Derivator 1 output (Connector F) exterior / interior 24db...

Derivator 1 output (Connector F) exterior / interior 24db…

KSh424.00

Shunt 1 output (Connector F) exterior / interior 24db OTT 1-24

Specifications
Model ? OTT 1-24
Code ? 349124
Frequency range MHz 5 – 2400
No. of outputs ? 1
Lost in step 5 – 40 MHz dB dB < 1.0 40 - 1000 MHz dB < 1.0 1000 - 1750 MHz dB < 1.8 1750 - 2150 MHz dB < 2.0 2150 - 2400 MHz dB < 2.5 Lost in shunt 5 - 40 MHz dB dB 24.0 (? 2.0) 40 - 1000 MHz dB 24.0 (? 1.5) 1000 - 1750 MHz dB 24.0 (? 1.5) 1750 - 2150 MHz dB 24.0 (? 2.0) 2150 - 2400 MHz dB 24.0 (? 2.5) Decoupling dB > 35.0
Missed return (input / output) dB > 14.0
Lost of return (derivation) dB > 12.0
Protection of the shield dB ? 110.0
Current passage ? Input / Output
Impedance Ohm 75
Measurements (h x d x w) mm mm 74 x 40 x 20
