Alcad CA-662 Ampli uhf-uhf-biii-bi/fm lte700 everest
KSh29,146.00
Alcad CA-662 – Serie 904: Ampli uhf-uhf-biii-bi/fm lte700 everest.
Broadband amplifier for head-end, with four inputs and different frequency configurations, compatible with the transmission of LTE700 and LTE800 mobile telephone signals. The built-in power supply unit can feed a preamplifiers by means of a switch. Optional external power supply for redundant power. Output test-point to adjust the installation without having to disconnect the TV signal.
Applications
Large-scale digital and analogue MATV installations which are affected by the transmission of LTE700 and LTE800 mobile telephone signals. Suitable for installations where the channels of each band are received at similar levels. Adjustment by means of switches and regulators which control the gain at each input.
Characteristics
Made from zamak and galvanised steel plate to provide maximum shielding. Input and output connectors in the opposite sides to facilitate installation. F-type connectors.
Downloads
Technical specification
Technical specification
Manuals
CA-662 Manual pdf 1.3 MB
Catalogues
CATALOGUE_ALCAD_EN_MULTIMEDIA_TV pdf 5.42 MB
Certificates
CE Declaration – CA-661-662-663 20210716 pdf 70.79 KB
Flyers
EVEREST flyer pdf 578.79 KB
Technical specifications
