Coaxial cable SK2015plus LSFH Resistant UV Cca Class A++…
KSh46,464.00
SK2015plus Coaxial cable, 18AtC
Cca Euroclass, A++ Class shielded
Coaxial cable with both conductors made of copper (Cu/Cu) and excellent braid coverage (82%). Triple shielded (TSH) cable, equipped with a second foil for extra shielded. An 18AtC cable with UV-resistant LSFH sheath.
Highlights
Copper conductors
Class A++ shielded
Cca Euroclass
Features
External UV-resistant LSFH sheath, white colour
75 Ohm characteristic impedance
100m plastic coil
?
Class A++ Trishield (TSH) coaxial cable
With three shielding layers (Trishield), this cables provide the highest immunity to interference thanks to its very high shielding. Recommended in cases of high electromagnetic noise levels.
They belong in EN 50117 standard Class A++, according to their structural properties:
For 5 MHz – 30 MHz => TI < 0.9 m?/m
For 30 MHz - 1000 MHz => SA > 105 dB
For 1000 MHz – 2000 MHz => SA > 95 dB
For 2000 MHz – 3000 MHz => SA > 85 dB
Where the transfer impedance (TI) defines how effective the shielding is at low frequencies, while the shielding attenuation (SA) defines it in the 30 MHz-to-3000 MHz range.
Specifications
Type SK2015plus
Standard EN 50117-2-4
Euroclass Cca
Class A++
Inner conductor ? mm 1,05
Material Copper
Res. Ohm/Km 22
Dielectric ? mm 4.6
Material Expanded polyethylene?
Inner foil Aluminium + Polyester
Braid Material Tinned copper (98%Cu)
Dimensions (Nc x Ns x ?) 24 x 7 x 0.10
Res. Ohm/Km <11
% coverage 82
2nd shielding foil S?
Petro-Jelly No
Outer sheath ? mm 6.9
Material LSFH, UV Resistant
Bending radius minimum mm 34.5
1GHz shielding dB >105
Capacitance pF/m 54
Impedance Ohm 75
Transfer impedance (5-30MHz) mOhm/m <0.9
Velocity ratio % 82
Attenuation (dB/m)
Frequency (MHz)
200 0.09
500 0.14
800 0.18
1000 0.21
1350 0.24
1750 0.28
2050 0.3
2300 0.31
