Johansson 16 Way X16 User Band DSCR Multiswitch
4 satellite + 1 Terrestrial inputs
16 outputs with 16 User Band per output
Product code: 9748MC
4 satellite + 1 Terrestrial inputs
16 outputs with 16 User Band per output
• Up to 16 UBs per SCR Output
• Auto Detection for SCR and Legacy Mode
• Support all SCR standards
• Compatible with all Legacy STBs
• Amplified / Bypass terrestrial diplexer
• Soft power-up mode for Legacy
• Power diagnostics for trunk power
EACH 974XMC UNIT HAS:
• 4 cascadable LNB inputs for a universal Quattro/Quad LNB
• 1 terrestrial trunk
• 4, 8 or 16 SCR/Legacy outputs (9744MC, 9746MC or 9748MC)
• 1 DC input
EACH OUTPUT CAN SUPPORT A WIDE VARIETY OF SATELLITE RECEIVERS:
• In Legacy mode, the 974xMC outputs can be used as a standard
multiswitch
• In SCR mode, each 974xMC output supports up to 16UBs with all versions of
the single cable technology
• This includes OLT, SCR, CSS, EN50494, EN50607, and newer versions
AS ALL OUTPUTS ARE INDEPENDENT, THE INSTALLATION CAN BE A MIX OF LEGACY AND
SCR CONNECTIONS
THE OUTPUTS WILL AUTOMATICALLY DETECT THE APPROPRIATE MODE (SCR OR
LEGACY)
The terrestrial path allows support of any service operating below 1 GHz,
including terrestrial cable and DOCSIS reception
• The terrestrial path can be amplified or bypass
• via user selected switch
• LTE 4G ready – built in filtering
MULTIPLE WAYS TO POWER THE PRODUCT
• Powered from the DC Input: use ref. 2460(UK)
• Power from Trunk : this is if another 974xMC is
• powering the system
– Each product has a power-up diagnostic mode with a LED to indicate if
power is adequate for the system
• Power from the STB or MC power insertor
• Special low power Legacy mode <2W
DSCR MULTISWITCHES
• 4 cascadeable LNB inputs from universal Quattro LNBF :
VL-HL-VH-HH
• 1 terrestrial trunk (active or passive)
• 4/8/16 SCR/Legacy outputs
• 16 User Bands per output
• 1 DC input.
SKU: 9748MC Categories: Johansson, Multiswitches, Satellite Tags:
Johansson, Multiswitch
