Antena parab?lica prato QSD de alum?nio de 85 cm HQ (alta…
KSh64,126.00
Antenna Satellite Dish QSD Televes 85 cm HQ (High Quality) Color: Orange
This product is not sent to some countries or areas, if the cart does not have available carriers, you can contact us here
The new QSD line of Televes satellite dishes are launched to market after careful and strict product requirements that guarantee maximum performance against? corrosion, resistance to wind and ease of installation.
Features
Aluminium dish reflector, with diecast Zamak LNB holder.
Folding arm for fast and?easy mounting.
Pre-mounted?support and arm.
Robust back support.?Hot-dip galvanized.
Hidden cable routing system?with folding tabs.
Screws in?stainless steel.
German?T?V Approved.
Specifications
Reference ?7903
?Dimensions (W ? H) mm 850 x 950
?Gain dB 39,5
?Frequency range GHz 10,7…12,75
?Beamwidth (- 3 dB) ? 1,9
?F/D ratio 0,6
?Elevation angle limits ? 10-80
?Weight (approx) Kg 14,5
Wind load 130 Km/h N 672
150 Km/h 924
?Antenna height m ?20 >20
?Wind pressure N/m? 800 1100
?Wind speed Km/h 130 150
Related products
-
Televes ISD Offset dish 83cm Aluminum 39dBi White
KSh19,116.00Add to cartThis new range of satellite dishes is built using aluminium and stainless steel to guarantee the protection against rust.
-
Add to cartThis product is not sent to some countries or areas, if the cart does not have available carriers, you can contact us here
TRIAX TD Dishes?The difference is clear
Manufactured and tested to the highest standards of precision and quality, TRIAX?s easy-to-install dishes offer outstanding performance, durability and reliability.
TDS: Steel???? TDA: Aluminium
Features
Unrivaled build quality, whether Steel or Aluminium
– Hot-dip galvanized steel OR long lasting Aluminium – for extra corrosion protection?
– TRIAX?s unique cable protection system?
– Every part, every accessory is weatherproofed
– 2 years corrosion warranty
– 5 years functionality warranty
Outstanding performance
– High gain for an exceptional signal
Quick and easy installation
– One-click mounting system
– Self-locking screw & nuts
Logistic friendly
-?Single or Bulk packaging, according to customer needsTRIAX is your reliable partner, with?comprehensive service and support.?
Specifications
ORDER INFORMATION
EAN Number 5702661205088
CHARACTERISTICS
Elevation range 0…90 ?
Offset angle 25.6 ?
F/D ratio 0,62
FREQUENCY
Frequency range 10.7…12.75 GHz
GAIN
Gain @ 11.7 GHz 36.5 dBi
Gain @ 10.70 GHz 38.5 dBi
Gain @ 12.75 GHz 37 dBi
MECHANICAL
Main material Galvanized steel (hot-dip)
Colour RAL 7016 – Anthracite grey
Arm Colour Raw
Total Weight 5,600 kg
LNB holder 40
Net Weight 4,210 kg
Packing QTY 1
Reflector type Offset
Width (cm) 71 cm
Height (cm) 79 cm
Packaging Depth 0,100 m
Packaging Height 0,870 m
Packaging Width 0,832 m
Tara Weight 1,390 kg
Packaging Volume 0,072 m3 -
Add to cartLarge aluminum offset dish antenna (141×130 cm) to receive satellite signals in areas of low satellite coverage. LNB support made of ABS plastic, black color, resistant to UV rays, for 40mm horn neck. Arm 30mm wide. Two 12mm stainless steel braces. Adjustable lifting angle between 30 ? and 80 ?. For 60mm masts. Televes 757401
-
Alcad PF-420 Satellite dish 80 cm steel (x1)
KSh10,536.00Add to cartAlcad PF-420 – Serie 912: Satellite dish 80 cm steel (x1).
Offset type parabolic antenna with high gain and efficiency. The assembly of the antenna is simple, once installed it is very robust and assures great orientation stability. The packaging includes fittings which avoid damage to the dish during transportation.
Applications
Suitable for satellite TV installations, collective or individual. The antenna is available in three sizes: 100 x 95 cm for collective installations; 85 x 80 cm and 65 x 60 cm for individual installations.
Characteristics
Robust antenna with great resistance to sun and saltpetre. The dish is made from epoxy covered galvanised steel and the accessories are of galvanised iron.
Downloads
Technical specification
Technical specification
Manuals
– pdf 169.98 KB
Catalogues
CATALOGUE_ALCAD_EN_MULTIMEDIA_TV pdf 5.42 MB
Technical specifications
-
Add to cartThis product is not sent to some countries or areas, if the cart does not have available carriers, you can contact us here
TRIAX TD Dishes?The difference is clear
Manufactured and tested to the highest standards of precision and quality, TRIAX?s easy-to-install dishes offer outstanding performance, durability and reliability.
TDS: Steel???? TDA: Aluminium
Features
Unrivaled build quality, whether Steel or Aluminium
– Hot-dip galvanized steel OR long lasting Aluminium – for extra corrosion protection?
– TRIAX?s unique cable protection system?
– Every part, every accessory is weatherproofed
– 2 years corrosion warranty
– 5 years functionality warranty
Outstanding performance
– High gain for an exceptional signal
Quick and easy installation
– One-click mounting system
– Self-locking screw & nuts
Logistic friendly
-?Single or Bulk packaging, according to customer needsTRIAX is your reliable partner, with?comprehensive service and support.?
Specifications
ORDER INFORMATION
EAN Number 5702661205002
CHARACTERISTICS
Elevation range 0…90 ?
Offset angle 26 ?
F/D ratio 0,62
FREQUENCY
Frequency range 10.7…12.75 GHz
GAIN
Gain @ 11.7 GHz 35 dBi
Gain @ 10.70 GHz 37 dBi
Gain @ 12.75 GHz 34 dBi
MECHANICAL
Main material Galvanized steel (hot-dip)
Colour RAL 7016 – Anthracite grey
Arm Colour Raw
Total Weight 4,270 kg
LNB holder 40
Net Weight 3,220 kg
Packing QTY 1
Reflector type Offset
Width (cm) 60 cm
Height (cm) 66 cm
Packaging Depth 0,100 m
Packaging Height 0,734 m
Packaging Width 0,684 m
Tara Weight 1,050 kg
Packaging Volume 0,050 m3
