Plastic coil 100m coaxial cable SK2000plus White Televes
KSh35,090.00
Coaxial cable SK2000 plus (T100A ++) with live and mesh made of copper (Cu / Cu) with excellent braiding coverage (82%). It is triple shielded (TSH) so it has a second extra sheet of extra armor. An 18VAtC cable, PVC cover. Euroclass Eca and A ++ class shield. White. 100m plastic coil. Televes 4138
Coaxial cable with live and mesh made of copper (Cu / Cu) with excellent braiding coverage (82%). It is triple shielded (TSH) so it has a second extra sheet of extra armor. An 18VAtC cable, PVC cover.
Stands out for
Conductors made of copper
Class A shielding
Euroclass Eca
Features
Outer PVC cover in white
Characteristic impedance of 75 ohm
100m plastic coil
Coaxial cable trishield (TSH) Class A ++
With 3 layers of shielding (trishield), these cables are those that provide greater immunity to interference, as they have a very high screening. Its use is recommended in routes with high levels of electromagnetic noise.
Their constructive properties make them Class A ++, complying with EN 50117:
At 5 – 30 MHz => TI <0.9 m? / m
At 30 - 1000 MHz => SA> 105 dB
At 1000 – 2000 MHz => SA> 95 dB
At 2000 – 3000 MHz => SA> 85 dB
Where, the transfer impedance (TI) defines the effectiveness of the shielding at low frequencies, and the shielding attenuation (SA) defines it between 30 and 3000MHz.
Specifications
?Reference 4138
INNER CONDUCTOR – BRAID COMPOSITION COPPER – CuSn (copper-clad steel)
?Televes Model SK2000 PLUS
?Inner conductor ? mm 1.02
material – Cooper
resistance ?/Km 22
?Dielectric ? mm 4.6
material – Foam Polyethylene
?Overlapping shielding foil composition Aluminium+Polyester
?Braid resistance ?/Km < 11
material - CuSn (copper-clad steel)
?2? Overlapping shielding foil composition Aluminium+Polyester
?Antimigrating film No
?Petrol jelly No
?Outer sheath ? mm 6.7
color - White
material - PVC
?Minimum bending radius mm 33
?Screening efficiency dB >105 (30-1000MHz)
>95 (1-2GHz)
>85 (2-3GHz)
?Capacitance pF/m 55
?Environmental use Indoor
?Packaging meters/reel m 100
?
Frequency
Attenuation (MHz) 200 dB/m 0.08
500 0.14
800 0.18
1000 0.21
1350
0.24
1750 0.28
2050 0.30
2300 0.32
