H30+ (DVB-C) sprectrum analyzer Televes

All the functions you need, also in CATV cable systems

The H30+ is a lightweight, compact and robust equipment that includes a full range of tools and functionalities to successfully perform installation, maintenance and troubleshooting tasks in both analogue networks and digital networks with DVB-C channels. It stands out for incorporating automatic monitoring of the desired channel, double-check connectivity and the information about a QAM channel program content, among other powerful functions.

Operating the meter is more flexible thanks to its multiscreen system: the user can manage it remotely and display its contents on their own mobile device (Android, iOS or PC). Wi-Fi and Bluetooth connectivity will let you work with all the conveniences of a wireless connection. In addition, to make the use of the smartphone even more natural, a universal bracelet is provided for devices up to 6″.

Just as the rest of the meters fully designed and manufactured in Televes Corporation, H30+ takes advantage of the digital processing technology, and provides the user with a speed and mathematical accuracy equivalent to that of laboratory equipment.

Highlights
Multiscreen system with touch control: display the meter screen on a mobil device, and control the meter by touch gestures and buttons
WiFi and Bluetooth connectivity
Real-time digital processing
Light-weight handheld meter
User friendly interface
With WiFi / IPTV analyzers and HEVC display as options
Automatic parameter detection: the H30+ automatically detects signal type (A/D) and parameters to be measured (constellation, symbol rate, etc)
All measurements are carried out by pressing a single button equipped with Pass/Fail indicators to reduce installation errors
Discover

Differences between the H30+ and H30D+ models

Within the H30+ and H30D+ range of meters, we can find different models with specific functionalities depending on the needs of the cable installers. The comparative table compiling the most representative differences between them is detailed below:

? H30+ H30D+ H30D+ FULL
Frequency range ? 5 … 1002 MHz 5 … 1220 MHz 5 … 1794 MHz
Screen ? 2.8? TFT 400 x 240 full color 2.8? TFT 400 x 240 full color 2.8? TFT 400 x 240 full color
Multi-screen with touch control on mobile device ? OK OK OK
Smartphone armband ? OK OK OK
2,4 / 5GHz Wi-Fi connectivity ? OK OK OK
Bluetooth connectivity ? OK OK OK
Ethernet interface ? OK OK OK
USB interface ? USB (A-type) USB (A-type) USB (A-type)
DVB-C digital measurements ? OK OK OK
DVB-T digital measurements ? X X OK
DVB-T2 digital measurements ? X X OK
DOCSIS 3.1 ? X OK OK
Wi-Fi Analyzer ? OK(*) OK(*) OK
IPTV analyzer ? OK(*) OK(*) OK
HEVC displaying on the meter OK(*) OK(*) OK
on the mobile device OK(*) OK(*) OK
MPEG service information ? OK OK OK
IP speed test ? OK OK OK
Long Term Monitoring ? OK OK OK
Management interface access (datalogs, channel plan?) ? Wireless (Wi-Fi/Bluetooth) Ethernet cable Wireless (Wi-Fi/Bluetooth) Ethernet cable Wireless (Wi-Fi/Bluetooth) Ethernet cable
Dimensions ? 175x100x52 mm 175x100x52 mm 175x100x52 mm
Weight ? 529 g. 633 g. 633 g.
Color ? Black & Grey Black & Orange Black & Orange
Specifications
H30+
Mechanical Specifications
Screen 2.8? TFT 400 x 240 full color
Weight 529 g (1.16 lb)
Dimensions

175x100x52 mm / 6.9×3.9×2 (HxWxD)

AC Adaptor Input: 100-240 V~ 50-60 Hz Output: 12 VDC, 2 A
Battery Li-ion (7.2 VDC, 2550 mAh)
Battery range <4 without LNB powering Interfaces Bluetooth, Wi-Fi 2.4/5 GHz, Ethernet 1Gb, USB 2.0 Resilience It withstands drops From 1 m (3.2 ft) onto concrete on all sides Storage capacity 400 MB (internal) for measurements Impedance F-type connector - 75 Ohm Technical Specifications ?Frequency 5 to 1,002 MHz ?Resolution 50 kHz ?Input Impedance 75 Ohm ?Input level 45 - 125 ?Standards ITU-T J.83 Annex A/B/C standard ?Modulation 16/32/64/128/256 QAM, QPSK ?Symbol Rate 2 to 6.9 Msps ?MER 40 dB ?Digital Measurements DVB-C Power MER C/N PreBER (Annex B) PostBER (Annex B) BER (Annex A/C) Constellation with Zoom Capability ?Analog Measurements V/A ratio C/N ?MPEG Service Information ? ?IP Speed Test ? ?Advanced API ? ?Wi-Fi and Bluetooth Connectivity ? ?Long Term Monitoring ? ?Wi-Fi Analyzer Optional ?Services and IPTV Analyzer Optional ?HEVC display Optional
