Coaxial Cable Cu / Cu Bury Dca 10mm (250m)
TR165 Coaxial Cable Bury Cu / Cu Class A Euroclass Dca 10mm Televes 214911 (250m)
TR165 Coaxial Cable with conductor and mesh made of copper (Cu / Cu), with gray halogen-free outer jacket LSFH, it can be installed indoors and outdoors but mainly it is made to install underground without damaging the cable and thus not losing signal quality.
Cable made with 2 layers of Class A shielding that offer great shielding against interference that may occur. Its Euroclass Dca classification establishes a good reaction in case of fire by not spreading the flame and a lower emission of heat.
Conductors made of copper offer great response at both low and high frequencies, with the least radioelectric resistance
TR-165 Cu/Cu double shielded Coaxial Cable Class A for Burying with LSFH sheath and Euroclass Dca
What are the main characteristics of the Televes 214911 Coaxial Cable?
Conductors made of copper
Class A shielding
Euroclass Dca-s2, d2, a1
Petro-gel layer
LSFH outer cover, UV resistant, gray
Characteristic impedance of 75 ohm
250m wooden spool
What technical specifications does the Televes 214911 Coaxial Cable have?
Tipo TR-165
Est?ndard EN 50117-2-5
EuroClase Dca-s2,d2,a1
Clase A
Conductor central ? mm 1,63
Material CU
Res. Ohm/Km 9
Diel?ctrico ? mm 7,2
Material PEE
L?mina interior Aluminio + Polipoprileno + Aluminio
Malla Material Cu
Dimensiones (Ncx Nsx ?) 16 x 8,5 x 0,148
Res. Ohm/Km <7
% cobertura 77
L?mina antimigratoria No
Petro-Gel S?
Cobertura exterior ? mm 10,1
Material LSFH, Resistente UV
Radio de curvatura m?nimo mm 50
Blindaje a 1GHz dB >85
Capacidad pF/m 53
Impedancia Ohm 75
Impedancia de Transferencia (5-30MHz) mOhm/m ?5
Velocidad de propagaci?n m?n. % 84
Atenuaciones (dB/m)
Frecuencia (MHz)
5 0,005
47 0,02
90 0,04
200 0,05
500 0,09
800 0,11
1000 0,13
1350 0,15
1750 0,18
2050 0,19
2300 0,21
