TELEVES Nevoswitch 5x5x8 dSCR
TELEVES
Nevoswitch 5x5x8 dSCR
Cascade 5 In 8 Out dSCR or Legacy c/w DC
(Earth Bars Not Included) 2 Year Warranty
*Special Order! NCNR – Check Lead Time*
(May require PSU: 732802)
Related products
-
Read moreTELEVES Nevoswitch 5x5x6 CASCADE 5 In 6 Out c/w Output Earth Bar Only 2 Year
Warranty (May require a PSU: 12V1.5A PSU 732210) *Special Order! NCNR – Check
Lead Time* Cascadable multiswitch
equipped with 5 inputs (one terrestrial, and the four polarities of one
satellite), 6 user outputs, and a 12 dB potentiometer per user output. Can be
used as a terminal (star topology) or as a cascade by using a simple switch. Main Features: One potentiometer (12 dB) on each of the
user outputs to optimize the level on an individual basis A switch for either
powering terrestrial pre-amplifiers or allowing current circulation Can be
powered directly from the satellite receiver, without the need for a power
supply unit* Remote power feeding using VL Current circulation between all
inputs and cascades Active terrestrial European design, quality, and manufacturing
Very compact Made of zamak Input and output colour identification Available
ECO mode Selector switch to shift between cascade and terminal modes 12v
power supply Low power consumption -
Read moreTELEVES 13×24 CASCADE-TERMINATED 13 In 24 Out c/w Output Earth Bar Only 2
Year Warranty *Special Order! NCNR – Check Lead Time* This unit can be used as a cascade element
since it has 13 outputs to connect to other switches and increase the number
of users. This range of products has been designed with the ECO system: as
the number of users decreases, the power consumption of the system will
decrease as well. Gain in the FI band can be selected individually for each
group of 8 users to provide a balanced output. -
Read moreTELEVES Euroswitch 9x9x12 CASCADE 9 In 12 Out c/w Output Earth Bar Only 2
Year Warranty *Special Order! NCNR – Check Lead Time* Compact multiswitch equipped with 9 inputs
(one terrestrial and 8 for two satellites, each with its four polarities) and
12 user outputs. Thanks to its great
compactness and its optimized electronic design, it presents very low through
and tap losses. This allows to reduce the number of amplifiers needed in the
cascade and to obtain a better balanced signal in the users, even in large
collective installations. Can be used
as a terminal (star topology) or as a cascade by using a simple switch. In
addition, it incorporates a second switch that actives the TForce technology,
which automatically adjusts the terrestrial signal and keep it constant
despite variations in the reception. RED compliant Main Features: High shielding (A class) thanks to its
manufacture in Zamak Versatile: selector switch to shift between cascade and
terminal modes Low consumption under normal conditions. In addition, ECO mode
reduces consumption as the number of connected users decreases Wide 12-18V
power supply range, making it compatible with most existing systems Current
circulation between all inputs and cascades Input and output colour identification -
Read moreTELEVES Nevoswitch 9×9 CASCADE Launch
Amp 21dB SAT 17dB Terr – 2 Year
Warranty *Special Order! NCNR – Check Lead Time* NevoSwitch amplifier equipped with 9 inputs
(one terrestrial and the four polarities of two satellites) that allows
increasing the number of users in the installation while optimizing the
signal received by each of them. Around 27dB and 31dB amplification in
terrestrial and satellite respectively. Compatible with the return path
(passive). Main Features: High output level Switch for the selection
of whether or not to power the terrestrial pre-amplifiers (VDC or OFF) Gain
(20 dB) and slope (12 dB) individual adjustment Power feeding through the VL
input/output Very compact Made of zamak Input and output colour
identification 12 V power supply Low power consumption -
Read moreTELEVES Nevoswitch 15dB Tap 5 In – 5 Trunk + 5 Tap Out 2 Year Warranty
*Special Order! NCNR – Check Lead Time*
CONFIGURABLE ELEMENTS FOR BETTER SIGNAL ADJUSTMENT Highlights: Chassis
made of zamak: radiation inmune. Suitable for star/cascade system
configurations. Independent Output Level adjustment (except QUAD compatible
units). Low consumption ECO mode. Thanks to the ECO system, the consumption
decreases as the number of users is reduced. Main Features: Small size and
compact design. Cascadable and terminal configuration in a single reference.
Independent line-amplifier level adjustment. Multiple powering options (Jack,
VLow, Terrestrial Input/Output and user outputs) Independent output level
adjustment.
