Triax TMS 27 LTE 700 Satellite amplifier + LTE terrestrial…
KSh15,058.00
1 RF input (47 … 694 MHz) RF gain -3dB
1 input SAT FI Gain SAT-FI 42dB
118 dB?V output level.
Power for LNB 13/18 Vdc and 0/22 kHz
Related products
-
Central line amplifier DTKom Televes
KSh71,132.00Add to cartMATV central line applications.
Separate amplification, which facilitate high output voltages and minimizes intermodulation bands.
-
Add to cartConfigurable headend amplifier for SMATV systems with separate amplification that guarantees the absence of intermodulation between inputs. It consists of 4 inputs: FM-VHF-UHF-FI, the VHF and UHF ones have two selectable gain margins while the FM input has a single amplifier stage.
-
DTKom broadband multiband amplifier 5 inputs:…
KSh79,264.00Add to cartHigh-power multiband amplifier with multiple controls on the front end, which design uses components that minimize the total noise figure. Equipped with 5 inputs (FM-BIII-21…36-38…48-UHF). The UHF band is divided in 2 of the inputs, which is useful in two-repeater reception installations since it allows an appropriate filtering of the channels for each of them.
Equipped with LTE700 filtering.
RED compliant
Highlights
Separate amplification minimizes intermodulation between bands and provides high output levels
Designed using Push-Pull technology, which guarantees levels in the 123 dB?V range for terrestrial signals.
Includes a high-performance low-power consumption switch-mode power supply
High-screening Zamak chassis The design facilitates appropriate cooling
Features
Switch for pre-amplifier or BOSS system powering
Switched configurable gain (high/low), and high output level
Intuitive front cover, including adjustments and block diagram
Output signal LED indicator
Specifications
Bands UHF BV BIV BIII FM
Frequency margin MHz 470 … 694 606 … 694
(Ch38…48) 470 … 598
(Ch21…36) 174 … 370 88 … 108
Gain 0 dB 42 41(1) 41(2) 42 25
10 32 31(1) 31(2) 32 25
Gain margin (Manual)
0 … 20 (Manual)
0 … 20 (Manual)
0 … 20 (Manual)
0 … 20 (Manual)
0 … 20
Max. output level IMD3 (2 tones,-35 dB) dB?V
(dBmV) 125 (65)
DIN 45004B 123 (63)
IMD3 (2 tones,-60 dB) 120 (60)
IMD2 (2 tones,-60 dB) – – – 122 (62) –
Noise figure dB 10 10 10 5 6
Test -20
Powering inputs V= 12
Max. curent inputs mA 50
Mains voltage /frequency V~ / Hz 120 … 230 / 50-60
Total AC consumption OFF W / mA 5,8 / 120
ON W / mA 9,6 / 180
Protection level IP 20
Operating temperature range ?C (?F) -5 … +45 (23 … 113)(1) G(Ch38)=37/27dB
(2) G(Ch36)=38/28dB
-
Add to cartCompact WideBand amplifier for 1-satellite Overlight installations. It is responsible for compensating the losses of the coaxial cable in the installation. This amplifier can be powered from the Overlight transmitter or from an external power supply. Maximum gain up to 29 dB. It is equipped with 2 (H/V) WideBand inputs and 2 (H/V) WideBand outputs (250-2400 MHz). Indoor use.
-
DTKom broadband multiband amplifier 5 inputs:…
KSh79,264.00Add to cartHigh-power multiband amplifier with multiple controls on the front end, which design uses components that minimize the total noise figure. Equipped with 5 inputs (FM-BIII-21…32-36…48-UHF). The UHF band is divided in 2 of the inputs, which is useful in two-repeater reception installations since it allows an appropriate filtering of the channels for each of them.
Equipped with LTE700 filtering.
RED compliant
Highlights
Separate amplification minimizes intermodulation between bands and provides high output levels
Designed using Push-Pull technology, which guarantees levels in the 123 dB?V range for terrestrial signals.
Includes a high-performance low-power consumption switch-mode power supply
High-screening Zamak chassis The design facilitates appropriate cooling
Features
Switch for pre-amplifier or BOSS system powering
Switched configurable gain (high/low), and high output level
Intuitive front cover, including adjustments and block diagram
Output signal LED indicator
Specifications
Bands UHF BV BIV BIII FM
Frequency margin MHz 470 … 694 590… 694
(Ch36…48) 470 … 566
(Ch21…32) 174 … 370 88 … 108
Gain 0 dB 42 41(1) 41(2) 42 25
10 32 31(1) 31(2) 32 25
Gain margin (Manual)
0 … 20 (Manual)
0 … 20 (Manual)
0 … 20 (Manual)
0 … 20 (Manual)
0 … 20
Max. output level IMD3 (2 tones,-35 dB) dB?V
(dBmV) 125 (65)
DIN 45004B 123 (63)
IMD3 (2 tones,-60 dB) 120 (60)
IMD2 (2 tones,-60 dB) – – – 122 (62) –
Noise figure dB 10 10 10 5 6
Test -20
Powering inputs V= 12
Max. curent inputs mA 50
Mains voltage /frequency V~ / Hz 120 … 230 / 50-60
Total AC consumption OFF W / mA 5,8 / 120
ON W / mA 9,6 / 180
Protection level IP 20
Operating temperature range ?C (?F) -5 … +45 (23 … 113)
