Power supply 12V dc / 100 mA, 1 In / 2 Out, Connector F….
KSh2,804.00
IFP 102 Power supply with LTE filter. The Triax IFP 102 are indoor Power Supplies for Masthead amplifiers also providing a ?last defence? filter function against local LTE/4G interference.
Features
Easy installation, plugs into any EU VDE Mains wall outlet.
F-connectors for maximum shielding.
Green LED indication of Mains power.
White indoor housing. LTE filter 6-23 dB, (790-821MHz).
High current load possible, 12 VDC, 100mA. For Mains Power, 230 VAC, 50/60 Hz.
Specifications
ORDER INFORMATION
EAN Number 5702663701090
FREQUENCY
Frequency range 5-790 MHz
LOSS
Rejection @ 821 MHz (LTE D6) >23.0 dB
Through loss 6.0 dB
ELECTRICAL
Impedance 75 ?
OPERATIONAL
AC Supply voltage 230 VAC
PSU output DC voltage 12 VDC
PSU output max. DC current 100 mA
CONNECTORS
Connector Type F-female
Number of outputs 2
MECHANICAL
Product Depth 40 mm
Packaging Depth 0,203 m
Packaging Height 0,050 m
Total Weight 0,350 kg
Packaging Width 0,092 m
Net Weight 0,304 kg
Tara Weight 0,046 kg
Packaging Volume 0,001 m3
Product Width 140 mm
Product Height 70 mm
?
