F 2W splitter 5…2400MHz 5/4dB Televes
2-way splitter with F connectors, for SMATV signals. It presents low through losses thanks to the miniaturization applied to the electronic components, which improves its electrical behavior. In addition, its Zamak chassis provides great shielding.
6-way splitter with PAU F 6D
5…2400MHz 12/11dB
6-way splitter with PAU and F connectors, for SMATV signals. It presents low through losses thanks to the miniaturization applied to the electronic components, which improves its electrical behavior. In addition, its chassis provides great armoring as it is made of Zamak.
The PAU (User Access Point) offers an additional charged input for connection of the second downspout contemplated in an installation carried out according to the ICT-2 regulation.
Splitter for indoor installation, mounted on the wall, on a rack plate or on a DIN rail.
Stands out for
Assembly flexibility: it can be installed screwed to the wall, on rack plates with nuts on their connectors, or on a DIN rail (with adapter ref. 519901)
Ease of threading the cable, thanks to the 10? angle of inclination of the F connectors with respect to the installation wall
Optimization of space in registers and cabinets: its connectors are always located on the same side
Better organization of the installation: it allows the passage of the wiring through its rear part
Range can be chained together, using the ground screw itself, requiring a single grounding cable
Maintains levels on tap, even with long cable runs, thanks to better flatness in step response
High reliability: robotized online manufacturing with state-of-the-art microcomponents
100% European design, quality and manufacturing
Main features
Low through losses
Great shielding (class A), made of Zamak
F connectors with a longer threaded section, to facilitate and secure their installation on a rack plate
indoor mounting
Includes ground screw
Passage of DC from the outputs to the input
Specifications
frequency range MHz 5…2400
number of outputs 6
Tickets/Bands
TERR SAT
step losses dB
12 eleven
Reject between outputs dB
> 20 > 20
Max voltage Vdc 24
max current mA 350
DC Step Out?In
