Name: Multimedia terminal socket 5-1006MHz FM-TV-DATA 8-7-3.6dB... | +254720548999
SKU: TELEVES-524001
Price: 4264.00 KES
Availability: InStock

Terminal socket with three FM-TV-DATA connectors. In the lower left part a male CEI for terrestrial TV, in the lower right a female CEI for FM (radio) and in the upper center an F connector for multimedia data.
Specially designed for operators, it is compatible with DOCSIS 3.1.

Stands out for
Automated robotized online manufacturing
High shielding
Great isolation between departures
Features
Made in Zamak, high resistance
Compatible with coaxial cables with cover diameter ? 5 … 7mm
?
Tomas Televes: Fixation without screw

A class A shot full of advantages:

The live connects by simple push, you do not have to tighten any screw, but with an equivalent clamping force
Supports living diameters between 0.65 to 1.2mm and outer diameters of the cable from 5 to 6.9mm
Conical guide, connector type “F” to introduce the live easily
Wide margin in the length of the live (5 to 15mm) that makes the short between live and mesh difficult
Tilting and self-supporting full-opening clamp
The clamp consists of 3 rows serrated in 9mm for a perfect fastening of the mesh
Perforation of the printed circuit to make compatible the fixation screw of the trims
Rounded edges to avoid cuts
Class A shielding

In addition, this product range has several engravings on the chassis:

CE Marking
Numerical and logical reference
Indications of inputs and outputs
Dimensions of cable peeling
Specifications
Type TF
Band TV?
(111-1218MHz) DATA
(5-1218MHz) FM (Radio)
(87-1218MHz)
Connector “CEI” Male “F” Female “CEI” Female
Anchorage method Without screws
Rejection between departures dB DATA – TV ?> 70 (5-65 MHz) /> 30 (65-1218 MHz)
Output of passage Do not
Insertion losses dB – – –
Attenuations Output: TV dB 8 – –
Output: DATA – 3.6 –
Output: R – – 7
DC Step (24V – 350mA) SAT ??Input
