LNB Inverto Multiconnect Dielectric Twin 23mm
This innovative LNB was specifically designed for installations that make use of several LNBs on a satellite dish antenna. It?s novel slim feed technology incorporates advanced dielectric materials and a perfect front end design. This technology ensures maximum energy transfer from the dish to the LNB circuits also when the LNB position is off the focal point. Furthermore, it?s long neck allows placing the LNBs closely next to each other and gain access to satellites typically too close in their orbital position to be received with standard neck LNBs on a certain satellite dish antenna. This LNB enables the reception of signals from one satellite and its distribution to maximum two Set Top Boxes with Single Tuner (or to one STB with Twin Tuner).
Features
Novel Slim Feed Technology
Low Phase Noise, DVB-S2 (HDTV) compliant
Low Noise Figure
Low Power Consumption
High Cross Polarization Isolation
High Frequency Stability
Specificatinons
Inverto IDLB-TWNL24-MULTI-OPP
Low Band Input Frequency Range 10.7 ~ 11.7 GHz
Low Band Output Frequency Range 950 ~ 1950 MHz
Low Band LO Frequency 9.75 GHz
High Band Input Frequency Range 11.7 ~ 12.75 GHz
High Band Output Frequency Range 1100 ~ 2150 MHz
High Band LO Frequency 10.6 GHz
Noise Figure 0.2 dB Typ. (0.7 dB Max.)
LO Initial Accuracy +/- 1.0 MHz Max.
LO Temperature Drift +/- 3.0 MHz Max.
Phase Noise (@ 10 kHz) – 90 dBc / Hz Max.
Conversion Gain 60 dB Min.
Gain Ripple (Over 26MHz Bandwidth) +/- 0.75 dB
Gain Variation (Over Full Band)? +/- 4 dB Max.
Image Rejection 40 dB Min.
1 dB Compression Point (@ Output) 0.0 dBm Min.
Cross Polarization Isolation 22 dB Min.
Control Signal Ca (Vertical Polarization) 11.0 ~ 14.0 V
Control Signal Cb (Horizontal Polarization) 16.0 ~ 20.0 V
Control Signal Cc (Band Switching) 22 +/- 4 kHz
Output VSWR 2.0 : 1?
In-Band Spurious – 60 dBm Max.
Current Consumption 180 mA Max. @ 11 ~ 20 V
Operating Temperature – 30 ?C ? + 60 ?C
Output Impedance 75 ?
Output Connector F-Type (Female)
Weight 181 g
