Tiandy 2MP Motorized IR Bullet Camera
Product
Description
Camera
Image Sensor
1/2.8″CMOS
Min. Illumination
Color:0.0004Lux@(F1.3,AGC ON),B/W:0Lux with IR
Shutter Time
1s~1/100000s
Day&Night
IR-cut filter with auto Switch (ICR)
Smart IR
Yes
WDR
120dB
S/N
>42dB
Angle Adjustment
0~360°(P); 0~90°(T); 0~360°(R)
Lens
Lens Type
Motorized
Focal Length
2.7~13.5mm
Lens Mount
?14
Aperture Range
F1.3
Aperture Type
Auto(DC-Iris)
Field of View
103.5°~36.4°(H); 58.1°~20.5°(V); 118.7°~41.8°(D)
DORI Distance
Detect:38.5m~165.5m Observe:15m~65.5m Recognize:7.5m~33m
Identify:3.5m~16.5m
Illuminator
IR LEDs
4
IR Distance
Up to 80m
Wavelength
850nm
Compression Standard
Video Compression
S+265/H.265/H.264B/H.264M/H.264H/Motion JPEG
Video Bit Rate
32k~8Mbps
Audio Compression
G.711A/G.711U/ADPCM_D/AAC_LC
Audio Sampling Rate
8kHz/32kHz/48kHz
Max. Resolution
2MP,1920×1080@30fps
Main Stream
PAL:25fps(1920×1080, 1280×720, 640×480, 704×576) NTSC:30fps(1920×1080,
1280×720, 640×480, 704×480)
Sub Stream
PAL:25fps(704×576, 704×288, 640×360, 352×288) NTSC:30fps(704×480, 704×240,
640×360, 352×240)
Third Stream
PAL:25fps(704×576, 704×288, 352×288) NTSC:30fps(704×480, 704×240,
352×240)
BLC
Yes
HLC
Yes
AGC
Yes
3D DNR
Yes
White Balance
Auto/Semi-Auto/Manual/Sunshine/Nature Light/Warmlight Lamp/Daylight
Lamp/Filament Lamp/Lock White Balance
ROI
8 rectangular static areas
Corridor Mode
Yes
OSD
Overlay of additional characters in 5 regions, 1 line, with a maximum of
127 characters or 42 Chinese characters per region;
16*16/32*32/48*48/64*64
Picture Overlay
1*200×200 size BMP 16 color bit image overlay
Privacy Mask
4 black static areas
Defog
Yes
Feature
General Alarm
Motion Detection; Mask Alarm; Alarm Input
Exceptions Alarm
Voltage Alarm; Disk Full; Disk R/W Error; IP Address Conflict; MAC Address
Conflict; FTP Server Exception
Linkage Method
Send Email; Trigger Sound; Trigger Recording; Trigger Capture; Notify
Surveillance Center; Alarm Output
Video Analytics
Human/Vehicle Classification; Tripwire; Double Tripwire; Perimeter; Object
Abandon; Object Missing; Heatmap; Loitering; Running; Parking; People
Counting; Crowed Detection; Safety Helmet Detection; On Duty Detection; Video
Abnormal; Audio Abnormal
Rules of Behavior Analyse In 1 Scene
8
Face Mode
Face Capture
Face Detection Performance
Detect up to 16 faces at the same scene; Capture up to 8 faces at the same
scene
Network
ANR
Yes
Protocols
HTTP; HTTPS; TCP/IP; UDP; UPnP; ICMP; IGMP; SNMP v1v2v3; DHCP; DNS; DDNS;
Easy DDNS; NTP; SMTP; TLS v1.2; SSL; 802.1X; QoS; IPv4; IPv6; PPPoE; SSH;
Unicast; Multicast; RTCP; ARP; SRTP; FTP; SFTP
System Compatibility
ONVIF(Profile S/T/G/M) ; SDK; CGI; Milestone; RTSP; RTMP
Remote Connection
?7
Client
Easy7 VMS
Moblie Client
EasyLive Plus
Web
IE10+; Firefox52+; Edge89+; Safari11+; Chrome57+
Interface
Communication Interface
1*RJ-45 (10/100 Base-T)
Audio I/O
1; 1
Alarm I/O
2-ch,TTL inputs,3mA,3.3VDC; 1-ch,relay output,1A,24VDC
Built-in Mic
Yes
Reset Button
Yes
On-board Storage
Support microSD/microSDHC/microSDXC card,up to 512GB
RTC
Yes
Additional Interfaces
RS-485
General
Web Client Language
19 languages Simple Chinese/Traditional Chinese/English/Spanish/Korean/Italian/Turkish/Russian/Thai/French/Polish/Dutch/Hebrew/Arabic/Vietnamese/German/Ukrainian/Portuguese/Albanian
Operating Temperature
-40?~65?(-40?~149?)
Operating Humidity
?95%RH
Storage Temperature
-40?~65?(-40?~149?)
Storage Humidity
10%~95%RH(non-condensing)
Power Supply
DC12V±25%,Max. 9W; PoE:IEEE 802.3af,Max. 10W
Protection
Surge4000V; ESD6000V; IP67
Boundary Dimensions
264(L)106(W)106(H)mm
Package Dimensions
360(L)150(W)170(H)mm
GrossWeight
1.6kg
