Televes Indoor LSFH Singlemode (SM) SC/APC Fiber Optic Patch Cord 1m
1m FO hose with SC/APC connectors
Televes 232626 fiber optic patch cord 232626 is a single mode (SM) preconnectorized patch cord with SC/APC connectors for interconnecting optical equipment. It has a length of 1metro.?
This patch cord can be used for different uses: for single-mode fiber installations, either from an operator, or in an ICT fiber infrastructure, it can be used in data networks in a company or a building, but we can also use it in a fiber CCTV installation.The jacket is halogen-free (LSFH) and is recommended for use in indoors. The hose is of type ITU-T G.657.A2..
Supplied in individual bag with hanger.
Technical Specifications of 1m FO Hose with SC/APC Connectors
Fiber type
?
Single-mode (ITU-T-G.657A2)
Fiber type category
?
OS1
Fiber core diameter
?m
?
Fiber cladding diameter
?m
?
Fiber coating diameter
?m
?
Cable structure
?
Adjusted
Diameter Outer jacket
mm
?
Material Outer jacket
?
LSFH
Attenuation 1310nm
dB/km
< 0.4 Attenuation 1490nm dB/km < 0.4 Attenuation 1550nm dB/km < 0.3 Insertion losses in connector 1 dB < 0.5 Insertion losses in connector 2 dB < 0.5 Return loss at connector 1 dB > 60
Return loss on connector 2
dB
> 60
Optical connector type 1
?
SC
Polishing type (Optical connector 1)
?
APC
Optical connector type 2
?
SC
Polishing type (Optical connector 2)
?
APC
Minimum bending radius
mm
?
Operating temperature
?C
-20 … 70
