Recessed tilting base Galvanized hot turret series 450 Televes
KSh129,978.00
Flush-mounted flush-mounted base, hot-dip galvanized, for anchoring a braced tower of the 450 series. It is possible to avoid concrete if it is installed screwed onto a surface plate (ref 312901). Televes 313401
Pivoting embedded base for the anchoring of a 450 range guy-wired braced tower.?Hot-dip galvanised
Concrete might not be necessary if bolted on a surface plate (ref. 312901).
Specifications
Reference 313401
?Description Flush-mounted flush-mounted base, hot-dip galvanized, tower 450
?Material (1) Steel F626 (S 235), 15 mm thickness plate
Re min. 235 N/mm2 – Rn min. 340 N/mm2
(2) Hardened and tempered steel.
?Weight 15.4 Kg
