Coil 100 m Multifiber cable 48 fibers singlemode Euroclass…
KSh114,708.00
48-fibre cable with UV-resistant LSFH sheath for indoor and outdoor installation. Divided in 6 micro-modules of 8 fibres each, each with its own LSFH sheath and different colour. This provides a better organization and makes identification easier. Coil 100 m
Multi-fibre cable 48 single-mode fibres
Dca Euroclass and UV-resistant LSFH, indoor/outdoor
48-fibre cable with UV-resistant LSFH sheath for indoor and outdoor installation. Divided in 6 micro-modules of 8 fibres each, each with its own LSFH sheath and different colour. This provides a better organization and makes identification easier.
Coil 100 m
Highlights
Dca-s2,d2,a1 Euroclass
Low attenuation
Organized in fibre micro-modules
Blocking jelly, offering great protection against water
Good structure reinforcement using aramid fibers (kevlar), which allows to maintain its traction without the need for a central guiding wire for resistance
Features
9/125, ITU-T G.657A2 fibre type
Coating diameter adapted to the fibre: 250 ?m
Ripcord to open the outer sheath
UV-resistant LSFH sheath, orange colour
Specifications
Cable type Indoor/Outdoor
Fibre type 9/125 (G657A2)
Number of fibres 48
Attenuation 1310nm dB/Km ?0,35
1550nm ?0,21
Micro-modules Material LSFH (Low Smoke Free Halogen)
Filler Water blocking petrol-jelly
Diameter mm 01,1 ?0,1
Outer sheath Material UV-resistant LSFH (Low Smoke Free Halogen)
Color Orange
Diameter mm 7,6 ?0,4
Min. bending radius mm 76
Short tension N 1000
Short crush N/100mm 1000
Operating temperature ?C -5 … 60
