Double FO Singlemode LSFH Dca Patch Cord Preconnected SC/APC…
KSh12,768.00
Single-mode (SM) optical-fibre patch cord Pre-terminated with SC/APC connectors for the connection of the elements of an optical network. Furthermore, since they are duplex, they are suitable for use in point-to-point networks that use the same window for both upstream and downstream traffic. The sheath being LSFH, it is recommended for indoor use.
Highlights
Low attenuation levels and high reliability
Connectors mechanically outphased on one end to facilitate wiring
Equipped with locks and removable fixing devices: the fibres may be kept together or separate
Includes identifiers for each of the fibres
Dca-s2,d2,a1 Euroclass
Main features
ITU-T G.657A2 fibre type
Duplex patch cord: two fibre cables
LSFH sheath, orange colour
SC/APC connectors
Length 40m
Specifications
Technical specifications
Euroclass Type Dca-s2,d2,a1
Fiber Type Single Mode
Opctics connectors Type SC/APC
Cover material Type LSFH
Attenuation dB ? 0,8
Insertion losses dB < 0,5
Return losses (in each patch cord ) dB >60
Minimum radius of curvature mm 30
Outside diameter of the fiber mm 3
