MATV (bridged)
KSh1,604.00
TOMA TERMINAL PUENTEADA
?
A simple push is enough to connect the inner conductor, no screws needed.
Allows the visualization of the connection.
Support an inner conductor with diameters ranging from ? 0,65 to ? 1,2 mm.
Support an outdoor cable with a diameter ranging from ? 5 to ? 6.9 mm.
Compliant with the European guidelines 2004/108/CEE and 2006/95/CEE.
The outlets with data connection are compatible with DOCSIS 3.0
Related products
-
FM-TV 4 dB end outlet Low losses 5-862 MHz
KSh2,018.00 -
Add to cartIKUSI ARTU 088. OUTLETS ARTU SERIES
Features
Filtered outlet sockets for individual or cascade assembly.
Fast clamping of the cable thanks to the swivel flange.
Easy connection using the system to insert live product.
Minimum current losses.
Current flow through the C2 connector, SAT output.
Compatible with the main wall-covering plates on the market.
Technical specifications
Modelo
Model
Mod?le ARTU088 ARTU068
Ref. 2570 2571
Instalaci?n
Installation
Installation Indivudual
Single
Individuel
Tipo
Type
Type Filtrada
Filtered
Filtr?
Conector
Connector
Connecteu C1 IEC macho
IEC male
IEC m?le
C2 IEC hembra
IEC female
IEC f?melle
Rango de frecuencias
Frequency range
Bande passante C1 5 – 862 MHz 5 – 694 MHz
C2 950 – 2400 MHz
Atenuaci?n de conexi?n
Transfer loss
Att?nuation de connexion TV < 1 dB? < 1 dB? SAT < 1,5 dB? < 1,5 dB? Desacoplo C1-C2 C1-C2 Isolation D?couplage C1-C2 TV > 25 dB? > 25 dB?
SAT > 25 dB? > 25 dB?
Selectividad
Selectivity
S?lectivit? TV > 15 dB? > 20 dB?
SAT ? ?
P?rdidas de retorno
Return losses
Pertes de retour TV > 10 dB? > 10 dB?
SAT > 6 dB? > 6 dB?
Paso de corriente C2
DC transit C2
Passage de courant C2 VDC 24
mA? 500
Tono/Tone/Ton 22 kHz / DiSEqC
Garras de fijaci?n
Fixing hooks
Griffes de fixation S?
Yes
OuiMANUAL/DATASHEET
-
Add to cartIKUSI ARTU 081. OUTLETS ARTU SERIES
Features
Filtered outlet sockets for individual or cascade assembly.
Fast clamping of the cable thanks to the swivel flange.
Easy connection using the system to insert live product.
Minimum current losses.
Current flow through the C2 connector, SAT output.
Compatible with the main wall-covering plates on the market.
Technical specifications
Modelo
Model
Mod?le ARTU008 ARTU081
Ref. 2574 2576
Instalaci?n
Installation
Installation Final
End
Final
Tipo
Type
Type Puenteada
Bridget
Pont? Resistiva
Resistive
R?sistanc
Conector
Connector
Connecteu C1 IEC macho
IEC male
IEC m?le
C2 IEC hembra
IEC female
IEC f?melle
Rango de frecuencias
Frequency range
Bande passante C1 5 – 862 MHz 5 – 1000 MHz
C2
Atenuaci?n de conexi?n
Transfer loss
Att?nuation de connexion TV < 1,5 dB? < 3 dB? RD < 1,5 dB? < 10 dB? Desacoplo C1-C2 C1-C2 Isolation D?couplage C1-C2 TV - < 15 dB? RD - < 15 dB? P?rdidas de retorno Return losses Pertes de retour TV - < 10 dB? RD Garras de fijaci?n Fixing hooks Griffes de fixation S? Yes Oui MANUAL/DATASHEET -
Add to cartIKUSI ARTU 983. OUTLETS ARTU SERIES
Features
Filtered outlet sockets for individual or cascade assembly.
Fast clamping of the cable thanks to the swivel flange.
Easy connection using the system to insert live product.
Minimum current losses.
Current flow through the C2 connector, SAT output.
Compatible with the main wall-covering plates on the market.
Technical specifications
Modelo
Model
Mod?le ARTU980 ARTU981 ARTU982 ARTU983
Ref. 2578 2579 2580 2575
Instalaci?n
Installation
Installation Final
End
Finale Intermedia
Intermediate
interm?diaire Intermedia
Intermediate
interm?diaire Intermedia
Intermediate
interm?diaire
Tipo
Type
Type Inductiva
Inductive
Inductive
Conector
Connector
Connecteu C1 IEC macho
IEC male
IEC m?le
C2 IEC hembra
IEC female
IEC f?melle
Rango de frecuencias
Frequency range
Bande passante C1 5 – 862 / 950 – 2400 MHz
C2
Atenuaci?n de conexi?n
Transfer loss
Att?nuation de connexion TV + RD < 4,5 dB? < 9 dB? < 13 dB? < 20 dB? SAT < 6 dB? < 10 dB? < 14 dB? < 24 dB? Atenuaci?n de paso Through loss Att?nuation de passage TV + RD - < 2 dB? < 1,2 dB? < 0,5 dB? SAT - < 3 dB? < 2 dB? < 1,2 dB? Desacoplo C1-C2 C1-C2 Isolation D?couplage C1-C2 TV + RD > 16 dB? > 25 dB? > 25 dB? > 25 dB?
SAT > 16 dB? > 25 dB? > 25 dB? > 25 dB?
P?rdidas de retorno
Return losses
Pertes de retour TV + RD > 10 dB? > 10 dB? > 10 dB? > 10 dB?
SAT > 6 dB? > 6 dB? > 6 dB? > 6 dB?
Paso de corriente C2
DC transit C2
Passage de courant C2 VDC 24 24
mA? 500 500
Tono/Tone/Ton 22 kHz / DiSEqC 22 kHz / DiSEqC
Garras de fijaci?n
Fixing hooks
Griffes de fixation S?
Yes
Oui S?
Yes
OuiMANUAL/DATASHEET
-
Add to cartSeparator terminal connector with two CEI connectors. The one on the left is a male CEI for FM (radio) and terrestrial TV and the one on the right is a female CEI for satellite TV (FI). TV/FM-SAT. 0.6 – 1.5dB + DC without claws. Televes 5276
