Through loss dB 0,5?2,2 0,5-2,2
Tap loss 21
Rejection between taps >30 >22
DC Pass (max.) mA 300 (in.?out.)
