Alcad PF-220 Satellite dish 65 cm steel (x1)
KSh7,158.00
Alcad PF-220 – Serie 912: Satellite dish 65 cm steel (x1).
Offset type parabolic antenna with high gain and efficiency. The assembly of the antenna is simple, once installed it is very robust and assures great orientation stability. The packaging includes fittings which avoid damage to the dish during transportation.
Applications
Suitable for satellite TV installations, collective or individual. The antenna is available in three sizes: 100 x 95 cm for collective installations; 85 x 80 cm and 65 x 60 cm for individual installations.
Characteristics
Robust antenna with great resistance to sun and saltpetre. The dish is made from epoxy covered galvanised steel and the accessories are of galvanised iron.
Downloads
Technical specification
Technical specification
Manuals
– pdf 1.49 MB
Catalogues
CATALOGUE_ALCAD_EN_MULTIMEDIA_TV pdf 5.42 MB
Technical specifications
