Showing 81–160 of 510 results
-
Add to cartDahua 4 Channel Smart 4PoE 4K&H.265 Lite NVR, DHI-NVR4104-P-zz
System
Main Processor
Industrial embedded micro-processor
Operating System
Embedded Linux
Operation Interface
Web; local GUI
Perimeter Protection by Camera
Performance
4/8 channels
AI Search
Search for pictures by channel, time and event type
SMD Plus by Camera
Performance
4/8 channels
AI Search
Search by target classification (human, vehicle)
Video
Access Channel
4/8
Network Bandwidth
80 Mbps for access, 80 Mbps for storage and 48 Mbps for forwarding
Resolution
8MP, 6MP, 5MP, 4MP, 3MP, 1080p, 1.3MP, 720p, D1, and more
Decoding Capability
8 channels@1080p (30 fps)
Video Output
HDMI: 3840 × 2160; 1920 × 1080; 1280 × 1024; 1280 × 720
VGA: 1920 × 1080; 1280 × 1024; 1280 × 720Multi-screen Display
4-channel: 1/4
8-channel: 1/4/8/9Third Party Camera Access
Panasonic, Sony, Samsung, Axis, Pelco, Arecont, ONVIF, Canon and more
Compression
Video
Smart H.265+; Smart H.264+; H.265; H.264
Audio
PCM; G.711A; G.711U; G.726
Network
Network Protocol
HTTP; HTTPS; TCP/IP; IPv4/IPv6; UPnP; SNMP; RTSP; UDP; SMTP; NTP; DHCP; DNS; IP Filter; DDNS; FTP; Alarm Server; IP Search (supports Dahua IP camera, DVR, NVS, and more); P2P
Mobile Phone Access
Android; iOS
Interoperability
ONVIF (profile T/S/G); CGI; SDK
Browser
Chrome; IE9 or later; Firefox
Record Playback
Multi-channel Playback
4-channel: 1/4
8-channel: 1/4/9Record Mode
Manual; schedule (general; MD; alarm; MD & alarm; intelligent)
Storage Method
Local HDD and network
Backup
USB device
Playback Function
1. Play; pause; stop; fast forward; fast backward; rewind; play by frame
2. Full screen; backup (cut/file) ; partially enlarge; audio on/offStorage
Disk Group
Yes
Alarm
General Alarm
Motion detection; privacy masking; video loss; PIR alarm; IPC alarm
Anomaly Alarm
Camera offline; storage error; full storage; IP conflict; MAC conflict; login lock; network security anomaly
Intelligent Alarm
Perimeter protection; SMD; people counting; heat map
Alarm Linkage
Record; snapshot; IPC external alarm output; buzzer; log; preset; email
External Port
Audio Input
1 channel, RCA connector
Audio Output
1 channel, RCA connector, which support voice intercom output
HDD
1 SATA III port, up to 10 TB for a single HDD. The maximum HDD capacity varies with environment temperature
USB
1 front USB 2.0 port, 1 rear USB 3.0 port
HDMI
1
VGA
1
Network
1 independent 100 Mbps ethernet port
PoE
4 ports (IEEE802.3at/af)
General Parameter
Power Supply
48V/1.5A DC
Power Consumption
NVR: < 7.5W (without HDD) PoE: Max 25.5W for single port, 48W in total Net Weight 0.8 kg (1.76 lb) (without HDD) Gross Weight 1.6 kg (3.53 lb) (without HDD) Product Dimensions 260.0 mm × 232.5 mm × 47.6 mm (10.2** × 9.2** × 1.9**) Package Dimensions 331 mm × 312 mm × 87 mm (13.0** × 12.3** × 3.4**) Operating Temperature -10°C to +55°C (+14°F to +131°F) Storage Temperature 0°C to +40°C (+32°F to +104°F) Operating Humidity 10%–93% (RH) Storage Humidity 30%–85% (RH) Operating Altitude 3,000 m (9,843 ft) Certifications CE: EN55032; EN55024; EN50130-4; EN60950-1 FCC: Part 15 Subpart B; ANSI C63.4-2014 UL: UL 60950-
-
Add to cartDahua 4 MP IP-camera, Dahua DH-IPC-HFW2431TP-AS-S2 (3.6 mm)
Camera
Image Sensor
1/3” 4Megapixel progressive CMOS
Max. Resolution
2688 (H) × 1520 (V)
ROM
128 MB
RAM
128 MB
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual 1/3 s–1/100,000 s
Min. Illumination
0.008 Lux@F1.6
S/N Ratio
> 56 dB
Illumination Distance
80 m (262.5 ft)
Illuminator On/Off Control
Auto/Manual
Illuminator Number
4 (IR LED)
Pan/Tilt/Rotation Range
Pan: 0°–360°
Tilt: 0°–90°
Rotation: 0°–360°
Lens
Lens Type
Fixed-focal
Mount Type
M12
Focal Length
3.6 mm; 6 mm; 8 mm
Max. Aperture
3.6 mm: F1.6
6 mm: F1.6
8 mm: F1.6
Field of View
3.6 mm: Horizontal 84° × Vertical 45° × Diagonal 100°
6 mm: Horizontal 52° × Vertical 28° × Diagonal 61°
8 mm: Horizontal 40° × Vertical 23° × Diagonal 45°
Iris Type
Fixed
Close Focus Distance
3.6 mm: 1.4 m (4.6 ft)
6 mm: 3.1 m (10.2 ft)
8 mm:4.9 m(16.1 ft)
DORI Distance
Lens
Detect
Observe
Recognize
Identify
3.6 mm
80 m
(262.5 ft)32.0 m
(105.0 ft)16.0 m
(52.5 ft)8.0 m
(26.2 ft)6 mm
120.0 m
(393.7 ft)48.0 m
(157.5 ft)24.0 m
(78.7 ft)12.0 m
(39.4 ft)8 mm
160.0 m
(524.9 ft)64.0 m
(210.0 ft)32.0 m
(105.0 ft)16.0m
(52.5 ft)Smart Event
IVS
Tripwire; intrusion
Video
Video Compression
H.265; H.264; H.264B; MJPEG(only supported
by the sub stream)
Smart Codec
Smart H.265+/ Smart H.264+
Video Frame Rate
Main stream:
2688 × 1520 (1 fps–20 fps)
2560 × 1440 (1 fps–25/30 fps)
Sub stream:
704 × 576 (1 fps–25 fps)
704 × 480 (1 fps–30 fps)
Stream Capability
2 streams
Resolution
2688 × 1520 (2688 × 1520); 2560 × 1440 (2560 × 1440); 3M (2048 × 1536); 2304 × 1296 (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
Bit Rate Control
CBR/VBR
Video Bit Rate
H.264: 32 kbps–6144 kbps
H.265: 12 kbps–6144 kbps
Day/Night
Auto(ICR)/Color/B/W
BLC
Yes
HLC
Yes
WDR
120 dB
White Balance
Auto/natural/street lamp/outdoor/manual/regional custom
Gain Control
Auto/Manual
Noise Reduction
3D NR
Motion Detection
OFF/ON (4 areas, rectangular)
Region of Interest (RoI)
Yes (4 areas)
Smart Illumination
Yes
Image Rotation
0°/90°/180°/270° (Supports 90°/270° with 2688 × 1520 resolution and lower)
Mirror
Yes
Privacy Masking
4 areas
Audio
Audio Compression
G.711a; G.711Mu; G.726
Alarm
Alarm Event
No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; audio detection; voltage detection; security exception; local alarm
Network
Network
RJ-45 (10/100 Base-T)
SDK and API
Yes
Cyber Security
Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade
Protocol
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; Bonjour
Interoperability
ONVIF (Profile S/Profile G/Profile T); CGI; Milestone; Genetec; P2P
User/Host
20
Storage
FTP; SFTP; Micro SD Card (support max. 256 GB); NAS
Browser
IE
Chrome
FirefoxManagement Software
Smart PSS; DSS; DMSS
Mobile Phone
IOS; Android
Certification
Certifications
CE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07Port
Audio Input
1 channel (RCA port)
Audio Output
1 channel (RCA port)
Alarm Input
1 channel in: 5mA 3V–5V DC
Alarm Output
1 channel out: 300mA 12V DC
Power
Power Supply
12V DC/PoE (802.3af)
Power Consumption
< 7.7W Environment Operating Conditions –40°C to +60°C (–40°F to +140°F)/less than ** 95% RH Storage Temperature –40°C to +60°C (–40°F to +140°F) Protection Grade IP67; IK10(optional) Structure Casing Metal Dimensions 244.1 mm × **90.4 mm (9.61** × **3.26**) Net Weight 0.91 kg (2.0 lb) Gross Weight 1.16 kg (2.6 lb)
-
Add to cart
Dahua 4 MP IP-camera, Dahua DH-IPC-HFW2431TP-AS-S2 (3.6 mm)
Camera
Image Sensor
1/3” 4Megapixel progressive CMOS
Max. Resolution
2688 (H) × 1520 (V)
ROM
128 MB
RAM
128 MB
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual 1/3 s–1/100,000 s
Min. Illumination
0.008 Lux@F1.6
S/N Ratio
> 56 dB
Illumination Distance
80 m (262.5 ft)
Illuminator On/Off Control
Auto/Manual
Illuminator Number
4 (IR LED)
Pan/Tilt/Rotation Range
Pan: 0°–360°
Tilt: 0°–90°
Rotation: 0°–360°
Lens
Lens Type
Fixed-focal
Mount Type
M12
Focal Length
3.6 mm; 6 mm; 8 mm
Max. Aperture
3.6 mm: F1.6
6 mm: F1.6
8 mm: F1.6
Field of View
3.6 mm: Horizontal 84° × Vertical 45° × Diagonal 100°
6 mm: Horizontal 52° × Vertical 28° × Diagonal 61°
8 mm: Horizontal 40° × Vertical 23° × Diagonal 45°
Iris Type
Fixed
Close Focus Distance
3.6 mm: 1.4 m (4.6 ft)
6 mm: 3.1 m (10.2 ft)
8 mm:4.9 m(16.1 ft)
DORI Distance
Lens
Detect
Observe
Recognize
Identify
3.6 mm
80 m
(262.5 ft)32.0 m
(105.0 ft)16.0 m
(52.5 ft)8.0 m
(26.2 ft)6 mm
120.0 m
(393.7 ft)48.0 m
(157.5 ft)24.0 m
(78.7 ft)12.0 m
(39.4 ft)8 mm
160.0 m
(524.9 ft)64.0 m
(210.0 ft)32.0 m
(105.0 ft)16.0m
(52.5 ft)Smart Event
IVS
Tripwire; intrusion
Video
Video Compression
H.265; H.264; H.264B; MJPEG(only supported
by the sub stream)
Smart Codec
Smart H.265+/ Smart H.264+
Video Frame Rate
Main stream:
2688 × 1520 (1 fps–20 fps)
2560 × 1440 (1 fps–25/30 fps)
Sub stream:
704 × 576 (1 fps–25 fps)
704 × 480 (1 fps–30 fps)
Stream Capability
2 streams
Resolution
2688 × 1520 (2688 × 1520); 2560 × 1440 (2560 × 1440); 3M (2048 × 1536); 2304 × 1296 (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
Bit Rate Control
CBR/VBR
Video Bit Rate
H.264: 32 kbps–6144 kbps
H.265: 12 kbps–6144 kbps
Day/Night
Auto(ICR)/Color/B/W
BLC
Yes
HLC
Yes
WDR
120 dB
White Balance
Auto/natural/street lamp/outdoor/manual/regional custom
Gain Control
Auto/Manual
Noise Reduction
3D NR
Motion Detection
OFF/ON (4 areas, rectangular)
Region of Interest (RoI)
Yes (4 areas)
Smart Illumination
Yes
Image Rotation
0°/90°/180°/270° (Supports 90°/270° with 2688 × 1520 resolution and lower)
Mirror
Yes
Privacy Masking
4 areas
Audio
Audio Compression
G.711a; G.711Mu; G.726
Alarm
Alarm Event
No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; audio detection; voltage detection; security exception; local alarm
Network
Network
RJ-45 (10/100 Base-T)
SDK and API
Yes
Cyber Security
Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade
Protocol
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; Bonjour
Interoperability
ONVIF (Profile S/Profile G/Profile T); CGI; Milestone; Genetec; P2P
User/Host
20
Storage
FTP; SFTP; Micro SD Card (support max. 256 GB); NAS
Browser
IE
Chrome
FirefoxManagement Software
Smart PSS; DSS; DMSS
Mobile Phone
IOS; Android
Certification
Certifications
CE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07Port
Audio Input
1 channel (RCA port)
Audio Output
1 channel (RCA port)
Alarm Input
1 channel in: 5mA 3V–5V DC
Alarm Output
1 channel out: 300mA 12V DC
Power
Power Supply
12V DC/PoE (802.3af)
Power Consumption
< 7.7W Environment Operating Conditions –40°C to +60°C (–40°F to +140°F)/less than ** 95% RH Storage Temperature –40°C to +60°C (–40°F to +140°F) Protection Grade IP67; IK10(optional) Structure Casing Metal Dimensions 244.1 mm × **90.4 mm (9.61** × **3.26**) Net Weight 0.91 kg (2.0 lb) Gross Weight 1.16 kg (2.6 lb)
-
Add to cartDahua 4-Port PoE Managed Switch, DH-PFS4206-4P-96
Technical Speci**cation
Model
DH-PFS4206-4P-96
Ethernet Port
2*1000 Base-X(SFP)
1*10/100/1000 Base-T(Hi-PoE/PoE+/PoE)
3*10/100 Base-T (PoE+/PoE)
PoE Power Consumption
Port1, 2, 3 **30W
Port4**60W
Total**96W
PoE Protocol
PoE(802.3af), PoE+(802.3at), Hi-PoE
Switching Capacity
6.8Gbps
Packet Forwarding Rate
4.91Mpps
Packet Buffer Memory
1Mb
Application Humidity
10%~90%
Power
DC48~57V
Lightning Protection
Common Mode 4KV
Differential Mode 2KV
Working Temperature
-30°C~65°C
Weight
480g
Dimension(W×D×H)
150mm×100mm×30mm
Service Characteristics
System
Username / password: admin/(empty)
IP Address :192.168.1.110/24
PoE Budget
96W
MAC Table Size
8K
VLAN
802.1Q Standard VLAN
Port Mirroring
Support many-to-one port mirroring
Flow Control
Support half-duplex based on back pressure type control
Support full duplex based on PAUSE frame
Network Management
WEB, SNMP V1/V2C
Ring Network
Support Spanning Tree, STP/RSTP
Support Loop Detection
PoE Management
Support PoE power consumption, PoE on/off of IPC configuration, power down when exceeding the value of overload power
-
Add to cart
Dahua 4-Port PoE Managed Switch, DH-PFS4206-4P-96
Technical Speci**cation
Model
DH-PFS4206-4P-96
Ethernet Port
2*1000 Base-X(SFP)
1*10/100/1000 Base-T(Hi-PoE/PoE+/PoE)
3*10/100 Base-T (PoE+/PoE)
PoE Power Consumption
Port1, 2, 3 **30W
Port4**60W
Total**96W
PoE Protocol
PoE(802.3af), PoE+(802.3at), Hi-PoE
Switching Capacity
6.8Gbps
Packet Forwarding Rate
4.91Mpps
Packet Buffer Memory
1Mb
Application Humidity
10%~90%
Power
DC48~57V
Lightning Protection
Common Mode 4KV
Differential Mode 2KV
Working Temperature
-30°C~65°C
Weight
480g
Dimension(W×D×H)
150mm×100mm×30mm
Service Characteristics
System
Username / password: admin/(empty)
IP Address :192.168.1.110/24
PoE Budget
96W
MAC Table Size
8K
VLAN
802.1Q Standard VLAN
Port Mirroring
Support many-to-one port mirroring
Flow Control
Support half-duplex based on back pressure type control
Support full duplex based on PAUSE frame
Network Management
WEB, SNMP V1/V2C
Ring Network
Support Spanning Tree, STP/RSTP
Support Loop Detection
PoE Management
Support PoE power consumption, PoE on/off of IPC configuration, power down when exceeding the value of overload power
-
Add to cartDahua 4MP EZ-IP IPC-B2B40P-ZS Mini-Bullet IP Camera
Is perfect for small to medium size applications like home/ residential security, small retail shops, and other typical SMB applications. 4MP EZ-IP IPC-B2B40P-ZS Mini-Bullet IP Camera offers a perfect alternative to migrate from analog to an IP system with its easy to use nature and cost-effectiveness.
It is fully in line with Dahua’s quality. Stable and reliable components are utilized and Various tests such as anti-vibration, water resistance, and aging tests are performed to ensure Dahua quality standards. 4MP Mini-Bullet IP Camera Captures unnecessary data such as surrounding hallway walls can increase storage requirements without any added value. The image flip feature allows the camera’s image to be rotated in 90° increments for better video optimization.
Dahua 4MP Mini-Bullet IP Camera (ROI) feature allows the operator to monitor specific areas of a scene while still maintaining overall situational awareness of less important areas Dahua 4MP Mini-Bullet IP Camera allows for ±25% input voltage tolerance, suitable for the most unstable conditions for outdoor applications. Its 2KV lightning rating provides effective protection for both the camera and its structure against lightning. Subjected and certified to rigorous dust and immersion tests (IP67).
Dahua 4MP Mini-Bullet IP Camera specifications
Camera
Image Sensor 1/3” 4Megapixel progresive CMOS
Effective Pixels 2560(H)x1440(V)
RAM/ROM 256MB/16MB
Scanning System Progressive
Electronic Shutter Speed Auto/Manual, 1/3~1/100000s
Minimum Illumination 0.05Lux/F1.8( Color,1/3s,30IRE) 0.3Lux/F1.8( Color,1/30s,30IRE) 0Lux/F1.8(IR on)
S/N Ratio More than 50dB
IR Distance Distance up to 40m(131ft)
IR On/Off Control Auto/ Manual
IR LEDs 2
Lens
Lens Type Motorized
Mount Type Board-in
Focal Length 2.8mm~12mm
Max. Aperture F1.8
Angle of View H:97°~31°, V:54°~17°
Focus Control Fixed
Close Focus Distance 0.2m(0.66ft)
DORI Distance Lens Detect Observe Recognize Identify
W 66m(216.5ft) 26.4m(86.6ft) 13.2m(43.3ft) 6.6m(21.7ft)
T 200m(656.2ft) 80m(262.5ft) 40m(131.2ft) 20m(65.6ft)
PTZ
Pan/Tilt Range Pan:0° ~360° ;Tilt:0° ~90° ;Rotation:0° ~360°
Intelligence
Event Trigger Motion detection, Video tampering , Network disconnection , Scene change, IP address conflict, Illegal Access,Storage anomaly
Video
Compression H.265/H.264/H.264B/MJPEG(Sub Stream)
Smart Codec Support H.265+/H.264+
Streaming Capability 2 Streams
Resolution 4M(2560×1440)/3M(2304×1296)/1080P(1920×1080)/720P(1280×720)/VGA(640×480)/D1(704×576/704×480)/CIF(352×288/352×240)
Frame Rate Main Stream: 4M(1 ~ 20fps)
Sub Stream: D1(1 ~ 25/30fps)
Bit Rate Control CBR/VBR
Bit Rate H.264: 32K~6144K H.265: 12K~ 6144K
Day/Night Auto(ICR) / Color / B/WBLC Mode BLC / HLC / DWDR
White Balance Auto/Natural/Street Lamp/Outdoor/Manual
Gain Control Auto/Manual
Noise Reduction 3D DNR
Motion Detetion Off / On (4 Zone, Rectangle)
Region of Interest Off / On (4 Zone)
Electronic Image Stabilization (EIS) N/A
Smart IR Support
Digital Zoom 16x
Flip 0°/90°/180°/270°
Mirror Off / On
Privacy Masking Off / On (4 Area, Rectangle)
Audio
Compression N/A
Network
Ethernet RJ-45 (10/100Base-T)
Protocol HTTP;HTTPS;TCP;ARP;RTSP;RTP;RTCP;UDP;SMTP; FTP;DHCP;DNS;DDNS;IPV4/V6;QoS;UPnP; NTP;Bonjour;Multicast;ICMP;IGMP;TLS;SSH
Interoperability ONVIF Profile S&G, API
Streaming Method Unicast / Multicast
Max. User Access 10 Users/20 Users
Edge Storage NAS(Network Attached Storage) Local PC for instant recording Micro SD Card 128GB
Web Viewer IE, Chrome, Firefox, Safari
Management Software Smart PSS, DSS,DMSS
Smart Phone IOS, Android
Certifications
Certifications CE: (EN 60950:2000) FCC: FCC Part 15 Subpart B
Interface
Video Interface N/A
Audio Interface N/A
RS485 N/A
Alarm N/A
Electrical
Power Supply DC12V, PoE (802.3af)(Class 0)
Power Consumption DC12V: 1.8W, 5.3W(IR On) PoE: 2.2W, 6.3W(IR On)
Environmental
Operating Conditions -30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH
Strorage Conditions -30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH
Ingress Protection IP67
Vandal Resistance N/A
Construction
Casing Metal+Plastic
Dimensions 243.6mm×90.7mm×90.2mm (9.59”×3.57”×3.55”)
Net Weight 0.434Kg(0.957lb)
Gross Weight 0.693Kg(1.53b)
Dahua 4MP IR Mini-Bullet Network Camera
4MP IR Mini-Bullet Network Camera
Dahua 4MP Mini-Bullet IP Camera -
Add to cart
Dahua 4MP EZ-IP IPC-B2B40P-ZS Mini-Bullet IP Camera
Is perfect for small to medium size applications like home/ residential security, small retail shops, and other typical SMB applications. 4MP EZ-IP IPC-B2B40P-ZS Mini-Bullet IP Camera offers a perfect alternative to migrate from analog to an IP system with its easy to use nature and cost-effectiveness.
It is fully in line with Dahua’s quality. Stable and reliable components are utilized and Various tests such as anti-vibration, water resistance, and aging tests are performed to ensure Dahua quality standards. 4MP Mini-Bullet IP Camera Captures unnecessary data such as surrounding hallway walls can increase storage requirements without any added value. The image flip feature allows the camera’s image to be rotated in 90° increments for better video optimization.
Dahua 4MP Mini-Bullet IP Camera (ROI) feature allows the operator to monitor specific areas of a scene while still maintaining overall situational awareness of less important areas Dahua 4MP Mini-Bullet IP Camera allows for ±25% input voltage tolerance, suitable for the most unstable conditions for outdoor applications. Its 2KV lightning rating provides effective protection for both the camera and its structure against lightning. Subjected and certified to rigorous dust and immersion tests (IP67).
Dahua 4MP Mini-Bullet IP Camera specifications
Camera
Image Sensor 1/3” 4Megapixel progresive CMOS
Effective Pixels 2560(H)x1440(V)
RAM/ROM 256MB/16MB
Scanning System Progressive
Electronic Shutter Speed Auto/Manual, 1/3~1/100000s
Minimum Illumination 0.05Lux/F1.8( Color,1/3s,30IRE) 0.3Lux/F1.8( Color,1/30s,30IRE) 0Lux/F1.8(IR on)
S/N Ratio More than 50dB
IR Distance Distance up to 40m(131ft)
IR On/Off Control Auto/ Manual
IR LEDs 2
Lens
Lens Type Motorized
Mount Type Board-in
Focal Length 2.8mm~12mm
Max. Aperture F1.8
Angle of View H:97°~31°, V:54°~17°
Focus Control Fixed
Close Focus Distance 0.2m(0.66ft)
DORI Distance Lens Detect Observe Recognize Identify
W 66m(216.5ft) 26.4m(86.6ft) 13.2m(43.3ft) 6.6m(21.7ft)
T 200m(656.2ft) 80m(262.5ft) 40m(131.2ft) 20m(65.6ft)
PTZ
Pan/Tilt Range Pan:0° ~360° ;Tilt:0° ~90° ;Rotation:0° ~360°
Intelligence
Event Trigger Motion detection, Video tampering , Network disconnection , Scene change, IP address conflict, Illegal Access,Storage anomaly
Video
Compression H.265/H.264/H.264B/MJPEG(Sub Stream)
Smart Codec Support H.265+/H.264+
Streaming Capability 2 Streams
Resolution 4M(2560×1440)/3M(2304×1296)/1080P(1920×1080)/720P(1280×720)/VGA(640×480)/D1(704×576/704×480)/CIF(352×288/352×240)
Frame Rate Main Stream: 4M(1 ~ 20fps)
Sub Stream: D1(1 ~ 25/30fps)
Bit Rate Control CBR/VBR
Bit Rate H.264: 32K~6144K H.265: 12K~ 6144K
Day/Night Auto(ICR) / Color / B/WBLC Mode BLC / HLC / DWDR
White Balance Auto/Natural/Street Lamp/Outdoor/Manual
Gain Control Auto/Manual
Noise Reduction 3D DNR
Motion Detetion Off / On (4 Zone, Rectangle)
Region of Interest Off / On (4 Zone)
Electronic Image Stabilization (EIS) N/A
Smart IR Support
Digital Zoom 16x
Flip 0°/90°/180°/270°
Mirror Off / On
Privacy Masking Off / On (4 Area, Rectangle)
Audio
Compression N/A
Network
Ethernet RJ-45 (10/100Base-T)
Protocol HTTP;HTTPS;TCP;ARP;RTSP;RTP;RTCP;UDP;SMTP; FTP;DHCP;DNS;DDNS;IPV4/V6;QoS;UPnP; NTP;Bonjour;Multicast;ICMP;IGMP;TLS;SSH
Interoperability ONVIF Profile S&G, API
Streaming Method Unicast / Multicast
Max. User Access 10 Users/20 Users
Edge Storage NAS(Network Attached Storage) Local PC for instant recording Micro SD Card 128GB
Web Viewer IE, Chrome, Firefox, Safari
Management Software Smart PSS, DSS,DMSS
Smart Phone IOS, Android
Certifications
Certifications CE: (EN 60950:2000) FCC: FCC Part 15 Subpart B
Interface
Video Interface N/A
Audio Interface N/A
RS485 N/A
Alarm N/A
Electrical
Power Supply DC12V, PoE (802.3af)(Class 0)
Power Consumption DC12V: 1.8W, 5.3W(IR On) PoE: 2.2W, 6.3W(IR On)
Environmental
Operating Conditions -30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH
Strorage Conditions -30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH
Ingress Protection IP67
Vandal Resistance N/A
Construction
Casing Metal+Plastic
Dimensions 243.6mm×90.7mm×90.2mm (9.59”×3.57”×3.55”)
Net Weight 0.434Kg(0.957lb)
Gross Weight 0.693Kg(1.53b)
Dahua 4MP IR Mini-Bullet Network Camera
4MP IR Mini-Bullet Network Camera
Dahua 4MP Mini-Bullet IP Camera -
Add to cartDahua 4MP EZ-IP IPC-D2B40 Mini-Dome IP Camera
The Dahua 4MP EZ-IP IPC-D2B40 Mini-Dome IP Camera is a compact and high-performance surveillance solution designed for both indoor and outdoor environments. Offering 4MP resolution (2560×1440), it captures clear, detailed images, making it ideal for monitoring areas where fine detail is essential. The camera’s 2.8mm fixed lens provides a wide-angle view, ensuring broad coverage in various settings.
This camera supports advanced video compression technologies, including H.265+, H.265, H.264+, and H.264, which optimize bandwidth usage and storage efficiency without compromising video quality. The 1/3** CMOS sensor combined with wide dynamic range (WDR) enhances its performance in environments with challenging lighting conditions, producing clear images even in high-contrast scenes.
Designed for 24/7 surveillance, the IPC-D2B40 features True Day/Night functionality with an IR cut filter, as well as infrared (IR) night vision capabilities that allow for clear footage up to 30 meters in complete darkness. Whether during the day or night, the camera adapts to changing lighting conditions to maintain optimal image quality.
The mini-dome camera also includes support for two-way audio, enabling remote communication, and is equipped with PoE (Power over Ethernet) support for easy installation without the need for separate power cables. Its weatherproof IP67 rating ensures reliable operation in harsh conditions, withstanding rain, dust, and varying temperatures from -30°C to +60°C.
With built-in smart features like motion detection, privacy masking, and alarm triggering, this camera enhances security by enabling proactive monitoring. It also supports local storage via a microSD card (up to 128GB), providing flexibility in data management. Furthermore, remote access is made easy through the Dahua mobile app, enabling users to view live footage from anywhere, anytime.
Overall, the Dahua 4MP EZ-IP IPC-D2B40 Mini-Dome IP Camera combines cutting-edge technology, ease of use, and durability, making it an ideal choice for both small and large-scale surveillance installations
-
Add to cart
Dahua 4MP EZ-IP IPC-D2B40 Mini-Dome IP Camera
The Dahua 4MP EZ-IP IPC-D2B40 Mini-Dome IP Camera is a compact and high-performance surveillance solution designed for both indoor and outdoor environments. Offering 4MP resolution (2560×1440), it captures clear, detailed images, making it ideal for monitoring areas where fine detail is essential. The camera’s 2.8mm fixed lens provides a wide-angle view, ensuring broad coverage in various settings.
This camera supports advanced video compression technologies, including H.265+, H.265, H.264+, and H.264, which optimize bandwidth usage and storage efficiency without compromising video quality. The 1/3** CMOS sensor combined with wide dynamic range (WDR) enhances its performance in environments with challenging lighting conditions, producing clear images even in high-contrast scenes.
Designed for 24/7 surveillance, the IPC-D2B40 features True Day/Night functionality with an IR cut filter, as well as infrared (IR) night vision capabilities that allow for clear footage up to 30 meters in complete darkness. Whether during the day or night, the camera adapts to changing lighting conditions to maintain optimal image quality.
The mini-dome camera also includes support for two-way audio, enabling remote communication, and is equipped with PoE (Power over Ethernet) support for easy installation without the need for separate power cables. Its weatherproof IP67 rating ensures reliable operation in harsh conditions, withstanding rain, dust, and varying temperatures from -30°C to +60°C.
With built-in smart features like motion detection, privacy masking, and alarm triggering, this camera enhances security by enabling proactive monitoring. It also supports local storage via a microSD card (up to 128GB), providing flexibility in data management. Furthermore, remote access is made easy through the Dahua mobile app, enabling users to view live footage from anywhere, anytime.
Overall, the Dahua 4MP EZ-IP IPC-D2B40 Mini-Dome IP Camera combines cutting-edge technology, ease of use, and durability, making it an ideal choice for both small and large-scale surveillance installations
-
Add to cartDAHUA 4MP WDR IR Mini Bullet Network Camera, DH-IPC-HFW4431EP-S-S4
Camera
Image Sensor
1/3” 4Megapixel progressive scan CMOS
Effective Pixels
2688(H)x1520(V)
RAM/ROM
512MB/32MB
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual, 1/3(4)~1/100000s
Minimum Illumination
0.06Lux/F1.6( Color,1/3s,30IRE)
0.4Lux/F1.6( Color,1/30s,30IRE)
0Lux/F1.6(IR on)
S/N Ratio
More than 50dB
IR Distance
Distance up to 40m (131ft)
IR On/Off Control
Auto/ Manual
IR LEDs
2
Lens
Lens Type
Fixed
Mount Type
Board-in
Focal Length
3.6mm (6mm optional)
Max. Aperture
F1.6 (F1.6)
Angle of View
H: 83° (55°), V: 45° (31°)
Optical Zoom
N/A
Focus Control
Fixed
Close Focus Distance
1.5m (3.1m)
DORI Distance
Lens
Detect
Observe
Recognize
Identify
3.6 mm
80m(262ft)
32m(105ft)
16m(52ft)
8m(26ft)
6.0 mm
120m(394ft)
48m(157ft)
24m(79ft)
12m(39ft)
Pan/Tilt/Rotation
Pan/Tilt/Rotation Range
Pan:0**~360**; Tilt:0**~90**; Rotation:0**~360**
Intelligence
IVS
Tripwire, Intrusion, Object Abandoned/Missing
Advanced Intelligent Functions
Face Detection
Video
Compression
H.265+/H.265/H.264+/H.264
Streaming Capability
3 Streams
Resolution
4M(2688×1520)/3M(2304×1296)/
1080P(1920×1080)/1.3M(1280×960)/
720P(1280×720)/D1(704×576/704×480)/
VGA(640×480)/CIF(352×288/352×240)
Frame Rate
Main Stream: 4M(1~25/30fps)
Sub Stream: D1(1~25/30fps)
Third Stream: 720P(1~25/30fps)
Bit Rate Control
CBR/VBR
Bit Rate
H.264: 24K ~ 10240Kbps
H.265: 14K ~ 9984Kbps
Day/Night
Auto(ICR) / Color / B/W
BLC Mode
BLC / HLC / WDR(120dB)
White Balance
Auto/Natural/Street Lamp/Outdoor/Manual
Gain Control
Auto/Manual
Noise Reduction
3D DNR
Motion Detetion
Off / On (4 Zone, Rectangle)
Region of Interest
Off / On (4 Zone)
Electronic Image Stabilization (EIS)
N/A
Smart IR
Support
Defog
N/A
Digital Zoom
16x
Flip
0°/90°/180°/270°
Mirror
Off / On
Privacy Masking
Off / On (4 Area, Rectangle)
Audio
Compression
N/A
Network
Ethernet
RJ-45 (10/100Base-T)
Protocol
HTTP; HTTPs; TCP; ARP; RTSP; RTP; UDP; SMTP;
FTP; DHCP; DNS; DDNS; PPPOE; IPv4/v6; QoS;
UPnP;NTP; Bonjour; 802.1x; Multicast; ICMP;
IGMP; SNMP
Interoperability
ONVIF, PSIA, CGI
Streaming Method
Unicast / Multicast
Max. User Access
10 Users /20 Users
Edge Storage
NAS
Local PC for instant recording
Mirco SD card 128GB
Web Viewer
IE, Chrome, Firefox, Safari
Management Software
Smart PSS, DSS, Easy4ip
Smart Phone
IOS, Android
Certifications
Certifications
CE (EN 60950:2000)
UL:UL60950-1
FCC: FCC Part 15 Subpart B
Interface
Video Interface
N/A
Audio Interface
N/A
RS485
N/A
Alarm
N/A
Electrical
Power Supply
DC12V, PoE (802.3af)(Class 0)
Power Consumption
<6W Environmental Operating Conditions -30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH Strorage Conditions -30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH Ingress Protection IP67 Vandal Resistance N/A Construction Casing Metal Dimensions 180mm×70mm×70mm (7.09”×2.76”×2.76”) Net Weight 0.41kg (0.91lb) Gross Weight 0.53 kg (1.17lb)
-
Add to cart
DAHUA 4MP WDR IR Mini Bullet Network Camera, DH-IPC-HFW4431EP-S-S4
Camera
Image Sensor
1/3” 4Megapixel progressive scan CMOS
Effective Pixels
2688(H)x1520(V)
RAM/ROM
512MB/32MB
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual, 1/3(4)~1/100000s
Minimum Illumination
0.06Lux/F1.6( Color,1/3s,30IRE)
0.4Lux/F1.6( Color,1/30s,30IRE)
0Lux/F1.6(IR on)
S/N Ratio
More than 50dB
IR Distance
Distance up to 40m (131ft)
IR On/Off Control
Auto/ Manual
IR LEDs
2
Lens
Lens Type
Fixed
Mount Type
Board-in
Focal Length
3.6mm (6mm optional)
Max. Aperture
F1.6 (F1.6)
Angle of View
H: 83° (55°), V: 45° (31°)
Optical Zoom
N/A
Focus Control
Fixed
Close Focus Distance
1.5m (3.1m)
DORI Distance
Lens
Detect
Observe
Recognize
Identify
3.6 mm
80m(262ft)
32m(105ft)
16m(52ft)
8m(26ft)
6.0 mm
120m(394ft)
48m(157ft)
24m(79ft)
12m(39ft)
Pan/Tilt/Rotation
Pan/Tilt/Rotation Range
Pan:0**~360**; Tilt:0**~90**; Rotation:0**~360**
Intelligence
IVS
Tripwire, Intrusion, Object Abandoned/Missing
Advanced Intelligent Functions
Face Detection
Video
Compression
H.265+/H.265/H.264+/H.264
Streaming Capability
3 Streams
Resolution
4M(2688×1520)/3M(2304×1296)/
1080P(1920×1080)/1.3M(1280×960)/
720P(1280×720)/D1(704×576/704×480)/
VGA(640×480)/CIF(352×288/352×240)
Frame Rate
Main Stream: 4M(1~25/30fps)
Sub Stream: D1(1~25/30fps)
Third Stream: 720P(1~25/30fps)
Bit Rate Control
CBR/VBR
Bit Rate
H.264: 24K ~ 10240Kbps
H.265: 14K ~ 9984Kbps
Day/Night
Auto(ICR) / Color / B/W
BLC Mode
BLC / HLC / WDR(120dB)
White Balance
Auto/Natural/Street Lamp/Outdoor/Manual
Gain Control
Auto/Manual
Noise Reduction
3D DNR
Motion Detetion
Off / On (4 Zone, Rectangle)
Region of Interest
Off / On (4 Zone)
Electronic Image Stabilization (EIS)
N/A
Smart IR
Support
Defog
N/A
Digital Zoom
16x
Flip
0°/90°/180°/270°
Mirror
Off / On
Privacy Masking
Off / On (4 Area, Rectangle)
Audio
Compression
N/A
Network
Ethernet
RJ-45 (10/100Base-T)
Protocol
HTTP; HTTPs; TCP; ARP; RTSP; RTP; UDP; SMTP;
FTP; DHCP; DNS; DDNS; PPPOE; IPv4/v6; QoS;
UPnP;NTP; Bonjour; 802.1x; Multicast; ICMP;
IGMP; SNMP
Interoperability
ONVIF, PSIA, CGI
Streaming Method
Unicast / Multicast
Max. User Access
10 Users /20 Users
Edge Storage
NAS
Local PC for instant recording
Mirco SD card 128GB
Web Viewer
IE, Chrome, Firefox, Safari
Management Software
Smart PSS, DSS, Easy4ip
Smart Phone
IOS, Android
Certifications
Certifications
CE (EN 60950:2000)
UL:UL60950-1
FCC: FCC Part 15 Subpart B
Interface
Video Interface
N/A
Audio Interface
N/A
RS485
N/A
Alarm
N/A
Electrical
Power Supply
DC12V, PoE (802.3af)(Class 0)
Power Consumption
<6W Environmental Operating Conditions -30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH Strorage Conditions -30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH Ingress Protection IP67 Vandal Resistance N/A Construction Casing Metal Dimensions 180mm×70mm×70mm (7.09”×2.76”×2.76”) Net Weight 0.41kg (0.91lb) Gross Weight 0.53 kg (1.17lb)
-
Add to cartDahua 64GB C10/U3/V30 MicroSD Memory Card – DHI-TF-C100/64GB Key features: Read Speed: Up to 95 MB/s Write Speed: Up to 38 MB/s 7-year limited warranty High-quality FLASH Memory Cell and Superior Performance: Adopts mainstream FLASH memory cell; superior performance and long service life. Meeting Various Needs: Meets various user needs such as recording videos, taking photos, listening to music, playing games, and storing data. High Compatibility: Compatible with various digital products. Durable Design: Four types of protection: High and low temperature resistant, waterproof, anti-magnetic, and anti X-ray ; adapts to a variety of environments.
-
Add to cartDahua 64GB Dual Drive USB3.2 Gen1 – DHI-USB-P629-32-64GB Key features: Exclusive appearance with metal casing Shockproof and anti-drop for great quality High-speed of 20 MB/s–150 MB/s read and 6 MB/s–100 MB/s write Easy to hold and plug because of the protruding edge Compatible with Windows, macOS, and Linux operating systems With two ports, it is compatible with devices having Type-A and Type-C ports Smooth surface can be engraved with words to turn the product to a personalized gift Transfer and back up texts, images, music, videos and other data on computers, mobile phones and digital products 5 year limited warranty
-
Add to cartDahua 64GB USB2.0 Flash Drive – DHI-USB-U106-20-64GB Key features: Capacity: 64GB Interface: USB 2.0 File system: exFAT Exquisite appearance High-speed Read 10–25 MB/s and Write 3–10 MB/s Meeting Diverse Needs: Transfer and back up texts, images, music, videos and other data on computers and digital products Compatible with Multiple Operating Systems Compatible with Windows, macOS, Linux, and other operating systems. 5 Year warranty
-
Add to cartDahua 64GB USB3.0 Flash Drive – DHI-USB-106-30-64GB Key features: Capacity: 64GB Interface: USB 3.0 File system: exFAT Exquisite appearance High-speed Read 40–70 MB/s and Write 9–25 MB/s Meeting Diverse Needs: Transfer and back up texts, images, music, videos and other data on computers and digital products Compatible with Multiple Operating Systems Compatible with Windows, macOS, Linux, and other operating systems. 5 Year warranty
-
Dahua 700TVL Analogue Bullet/Dome Camera – Kenya
KSh2,600.00Add to cartDahua 700TVL Analogue Bullet/Dome Camera
The Dahua 700TVL Analog Bullet/Dome Camera is a versatile and high-resolution surveillance camera designed for reliable video monitoring in various settings. Available in both bullet and dome configurations, this camera delivers a sharp 700 TVL (Television Lines) resolution, ensuring clear and detailed image quality.
Equipped with a 1/3** Sony Super HAD CCD sensor, the camera provides excellent image capture in both day and night conditions. It features a fixed lens, typically 3.6 mm or 6 mm, offering a wide field of view suitable for a range of surveillance applications. The camera’s infrared (IR) LEDs enable effective night vision, with an IR distance of up to 20 meters, allowing it to capture clear footage even in complete darkness.
The Dahua 700TVL camera supports analog CCTV video output via a BNC connector, making it compatible with existing analog CCTV systems. Its weatherproof design, with an IP66 or IP67 rating, ensures durability and protection against dust and water, making it suitable for both indoor and outdoor use.
The camera operates on 12V DC power and is designed to function effectively in temperatures ranging from -10°C to +50°C. Its adjustable mounting bracket allows for flexible installation, ensuring optimal camera positioning and coverage.
Overall, the Dahua 700TVL Analog Bullet/Dome Camera offers a cost-effective solution for high-resolution analog surveillance, combining reliable performance with ease of installation and use.
-
Dahua 700TVL Analogue Bullet/Dome Camera – Kenya
KSh2,600.00Add to cartDahua 700TVL Analogue Bullet/Dome Camera
The Dahua 700TVL Analog Bullet/Dome Camera is a versatile and high-resolution surveillance camera designed for reliable video monitoring in various settings. Available in both bullet and dome configurations, this camera delivers a sharp 700 TVL (Television Lines) resolution, ensuring clear and detailed image quality.
Equipped with a 1/3** Sony Super HAD CCD sensor, the camera provides excellent image capture in both day and night conditions. It features a fixed lens, typically 3.6 mm or 6 mm, offering a wide field of view suitable for a range of surveillance applications. The camera’s infrared (IR) LEDs enable effective night vision, with an IR distance of up to 20 meters, allowing it to capture clear footage even in complete darkness.
The Dahua 700TVL camera supports analog CCTV video output via a BNC connector, making it compatible with existing analog CCTV systems. Its weatherproof design, with an IP66 or IP67 rating, ensures durability and protection against dust and water, making it suitable for both indoor and outdoor use.
The camera operates on 12V DC power and is designed to function effectively in temperatures ranging from -10°C to +50°C. Its adjustable mounting bracket allows for flexible installation, ensuring optimal camera positioning and coverage.
Overall, the Dahua 700TVL Analog Bullet/Dome Camera offers a cost-effective solution for high-resolution analog surveillance, combining reliable performance with ease of installation and use.
-
Dahua 8 CCTV Camera Package Installation – Kenya
KSh115,000.00Add to cartDahua 8 CCTV Camera Package Installation
Get your High-Quality Dahua CCTV 8 camera Set Full Package Kit with DVR that can monitor your home or business 24/7. Made of high-quality materials with meticulous work. Built-in HD lens, you can get 360-degree panoramic images.
Embedded processor,H.264 video compression, Support HDCVI/AHD/TVI/CVBS/IP video inputs, and Max 5/10/18 channels IP camera inputs, Long transmission distance over coax/coaxial cable. Supports 1 SATA HDD, up to 6TB.
Support P2P, allowing easier home applications
All channel synchronous real-time playback
All cameras with 1MP 720P real-time preview
H.264 dual-stream video compression
HDMI/VGA simultaneous video output
All channel non-real-time 720P recording
Multiple network monitoring: web-browser, smartphone/tablet APP
VGA output
HDMI output
Embedded processor
H.264 video compression
Support HDCVI/AHD/TVI/CVBS/IP video inputs
Max 5/10/18 channels IP camera inputs
Long transmission distance over coax cable> Support 1 SATA HDD, up to 6TB
Unit QTY
Dahua Cameras 1080P pcs 8
8 Channel Metallic Digital Video Recorder (DVR) 1080p pcs 1
24 inch TV pcs 1
1 TB Hard Disk pcs 1
Power Supply Unit (PSU) pcs 1
Wall Bracket pcs 1
UPS 650VA pcs 1
Coaxial Cable (RG59 with Power) —- 1
Accessories pcs 1
Labour(Installation) pcs 1 -
Dahua 8 CCTV Camera Package Installation – Kenya
KSh115,000.00Add to cartDahua 8 CCTV Camera Package Installation
Get your High-Quality Dahua CCTV 8 camera Set Full Package Kit with DVR that can monitor your home or business 24/7. Made of high-quality materials with meticulous work. Built-in HD lens, you can get 360-degree panoramic images.
Embedded processor,H.264 video compression, Support HDCVI/AHD/TVI/CVBS/IP video inputs, and Max 5/10/18 channels IP camera inputs, Long transmission distance over coax/coaxial cable. Supports 1 SATA HDD, up to 6TB.
Support P2P, allowing easier home applications
All channel synchronous real-time playback
All cameras with 1MP 720P real-time preview
H.264 dual-stream video compression
HDMI/VGA simultaneous video output
All channel non-real-time 720P recording
Multiple network monitoring: web-browser, smartphone/tablet APP
VGA output
HDMI output
Embedded processor
H.264 video compression
Support HDCVI/AHD/TVI/CVBS/IP video inputs
Max 5/10/18 channels IP camera inputs
Long transmission distance over coax cable> Support 1 SATA HDD, up to 6TB
Unit QTY
Dahua Cameras 1080P pcs 8
8 Channel Metallic Digital Video Recorder (DVR) 1080p pcs 1
24 inch TV pcs 1
1 TB Hard Disk pcs 1
Power Supply Unit (PSU) pcs 1
Wall Bracket pcs 1
UPS 650VA pcs 1
Coaxial Cable (RG59 with Power) —- 1
Accessories pcs 1
Labour(Installation) pcs 1 -
Add to cartDahua 8 Channel Compact 1U 8 PoE H.265 NVR, (NVR1B08HS-8P/E )
System
Main Processor
Dual-core embedded processor
Operating System
Embedded LINUX
Audio and Video
IP Camera Input
8 Channel
Two-way Talk
N/A
Display
Interface
1 HDMI, 1 VGA
Resolution
1920×1080, 1280×1024, 1280×720
Decoding Capacity
1ch@6MP 30fps, 4ch@1080P 25fps
Multi-screen Display
1/4
OSD
Camera title, Time, Camera lock, Motion detection, Recording
Recording
Compression
H.265+/H.264+
Resolution
6MP/5MP/4MP/3MP/1080P/ 720P/ D1&etc.
Record Rate
40Mbps
Bit Rate
16Kbps ~ 20Mbps Per Channel
Record Mode
Manual, Schedule(Regular(Continuous), MD, Stop
Record Interval
1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec
Video Detection and Alarm
Trigger Events
Recording, PTZ, Tour, Video Push, Snapshot, and Screen Tips
Video Detection
Motion Detection, MD Zones: 396 (22 × 18),
and Tampering
Alarm input
N/A
Relay Output
N/A
Playback and Backup
Sync Playback
1/4/9
Search Mode
Time /Date, MD and Exact Search
(accurate to second)
Playback Function
Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Backup Selection, Digital Zoom
Backup Mode
USB Device/Network
Third-party Support
Third-party Support
Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, and more
Network
Interface
1 RJ-45 port (10/100Mbps)
PoE
8 ports(IEEE802.3at/af)
Network Function
HTTP/HTTPS, TCP/IP, IPv4/IPv6, RTSP, UDP, NTP, DHCP, DNS, IP Filter, IP Search(Support IP camera, DVR, NVS and etc.), P2P
Optical Fiber Interface
N/A
Max. User Access
128 users
Smart Phone
iPhone, iPad, Android
Interoperability
ONVIF ,SDK, CGI Conformant
Storage
Internal HDD
1 SATA III Port, up to 4TB capacity for each HDD
HDD Mode
Single
eSATA
N/A
Auxiliary Interface
USB
2 ports (2 Rear USB2.0)
RS232
N/A
RS485
N/A
Electrical
Power Supply
Single, DC48V/2A
Power Consumption
NVR: <4.29W (without HDD) PoE: Max 25.5w for single port, 72w in total Environmental Operating Conditions -10°C ~ +45°C (+14°F ~ +113°F), 86 ~ 106kpa Storage Conditions -20°C ~ +70°C (-4°F ~ +158°F), 0 ~ 90% RH Construction Dimensions(W×D×H) Cooper 1U, 260mm×227mm×47.6mm (10.24** x 8.94** x 1.87**) Net Weight 2 kg (4.41 lb) (without HDD) Gross Weight 2.5 kg(5.51 lb)(without HDD) Certifications CE EN55032, EN55024, EN50130-4, EN60950-1 FCC Part 15 Subpart B, ANSI C63.4-2014
-
Add to cart
Dahua 8 Channel Compact 1U 8 PoE H.265 NVR, (NVR1B08HS-8P/E )
System
Main Processor
Dual-core embedded processor
Operating System
Embedded LINUX
Audio and Video
IP Camera Input
8 Channel
Two-way Talk
N/A
Display
Interface
1 HDMI, 1 VGA
Resolution
1920×1080, 1280×1024, 1280×720
Decoding Capacity
1ch@6MP 30fps, 4ch@1080P 25fps
Multi-screen Display
1/4
OSD
Camera title, Time, Camera lock, Motion detection, Recording
Recording
Compression
H.265+/H.264+
Resolution
6MP/5MP/4MP/3MP/1080P/ 720P/ D1&etc.
Record Rate
40Mbps
Bit Rate
16Kbps ~ 20Mbps Per Channel
Record Mode
Manual, Schedule(Regular(Continuous), MD, Stop
Record Interval
1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec
Video Detection and Alarm
Trigger Events
Recording, PTZ, Tour, Video Push, Snapshot, and Screen Tips
Video Detection
Motion Detection, MD Zones: 396 (22 × 18),
and Tampering
Alarm input
N/A
Relay Output
N/A
Playback and Backup
Sync Playback
1/4/9
Search Mode
Time /Date, MD and Exact Search
(accurate to second)
Playback Function
Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Backup Selection, Digital Zoom
Backup Mode
USB Device/Network
Third-party Support
Third-party Support
Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, and more
Network
Interface
1 RJ-45 port (10/100Mbps)
PoE
8 ports(IEEE802.3at/af)
Network Function
HTTP/HTTPS, TCP/IP, IPv4/IPv6, RTSP, UDP, NTP, DHCP, DNS, IP Filter, IP Search(Support IP camera, DVR, NVS and etc.), P2P
Optical Fiber Interface
N/A
Max. User Access
128 users
Smart Phone
iPhone, iPad, Android
Interoperability
ONVIF ,SDK, CGI Conformant
Storage
Internal HDD
1 SATA III Port, up to 4TB capacity for each HDD
HDD Mode
Single
eSATA
N/A
Auxiliary Interface
USB
2 ports (2 Rear USB2.0)
RS232
N/A
RS485
N/A
Electrical
Power Supply
Single, DC48V/2A
Power Consumption
NVR: <4.29W (without HDD) PoE: Max 25.5w for single port, 72w in total Environmental Operating Conditions -10°C ~ +45°C (+14°F ~ +113°F), 86 ~ 106kpa Storage Conditions -20°C ~ +70°C (-4°F ~ +158°F), 0 ~ 90% RH Construction Dimensions(W×D×H) Cooper 1U, 260mm×227mm×47.6mm (10.24** x 8.94** x 1.87**) Net Weight 2 kg (4.41 lb) (without HDD) Gross Weight 2.5 kg(5.51 lb)(without HDD) Certifications CE EN55032, EN55024, EN50130-4, EN60950-1 FCC Part 15 Subpart B, ANSI C63.4-2014
-
Add to cartDahua 8 Channel NVR, DHI NVR1108HS-S3/H 8 Channel Compact Video Recorder
System
Main Processor Embedded Processor
Operating System Embedded LINUX
Operation Interface Web/operating in local GUI
Video
Access Channel 8 channels
Network Bandwidth 80 Mbps for access, 80 Mbps for storage and 60 Mbps for forwarding.
Resolution 8MP/5MP/4MP/3MP/1080P/720P/D1/CIF
Decoding Capability 1–ch@8MP(30FPS) or 1–ch@5MP(30FPS) or
2–ch@4MP(30FPS) or 2–ch@3MP(30FPS) or 4–
ch@1080P(30FPS)8–ch@720P(30FPS)
Video Output 1 VGA/1 HDMI simultaneous video output, maximum resolution 1080P
Multi-screen Display 1 / 4 / 8 /9
Browser Onvif, RTSP
Compression
Video Smart H.265+/H.265/Smart H.264+/H.264
Audio PCM/G711A/G711U/G726/AAC
Network
Network Protocol HTTP, HTTPS, TCP/IP, IPv4, IPv6, RTSP, UDP, NTP, DHCP,
DNS, P2P
Mobile Phone Access iDMSS(iOS), gDMSS(Android)
Access Standard ONVIF(profile T/profile S/profile G),CGI,SDK
Browser Chrome, IE9 or above, Firefox
Record Playback
Multi-channel Playback Up to 8 channels playback
Record Mode Priority of record mode: Manual recording > alarm recording > motion detection recording > timed recording
Storage Local HDD and network
Backup USB device
Playback Function 1. Play, pause, stop, fast forward, fast backward, rewind, play by frame 2. Full screen, backup (cut/file), partially enlarge, audio on/off
Alarm
General Alarm Motion detection, privacy masking, video loss, PIR alarm, IPC alarm
Anomaly Alarm Front-end device going offline, storage error, full storage, IP conflict, MAC conflict, login lock, network security anomaly
Alarm Linkage Video recording, snapshot, log, preset, tour
External Port
HDD 1 SATA 2.0 port, up to 8 TB for a single HDD. The maximum HDD capacity varies with environment temperature
USB 1 front USB 2.0 port, 1 rear USB 2.0 port
HDMI 1
VGA 1
RCA Input 1
RCA Output 1
Alarm None
Network 1 RJ–45 port (10/100 Mbps)
General Parameter
Power Supply DC12V, 1.5A
Power Consumption Total output of NVR is ** 10W (without HDD)
Net Weight 0.81 kg (1.79 lb)
Gross weight 1.38 kg (3.04 lb)
Product Dimensions 260 mm×225 mm×47.6 mm (W × L × H)
Box Dimensions 87 mm×331 mm×312 mm (W × L × H)
Operating Temperature -10°C to 45°C (+34°F to +113°F)
Storage Temperature 0°C to 40°C (+32°F to +104°F)
Operating Humidity 10%~93%
Storage Humidity 30%~85%
Operating Altitude 3000 m (9843 ft)
Installation Desktop mounting
Certification CE/FCC -
Add to cart
Dahua 8 Channel NVR, DHI NVR1108HS-S3/H 8 Channel Compact Video Recorder
System
Main Processor Embedded Processor
Operating System Embedded LINUX
Operation Interface Web/operating in local GUI
Video
Access Channel 8 channels
Network Bandwidth 80 Mbps for access, 80 Mbps for storage and 60 Mbps for forwarding.
Resolution 8MP/5MP/4MP/3MP/1080P/720P/D1/CIF
Decoding Capability 1–ch@8MP(30FPS) or 1–ch@5MP(30FPS) or
2–ch@4MP(30FPS) or 2–ch@3MP(30FPS) or 4–
ch@1080P(30FPS)8–ch@720P(30FPS)
Video Output 1 VGA/1 HDMI simultaneous video output, maximum resolution 1080P
Multi-screen Display 1 / 4 / 8 /9
Browser Onvif, RTSP
Compression
Video Smart H.265+/H.265/Smart H.264+/H.264
Audio PCM/G711A/G711U/G726/AAC
Network
Network Protocol HTTP, HTTPS, TCP/IP, IPv4, IPv6, RTSP, UDP, NTP, DHCP,
DNS, P2P
Mobile Phone Access iDMSS(iOS), gDMSS(Android)
Access Standard ONVIF(profile T/profile S/profile G),CGI,SDK
Browser Chrome, IE9 or above, Firefox
Record Playback
Multi-channel Playback Up to 8 channels playback
Record Mode Priority of record mode: Manual recording > alarm recording > motion detection recording > timed recording
Storage Local HDD and network
Backup USB device
Playback Function 1. Play, pause, stop, fast forward, fast backward, rewind, play by frame 2. Full screen, backup (cut/file), partially enlarge, audio on/off
Alarm
General Alarm Motion detection, privacy masking, video loss, PIR alarm, IPC alarm
Anomaly Alarm Front-end device going offline, storage error, full storage, IP conflict, MAC conflict, login lock, network security anomaly
Alarm Linkage Video recording, snapshot, log, preset, tour
External Port
HDD 1 SATA 2.0 port, up to 8 TB for a single HDD. The maximum HDD capacity varies with environment temperature
USB 1 front USB 2.0 port, 1 rear USB 2.0 port
HDMI 1
VGA 1
RCA Input 1
RCA Output 1
Alarm None
Network 1 RJ–45 port (10/100 Mbps)
General Parameter
Power Supply DC12V, 1.5A
Power Consumption Total output of NVR is ** 10W (without HDD)
Net Weight 0.81 kg (1.79 lb)
Gross weight 1.38 kg (3.04 lb)
Product Dimensions 260 mm×225 mm×47.6 mm (W × L × H)
Box Dimensions 87 mm×331 mm×312 mm (W × L × H)
Operating Temperature -10°C to 45°C (+34°F to +113°F)
Storage Temperature 0°C to 40°C (+32°F to +104°F)
Operating Humidity 10%~93%
Storage Humidity 30%~85%
Operating Altitude 3000 m (9843 ft)
Installation Desktop mounting
Certification CE/FCC -
Add to cartDahua 8 Channel NVR, DHI-NVR4108HS-8P-4KS2/L 8 Channel 4K H.265 Lite NVR
System
Main Processor
Industrial-grade embedded processor
OS
Embedded Linux
Operation Interface
Web/operating in local GUI
Perimeter Protection by Camera
Performance
8 channels
AI Search
Search for pictures by channel, time and event type
Face Detection by Camera
Performance
4 channels
Face Attributes
6 attributes: Gender, age, glasses, expression, mouth mask, and beard
AI Search
Search for pictures by channel, time and face attributes
SMD Plus by Camera
Performance
8 channels
AI Search
Search by target classification (human, vehicle)
Video
Access Channel
8
Network Bandwidth
Access: 80 Mbps; Storage: 80 Mbps; Forward: 60 Mbps
Resolution
8MP; 6MP; 5MP; 4MP; 3MP; 1080p; 720p; D1
Decoding Capability
8 × 1080p@30 fps
Video Output
1 × VGA output, 1 × HDMI output, supports simultaneous video sources output for VGA and HDMI
Multi-screen Display
1, 4, 8, 9 views
Third-party Camera Access
ONVIF; RTSP
Compression
Video
Smart H.265/H.265/Smart H.264/H.264/MJPEG
Audio
PCM/G711A/G711U/G726/AAC
Network
Network Protocol
HTTP; HTTPS; TCP/IP; IPv4/IPv6; UPnP; SNMP; RTSP; UDP; SMTP; NTP; DHCP; DNS; IP Filter; DDNS; FTP; Alarm Server; IP Search (Support Dahua IP camera; DVR; NVS; etc.); P2P; auto register
Mobile Phone Access
Android; iOS
Interoperability
ONVIF(profile T/S/G); CGI; SDK
Browser
Chrome; IE9 or later; firefox
Record Playback
Multi-channel Playback
Up to 8 channels for playback
Record Mode
Manual record; alarm recording; SMD recording; smart recording
Storage
Local HDD; network
Backup
USB storage device
Playback Function
1. Play/pause/stop/slow/quick/backward/by frame
2. Full screen, backup (video clip/file), partial zoom in, and audio on/offStorage
Disk Group
Yes
Alarm
General Alarm
Motion detection, privacy masking, video loss, scene changing, PIR alarm, IPC external alarm
Anomaly Alarm
Camera disconnection, storage error, disk full, IP conflict, MAC conflict, login locked, and cybersecurity exception
Intelligent Alarm
Face detection, perimeter protection (intrusion and tripwire), IVS, people counting, heat map, and SMD alarms
Alarm Linkage
Recording, snapshot, audio, buzzer, log, preset, and email
External Port
Audio Input
1 × RCA input
Audio Output
1 × RCA output
HDD
1 SATA III ports, up to 10 TB for a single HDD. The maximum HDD capacity varies with environment temperature
USB
2 (1 × front USB2.0; 1 × back USB2.0)
HDMI
1 (supports up to 4K resolution output)
VGA
1
Network
1 × RJ-45, 10/100 Mbps self-adaptive Ethernet port
POE
8
General Parameter
Power Supply
DC48 V/53 V, 2A/1.8 A
Power Consumption
< 10 W (HDD not included, idling) Total output power of PoE is 72W, the maximum output power of a single port is 25.5W Net Weight 0.92 kg (2.03 lb) Gross Weight 2.07 kg (4.56 lb) Product Dimensions 260 mm × 232.5 mm × 50.3 mm (10.24** × 9.15** × 1.98**) (W × L × H) Package Dimensions 117 mm × 373 mm × 307 mm (4.61** × 14.69** × 12.09**) (W × L × H) Operating Conditions –10 °C to +55 °C (+10 °F to +131 °F) Storage Conditions 0 °C to +40 °C (32 °F to 104 °F) Operating Humidity 10**~93** Storage Humidity 30%~85% Operating Altitude 3000 m (9842.52 ft) Installation Desktop mounted Certifications CE: EN62368-1; EN55032,EN55024, EN55035, EN61000-3-2, EN61000-3-3 EN50130-4 FCC: Part 15 Subpart B
-
Add to cart
Dahua 8 Channel NVR, DHI-NVR4108HS-8P-4KS2/L 8 Channel 4K H.265 Lite NVR
System
Main Processor
Industrial-grade embedded processor
OS
Embedded Linux
Operation Interface
Web/operating in local GUI
Perimeter Protection by Camera
Performance
8 channels
AI Search
Search for pictures by channel, time and event type
Face Detection by Camera
Performance
4 channels
Face Attributes
6 attributes: Gender, age, glasses, expression, mouth mask, and beard
AI Search
Search for pictures by channel, time and face attributes
SMD Plus by Camera
Performance
8 channels
AI Search
Search by target classification (human, vehicle)
Video
Access Channel
8
Network Bandwidth
Access: 80 Mbps; Storage: 80 Mbps; Forward: 60 Mbps
Resolution
8MP; 6MP; 5MP; 4MP; 3MP; 1080p; 720p; D1
Decoding Capability
8 × 1080p@30 fps
Video Output
1 × VGA output, 1 × HDMI output, supports simultaneous video sources output for VGA and HDMI
Multi-screen Display
1, 4, 8, 9 views
Third-party Camera Access
ONVIF; RTSP
Compression
Video
Smart H.265/H.265/Smart H.264/H.264/MJPEG
Audio
PCM/G711A/G711U/G726/AAC
Network
Network Protocol
HTTP; HTTPS; TCP/IP; IPv4/IPv6; UPnP; SNMP; RTSP; UDP; SMTP; NTP; DHCP; DNS; IP Filter; DDNS; FTP; Alarm Server; IP Search (Support Dahua IP camera; DVR; NVS; etc.); P2P; auto register
Mobile Phone Access
Android; iOS
Interoperability
ONVIF(profile T/S/G); CGI; SDK
Browser
Chrome; IE9 or later; firefox
Record Playback
Multi-channel Playback
Up to 8 channels for playback
Record Mode
Manual record; alarm recording; SMD recording; smart recording
Storage
Local HDD; network
Backup
USB storage device
Playback Function
1. Play/pause/stop/slow/quick/backward/by frame
2. Full screen, backup (video clip/file), partial zoom in, and audio on/offStorage
Disk Group
Yes
Alarm
General Alarm
Motion detection, privacy masking, video loss, scene changing, PIR alarm, IPC external alarm
Anomaly Alarm
Camera disconnection, storage error, disk full, IP conflict, MAC conflict, login locked, and cybersecurity exception
Intelligent Alarm
Face detection, perimeter protection (intrusion and tripwire), IVS, people counting, heat map, and SMD alarms
Alarm Linkage
Recording, snapshot, audio, buzzer, log, preset, and email
External Port
Audio Input
1 × RCA input
Audio Output
1 × RCA output
HDD
1 SATA III ports, up to 10 TB for a single HDD. The maximum HDD capacity varies with environment temperature
USB
2 (1 × front USB2.0; 1 × back USB2.0)
HDMI
1 (supports up to 4K resolution output)
VGA
1
Network
1 × RJ-45, 10/100 Mbps self-adaptive Ethernet port
POE
8
General Parameter
Power Supply
DC48 V/53 V, 2A/1.8 A
Power Consumption
< 10 W (HDD not included, idling) Total output power of PoE is 72W, the maximum output power of a single port is 25.5W Net Weight 0.92 kg (2.03 lb) Gross Weight 2.07 kg (4.56 lb) Product Dimensions 260 mm × 232.5 mm × 50.3 mm (10.24** × 9.15** × 1.98**) (W × L × H) Package Dimensions 117 mm × 373 mm × 307 mm (4.61** × 14.69** × 12.09**) (W × L × H) Operating Conditions –10 °C to +55 °C (+10 °F to +131 °F) Storage Conditions 0 °C to +40 °C (32 °F to 104 °F) Operating Humidity 10**~93** Storage Humidity 30%~85% Operating Altitude 3000 m (9842.52 ft) Installation Desktop mounted Certifications CE: EN62368-1; EN55032,EN55024, EN55035, EN61000-3-2, EN61000-3-3 EN50130-4 FCC: Part 15 Subpart B
-
Add to cartDahua 8 Channel NVR, NVR4108-8P-4KS2, 8 channel IP NVR
System
Main Processor
Industrial-grade embedded processor
OS
Embedded Linux
Operation Interface
Web/operating in local GUI
Perimeter Protection by Camera
Performance
8 channels
AI Search
Search for pictures by channel, time and event type
Face Detection by Camera
Performance
4 channels
Face Attributes
6 attributes: Gender, age, glasses, expression, mouth mask, and beard
AI Search
Search for pictures by channel, time and face attributes
SMD Plus by Camera
Performance
8 channels
AI Search
Search by target classification (human, vehicle)
Video
Access Channel
8
Network Bandwidth
Access: 80 Mbps; Storage: 80 Mbps; Forward: 60 Mbps
Resolution
8MP; 6MP; 5MP; 4MP; 3MP; 1080p; 720p; D1
Decoding Capability
8 × 1080p@30 fps
Video Output
1 × VGA output, 1 × HDMI output, supports simultaneous video sources output for VGA and HDMI
Multi-screen Display
1, 4, 8, 9 views
Third-party Camera Access
ONVIF; RTSP
Compression
Video
Smart H.265/H.265/Smart H.264/H.264/MJPEG
Audio
PCM/G711A/G711U/G726/AAC
Network
Network Protocol
HTTP; HTTPS; TCP/IP; IPv4/IPv6; UPnP; SNMP; RTSP; UDP; SMTP; NTP; DHCP; DNS; IP Filter; DDNS; FTP; Alarm Server; IP Search (Support Dahua IP camera; DVR; NVS; etc.); P2P; auto register
Mobile Phone Access
Android; iOS
Interoperability
ONVIF(profile T/S/G); CGI; SDK
Browser
Chrome; IE9 or later; firefox
Record Playback
Multi-channel Playback
Up to 8 channels for playback
Record Mode
Manual record; alarm recording; SMD recording; smart recording
Storage
Local HDD; network
Backup
USB storage device
Playback Function
1. Play/pause/stop/slow/quick/backward/by frame
2. Full screen, backup (video clip/file), partial zoom in, and audio on/offStorage
Disk Group
Yes
Alarm
General Alarm
Motion detection, privacy masking, video loss, scene changing, PIR alarm, IPC external alarm
Anomaly Alarm
Camera disconnection, storage error, disk full, IP conflict, MAC conflict, login locked, and cybersecurity exception
Intelligent Alarm
Face detection, perimeter protection (intrusion and tripwire), IVS, people counting, heat map, and SMD alarms
Alarm Linkage
Recording, snapshot, audio, buzzer, log, preset, and email
External Port
Audio Input
1 × RCA input
Audio Output
1 × RCA output
HDD
1 SATA III ports, up to 10 TB for a single HDD. The maximum HDD capacity varies with environment temperature
USB
2 (2 × back USB2.0)
HDMI
1 (supports up to 4K resolution output)
VGA
1
Network
1 × RJ-45, 10/100 Mbps self-adaptive Ethernet port
POE
8
General Parameter
Power Supply
DC48V/53V, 2A/1.8A
Power Consumption
< 10 W (HDD not included, idling) Total output power of PoE is 72W, the maximum output power of a single port is 25.5W Net Weight 0.70 kg (1.54 lb) Gross Weight 1.80 kg (3.97 lb Product Dimensions 270 mm × 206.5 mm × 47.5 mm (10.63** × 8.13** × 1.87**) (W × L × H) Package Dimensions 96 mm × 427 mm × 262 mm (3.78** × 16.81** × 10.31**) (W × L × H) Operating Conditions –10 °C to +50 °C (+10 °F to +122 °F) Storage Conditions 0 °C to +40 °C (32 °F to 104 °F) Operating Humidity 10**~93** Storage Humidity 30%~85% Operating Altitude 3000 m (9842.52 ft) Installation Desktop mounted Certifications CE: EN62368-1; EN55032,EN55024, EN55035, EN61000-3-2, EN61000-3-3 EN50130-4 FCC: Part 15 Subpart
-
Add to cart
Dahua 8 Channel NVR, NVR4108-8P-4KS2, 8 channel IP NVR
System
Main Processor
Industrial-grade embedded processor
OS
Embedded Linux
Operation Interface
Web/operating in local GUI
Perimeter Protection by Camera
Performance
8 channels
AI Search
Search for pictures by channel, time and event type
Face Detection by Camera
Performance
4 channels
Face Attributes
6 attributes: Gender, age, glasses, expression, mouth mask, and beard
AI Search
Search for pictures by channel, time and face attributes
SMD Plus by Camera
Performance
8 channels
AI Search
Search by target classification (human, vehicle)
Video
Access Channel
8
Network Bandwidth
Access: 80 Mbps; Storage: 80 Mbps; Forward: 60 Mbps
Resolution
8MP; 6MP; 5MP; 4MP; 3MP; 1080p; 720p; D1
Decoding Capability
8 × 1080p@30 fps
Video Output
1 × VGA output, 1 × HDMI output, supports simultaneous video sources output for VGA and HDMI
Multi-screen Display
1, 4, 8, 9 views
Third-party Camera Access
ONVIF; RTSP
Compression
Video
Smart H.265/H.265/Smart H.264/H.264/MJPEG
Audio
PCM/G711A/G711U/G726/AAC
Network
Network Protocol
HTTP; HTTPS; TCP/IP; IPv4/IPv6; UPnP; SNMP; RTSP; UDP; SMTP; NTP; DHCP; DNS; IP Filter; DDNS; FTP; Alarm Server; IP Search (Support Dahua IP camera; DVR; NVS; etc.); P2P; auto register
Mobile Phone Access
Android; iOS
Interoperability
ONVIF(profile T/S/G); CGI; SDK
Browser
Chrome; IE9 or later; firefox
Record Playback
Multi-channel Playback
Up to 8 channels for playback
Record Mode
Manual record; alarm recording; SMD recording; smart recording
Storage
Local HDD; network
Backup
USB storage device
Playback Function
1. Play/pause/stop/slow/quick/backward/by frame
2. Full screen, backup (video clip/file), partial zoom in, and audio on/offStorage
Disk Group
Yes
Alarm
General Alarm
Motion detection, privacy masking, video loss, scene changing, PIR alarm, IPC external alarm
Anomaly Alarm
Camera disconnection, storage error, disk full, IP conflict, MAC conflict, login locked, and cybersecurity exception
Intelligent Alarm
Face detection, perimeter protection (intrusion and tripwire), IVS, people counting, heat map, and SMD alarms
Alarm Linkage
Recording, snapshot, audio, buzzer, log, preset, and email
External Port
Audio Input
1 × RCA input
Audio Output
1 × RCA output
HDD
1 SATA III ports, up to 10 TB for a single HDD. The maximum HDD capacity varies with environment temperature
USB
2 (2 × back USB2.0)
HDMI
1 (supports up to 4K resolution output)
VGA
1
Network
1 × RJ-45, 10/100 Mbps self-adaptive Ethernet port
POE
8
General Parameter
Power Supply
DC48V/53V, 2A/1.8A
Power Consumption
< 10 W (HDD not included, idling) Total output power of PoE is 72W, the maximum output power of a single port is 25.5W Net Weight 0.70 kg (1.54 lb) Gross Weight 1.80 kg (3.97 lb Product Dimensions 270 mm × 206.5 mm × 47.5 mm (10.63** × 8.13** × 1.87**) (W × L × H) Package Dimensions 96 mm × 427 mm × 262 mm (3.78** × 16.81** × 10.31**) (W × L × H) Operating Conditions –10 °C to +50 °C (+10 °F to +122 °F) Storage Conditions 0 °C to +40 °C (32 °F to 104 °F) Operating Humidity 10**~93** Storage Humidity 30%~85% Operating Altitude 3000 m (9842.52 ft) Installation Desktop mounted Certifications CE: EN62368-1; EN55032,EN55024, EN55035, EN61000-3-2, EN61000-3-3 EN50130-4 FCC: Part 15 Subpart
-
Dahua 8 Channels NVR – Kenya
KSh30,000.00Add to cartDahua 8 Channels NVR
Dahua 8 Channels NVR is efficient ultra HD IP Surveillance Systems. it delivers a wealth of cutting-edge attributes including support for up to 12 mp video recording and playback to an integrated 8 Port PoE Network it boasts of the latest compression method H.265+. it provides unparalleled bandwidth and storage efficiency.
Dahua NVR (NVR4208-8P) high-performance NVR is designed to support cameras of a wide range of brands and types. Not only that, the ONVIF version 2.3 conformance makes it highly interoperable. Adding to the convenience are the convenient monitoring options that this recorder has to offer. NVR4208-8P NVR can make use of network monitoring through web viewer, CMS(DSS/PSS) & DMSS. This device also scores high in the storage department. With the two Sata HDDs, it offers a capacity of up to 8TB.
Dahua NVR4208-8P 8 Channel H.264/MJPEG Real-Time Network Video Recorder to give the right leverage to your surveillance system. NVR4208-8P 8 Channel NVR is designed to deliver exceptional performance, this DVR offers 8 channels with 1080P real-time live view. With up to 5 MP resolution for preview and playback, it is an excellent addition to your security system. T he H2.64/MJPEG dual codec comes in really handy for restricting storage and bandwidth needs.
Dahua NVR (NVR4208-8P) Specifications
System
Main Processor Quad-core embedded processor
Operating System Embedded LINUX
Aduio and Video
IP Camera Input 8 Channel
Two-way Talk 1 Channel Input, 1 Channel Output, RCA
Display
Interface 1 HDMI, 1 VGA
Resolution HDMI: 3840×2160, 1920×1080, 1280×1024, 1280×720
VGA: 1920×1080, 1280×1024, 1280×720
Decoding Capacity 2ch@4K 30fps, 8ch@1080P 30fps
Multi-screen Display 1/4/8/9
OSD Camera title, Time, Camera lock, Motion detection, Recording
Recording
Compression Smart H.265+/H.265/Smart H.264+/H.264
Resolution 8Mp/ 6Mp/ 5MP/ 4MP/ 3MP/ 1080P/ 1.3MP/ 720P etc.
Record Rate 200Mbps
Bit Rate 16Kbps ~ 20Mbps Per Channel
Record Mode Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Tampering, Video Loss), Stop
Record Interval 1 ~ 120 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec
Video Detection and Alarm
Trigger Events Recording, PTZ, Tour, Video Push, Email, Snapshot, Buzzer and Screen Tips
Video Detection Motion Detection, MD Zones: 396 (22 × 18), Video Loss and Tampering
Alarm input 4 Channel
Alarm output 1-Channel relay output,1-Channel 12V control
Playback and Backup
Playback 1/4/9
Search Mode Time /Date, MD and Exact Search (accurate to second), Smart search
Playback Function Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Backup Selection, Digital Zoom
Backup Mode USB Device/Network
Third-party Support
Third-party Support Arecont Vision, Airlive, AXIS, Canon, Dynacolor, JVC, LG, Panasonic, Pelco, PSIA, Samsung, Sanyo, Sony, Watchnet and more
Network
Interface 1 RJ-45 Port (10/100/1000Mbps)
Ethernet Port 1 Independent 1000Mbps Ethernet Port
PoE 8 ports (IEEE802.3at/af)
Network Function HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE, DDNS, FTP, SNMP, IP Search (Support Dahua IP camera, DVR, NVS, etc.), Easy4ip
Max. User Access 128 users
Smart Phone iPhone, iPad, Android
Interoperability ONVIF 2.4, SDK, CGI
Storage
Internal HDD 2 SATA III Ports, Up to 6 TB capacity for each HDD
HDD Mode Single
Auxiliary Interface
USB 2 ports (1 USB2.0, 1 USB3.0)
RS232 N/A
RS485 N/A
Electrical
Power Supply AC100V ~ 240V, 50 ~ 60 Hz
Power Consumption NVR: < 9.6W(without HDD) PoE: Max 25.5w for single port, 130w in total Environmental Operating Conditions -10°C ~ +55°C (+14°F ~ +131°F), 86 ~ 106kpa Storage Conditions -20°C ~ +70°C (-4°F ~ +158°F), 0 ~ 90% RH Construction Dimensions 1U, 375mm×327.5mm×53mm (14.8** x 12.9** x2.1**) Net Weight 2.6kg (5.7 lb) (without HDD) Gross Weight 4kg(8.8 lb)(without HDD) Certifications CE EN55032, EN55024, EN50130-4, EN60950-1 FCC Part 15 Subpart B, ANSI C63.4-2014 UL UL60950-1 Dahua NVR4208-8P 8 Channel NVR NVR4208-8P Dahua 8 Channel NVR Dahua 8 Channel NVR -
Dahua 8 Channels NVR – Kenya
KSh30,000.00Add to cartDahua 8 Channels NVR
Dahua 8 Channels NVR is efficient ultra HD IP Surveillance Systems. it delivers a wealth of cutting-edge attributes including support for up to 12 mp video recording and playback to an integrated 8 Port PoE Network it boasts of the latest compression method H.265+. it provides unparalleled bandwidth and storage efficiency.
Dahua NVR (NVR4208-8P) high-performance NVR is designed to support cameras of a wide range of brands and types. Not only that, the ONVIF version 2.3 conformance makes it highly interoperable. Adding to the convenience are the convenient monitoring options that this recorder has to offer. NVR4208-8P NVR can make use of network monitoring through web viewer, CMS(DSS/PSS) & DMSS. This device also scores high in the storage department. With the two Sata HDDs, it offers a capacity of up to 8TB.
Dahua NVR4208-8P 8 Channel H.264/MJPEG Real-Time Network Video Recorder to give the right leverage to your surveillance system. NVR4208-8P 8 Channel NVR is designed to deliver exceptional performance, this DVR offers 8 channels with 1080P real-time live view. With up to 5 MP resolution for preview and playback, it is an excellent addition to your security system. T he H2.64/MJPEG dual codec comes in really handy for restricting storage and bandwidth needs.
Dahua NVR (NVR4208-8P) Specifications
System
Main Processor Quad-core embedded processor
Operating System Embedded LINUX
Aduio and Video
IP Camera Input 8 Channel
Two-way Talk 1 Channel Input, 1 Channel Output, RCA
Display
Interface 1 HDMI, 1 VGA
Resolution HDMI: 3840×2160, 1920×1080, 1280×1024, 1280×720
VGA: 1920×1080, 1280×1024, 1280×720
Decoding Capacity 2ch@4K 30fps, 8ch@1080P 30fps
Multi-screen Display 1/4/8/9
OSD Camera title, Time, Camera lock, Motion detection, Recording
Recording
Compression Smart H.265+/H.265/Smart H.264+/H.264
Resolution 8Mp/ 6Mp/ 5MP/ 4MP/ 3MP/ 1080P/ 1.3MP/ 720P etc.
Record Rate 200Mbps
Bit Rate 16Kbps ~ 20Mbps Per Channel
Record Mode Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Tampering, Video Loss), Stop
Record Interval 1 ~ 120 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec
Video Detection and Alarm
Trigger Events Recording, PTZ, Tour, Video Push, Email, Snapshot, Buzzer and Screen Tips
Video Detection Motion Detection, MD Zones: 396 (22 × 18), Video Loss and Tampering
Alarm input 4 Channel
Alarm output 1-Channel relay output,1-Channel 12V control
Playback and Backup
Playback 1/4/9
Search Mode Time /Date, MD and Exact Search (accurate to second), Smart search
Playback Function Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Backup Selection, Digital Zoom
Backup Mode USB Device/Network
Third-party Support
Third-party Support Arecont Vision, Airlive, AXIS, Canon, Dynacolor, JVC, LG, Panasonic, Pelco, PSIA, Samsung, Sanyo, Sony, Watchnet and more
Network
Interface 1 RJ-45 Port (10/100/1000Mbps)
Ethernet Port 1 Independent 1000Mbps Ethernet Port
PoE 8 ports (IEEE802.3at/af)
Network Function HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE, DDNS, FTP, SNMP, IP Search (Support Dahua IP camera, DVR, NVS, etc.), Easy4ip
Max. User Access 128 users
Smart Phone iPhone, iPad, Android
Interoperability ONVIF 2.4, SDK, CGI
Storage
Internal HDD 2 SATA III Ports, Up to 6 TB capacity for each HDD
HDD Mode Single
Auxiliary Interface
USB 2 ports (1 USB2.0, 1 USB3.0)
RS232 N/A
RS485 N/A
Electrical
Power Supply AC100V ~ 240V, 50 ~ 60 Hz
Power Consumption NVR: < 9.6W(without HDD) PoE: Max 25.5w for single port, 130w in total Environmental Operating Conditions -10°C ~ +55°C (+14°F ~ +131°F), 86 ~ 106kpa Storage Conditions -20°C ~ +70°C (-4°F ~ +158°F), 0 ~ 90% RH Construction Dimensions 1U, 375mm×327.5mm×53mm (14.8** x 12.9** x2.1**) Net Weight 2.6kg (5.7 lb) (without HDD) Gross Weight 4kg(8.8 lb)(without HDD) Certifications CE EN55032, EN55024, EN50130-4, EN60950-1 FCC Part 15 Subpart B, ANSI C63.4-2014 UL UL60950-1 Dahua NVR4208-8P 8 Channel NVR NVR4208-8P Dahua 8 Channel NVR Dahua 8 Channel NVR -
Add to cartDahua 8 MP, Dahua DH IPC HFW1831EP WDR IR Network Camera
Camera
Image Sensor
1/1.8” 8Megapixel progressive scan CMOS
Effective Pixels
3840(H) x 2160(V)
RAM/ROM
512MB/128MB
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual, 1/3(4)~1/100000s
Minimum Illumination
0.003Lux/F1.6( Color,1/3s,30IRE)
0.08Lux/F1.6( Color,1/30s,30IRE)
0Lux/F1.6(IR on)
S/N Ratio
More than 50dB
IR Distance
Distance up to 50m (164ft)
IR On/Off Control
Auto/ Manual
IR LEDs
2
Lens
Lens Type
Fixed
Mount Type
Board-in
Focal Length
2.8mm (4mm, 6mm optional)
Max. Aperture
F1.6
Angle of View
H:111°/87°/55°, V:59°/47°/30°
Optical Zoom
N/A
Focus Control
Fixed
Close Focus Distance
1.5m (16.4ft)
DORI Distance
Lens
Detect
Observe
Recognize
Identify
2.8mm
84m(276ft)
34m(112ft)
17m(56ft)
8m(26ft)
4.0 mm
104m(341ft)
42m(138ft)
21m(69ft)
10m(33ft)
6.0 mm
164m(538ft)
66m(217ft)
33m(108ft)
16m(53ft)
PTZ
Pan/Tilt/Rotation Range
Pan:0**~355**; Tilt:0**~90**; Rotation:0**~355**
Intelligence
Event Trigger
Motion detection, Video tampering, Scene changing, Network disconnection, IP address conflict, Illegal access, Storage anomaly
IVS
Tripwire, Intrusion
Video
Compression
H.265/H.264H/MJPEG(Sub Stream)
Smart Codec
Support H.265+/H.264+
Streaming Capability
2 Streams
Resolution
4K(3840×2160)/6M(3072×2048)/5M(2560×1920)/
3M(2048×1536)/3M(2304×1296)/
1080P(1920×1080)/1.3M(1280×960)/
720P(1280×720)/D1(704×576/704×480) /VGA(640×480)/CIF(352×288/352×240)
Frame Rate
Main Stream: 4K (1~25/30fps)
Sub Stream: D1(1~25/30fps)
Bit Rate Control
CBR/VBR
Bit Rate
H.264:24K ~ 8192Kbps
H.265:32K~ 8192Kbps
Day/Night
Auto(ICR) / Color / B/W
BLC Mode
BLC / HLC / WDR(120dB)
White Balance
Auto/Natural/Street Lamp/Outdoor/Manual
Gain Control
Auto/Manual
Noise Reduction
3D DNR
Motion Detection
Off / On (4 Zone, Rectangle)
Region of Interest
Off / On (4 Zone)
Electronic Image Stabilization (EIS)
N/A
Smart IR
Support
Defog
N/A
Digital Zoom
16x
Flip
0°/90°/180°/270°
Mirror
Off / On
Privacy Masking
Off / On (4 Area, Rectangle)
Audio
Compression
N/A
Network
Ethernet
RJ-45 (10/100Base-T)
Protocol
HTTP;TCP;ARP;RTSP;RTP;UDP;RTCP;SMTP;FTP;DHCP;DNS;DDNS;PPPOE;IPv4/v6;SNMP;QoS;UPnP;NTP
Interoperability
ONVIF Profile S&G, CGI
Streaming Method
Unicast / Multicast
Max. User Access
10 Users /20 Users
Edge Storage
NAS
Local PC for instant recording
Web Viewer
IE, Chrome, Firefox, Safari
Management Software
Smart PSS, DSS, DMSS
Smart Phone
IOS, Android
Certifications
Certifications
CE (EN 60950:2000)
UL:UL60950-1
FCC: FCC Part 15 Subpart B
Interface
Video Interface
N/A
Audio Interface
N/A
RS485
N/A
Alarm
N/A
Electrical
Power Supply
DC12V, PoE (IEEE802.3af)(Class 0)
Power Consumption
<7.8W Environmental Operating Conditions -30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH Storage Conditions -30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH Ingress Protection IP67 Vandal Resistance N/A Construction Casing Metal Dimensions 179.9mm×69.3mm×62mm (7.08”×2.73”×2.44”) Net Weight 0.48kg (1.06lb) Gross Weight 0.51 kg (1.12lb)
-
Add to cart
Dahua 8 MP, Dahua DH IPC HFW1831EP WDR IR Network Camera
Camera
Image Sensor
1/1.8” 8Megapixel progressive scan CMOS
Effective Pixels
3840(H) x 2160(V)
RAM/ROM
512MB/128MB
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual, 1/3(4)~1/100000s
Minimum Illumination
0.003Lux/F1.6( Color,1/3s,30IRE)
0.08Lux/F1.6( Color,1/30s,30IRE)
0Lux/F1.6(IR on)
S/N Ratio
More than 50dB
IR Distance
Distance up to 50m (164ft)
IR On/Off Control
Auto/ Manual
IR LEDs
2
Lens
Lens Type
Fixed
Mount Type
Board-in
Focal Length
2.8mm (4mm, 6mm optional)
Max. Aperture
F1.6
Angle of View
H:111°/87°/55°, V:59°/47°/30°
Optical Zoom
N/A
Focus Control
Fixed
Close Focus Distance
1.5m (16.4ft)
DORI Distance
Lens
Detect
Observe
Recognize
Identify
2.8mm
84m(276ft)
34m(112ft)
17m(56ft)
8m(26ft)
4.0 mm
104m(341ft)
42m(138ft)
21m(69ft)
10m(33ft)
6.0 mm
164m(538ft)
66m(217ft)
33m(108ft)
16m(53ft)
PTZ
Pan/Tilt/Rotation Range
Pan:0**~355**; Tilt:0**~90**; Rotation:0**~355**
Intelligence
Event Trigger
Motion detection, Video tampering, Scene changing, Network disconnection, IP address conflict, Illegal access, Storage anomaly
IVS
Tripwire, Intrusion
Video
Compression
H.265/H.264H/MJPEG(Sub Stream)
Smart Codec
Support H.265+/H.264+
Streaming Capability
2 Streams
Resolution
4K(3840×2160)/6M(3072×2048)/5M(2560×1920)/
3M(2048×1536)/3M(2304×1296)/
1080P(1920×1080)/1.3M(1280×960)/
720P(1280×720)/D1(704×576/704×480) /VGA(640×480)/CIF(352×288/352×240)
Frame Rate
Main Stream: 4K (1~25/30fps)
Sub Stream: D1(1~25/30fps)
Bit Rate Control
CBR/VBR
Bit Rate
H.264:24K ~ 8192Kbps
H.265:32K~ 8192Kbps
Day/Night
Auto(ICR) / Color / B/W
BLC Mode
BLC / HLC / WDR(120dB)
White Balance
Auto/Natural/Street Lamp/Outdoor/Manual
Gain Control
Auto/Manual
Noise Reduction
3D DNR
Motion Detection
Off / On (4 Zone, Rectangle)
Region of Interest
Off / On (4 Zone)
Electronic Image Stabilization (EIS)
N/A
Smart IR
Support
Defog
N/A
Digital Zoom
16x
Flip
0°/90°/180°/270°
Mirror
Off / On
Privacy Masking
Off / On (4 Area, Rectangle)
Audio
Compression
N/A
Network
Ethernet
RJ-45 (10/100Base-T)
Protocol
HTTP;TCP;ARP;RTSP;RTP;UDP;RTCP;SMTP;FTP;DHCP;DNS;DDNS;PPPOE;IPv4/v6;SNMP;QoS;UPnP;NTP
Interoperability
ONVIF Profile S&G, CGI
Streaming Method
Unicast / Multicast
Max. User Access
10 Users /20 Users
Edge Storage
NAS
Local PC for instant recording
Web Viewer
IE, Chrome, Firefox, Safari
Management Software
Smart PSS, DSS, DMSS
Smart Phone
IOS, Android
Certifications
Certifications
CE (EN 60950:2000)
UL:UL60950-1
FCC: FCC Part 15 Subpart B
Interface
Video Interface
N/A
Audio Interface
N/A
RS485
N/A
Alarm
N/A
Electrical
Power Supply
DC12V, PoE (IEEE802.3af)(Class 0)
Power Consumption
<7.8W Environmental Operating Conditions -30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH Storage Conditions -30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH Ingress Protection IP67 Vandal Resistance N/A Construction Casing Metal Dimensions 179.9mm×69.3mm×62mm (7.08”×2.73”×2.44”) Net Weight 0.48kg (1.06lb) Gross Weight 0.51 kg (1.12lb)
-
Add to cartDahua 8GB Flash Drive USB 2.0 – U106
The Dahua 8GB Flash Drive, model DHI-USB-U106-20-8GB, is a practical and reliable storage solution designed for everyday use. With 8GB of capacity, this compact flash drive provides sufficient space to store and transfer essential files, including documents, photos, and videos.
Equipped with a USB 2.0 interface, the drive offers read speeds of up to 12 MB/s and write speeds of up to 5 MB/s, allowing for efficient data transfers between devices. Its USB Type-A connector is compatible with a wide range of PCs and laptops, and is backward compatible with older USB 1.1 ports, ensuring versatility in various computing environments.
The Dahua flash drive features a durable plastic body and a metal connector, designed to withstand regular use and provide reliable performance. Its compact size and lightweight design make it highly portable, easily fitting into your pocket, bag, or on a keychain.
A built-in LED indicator offers visual feedback during data transfers, helping you monitor the status of your files. With plug-and-play functionality, the drive requires no additional drivers or software, making it easy to use right out of the box.
Operating within a temperature range of 0°C to 60°C (32°F to 140°F) and capable of withstanding storage temperatures from -20°C to 70°C (-4°F to 158°F), the Dahua 8GB Flash Drive is built to perform reliably in various conditions.
Ideal for users seeking a straightforward and dependable flash drive for everyday file storage and transfer, the Dahua DHI-USB-U106-20-8GB is backed by a limited warranty, ensuring durability and peace of mind.
Technical Speci**cation
Product Model
DHI-USB-U106-20-8GB
DHI-USB-U106-20-16GB
DHI-USB-U106-20-32GB
DHI-USB-U106-20-64GB
Interface
USB2.0
Capacity
8 GB
16 GB
32 GB
64 GB
Read Speed
10–25 MB/s
Write Speed
3–10 MB/s
File System
FAT32
FAT32
FAT32
exFAT
Operating Temperature
0°C to 60°C (32°F to 140°F)
Storage Temperature
-20°C to 70°C (-4°F to 158°F)
Compatible System
Windows 7/8/10; macOS10.15 and later versions; Linux 2.4.x and later versions
Max Operating Voltage
5V
Max Operating Current
150mA
Warranty
5-year limited warranty
Product Dimensions
40.4 mm × 12.25 mm × 4.65 mm (1.59** × 0.48** × 0.18**)
Packaging Dimensions
100 mm × 132 mm × 5.6 mm (3.94** × 5.20** × 0.22**)
Net Weight
About 5.7g
Gross Weight
About 14.2g
Reference Information
1. The capacity written on the product and package is nominal capacity.
2. 1 GB = 1 billion bytes, and the nominal capacity is not all for data storage. According to internal testing, the transmission speed varies with the devices, ports, environments, and other factors. -
Add to cart
Dahua 8GB Flash Drive USB 2.0 – U106
The Dahua 8GB Flash Drive, model DHI-USB-U106-20-8GB, is a practical and reliable storage solution designed for everyday use. With 8GB of capacity, this compact flash drive provides sufficient space to store and transfer essential files, including documents, photos, and videos.
Equipped with a USB 2.0 interface, the drive offers read speeds of up to 12 MB/s and write speeds of up to 5 MB/s, allowing for efficient data transfers between devices. Its USB Type-A connector is compatible with a wide range of PCs and laptops, and is backward compatible with older USB 1.1 ports, ensuring versatility in various computing environments.
The Dahua flash drive features a durable plastic body and a metal connector, designed to withstand regular use and provide reliable performance. Its compact size and lightweight design make it highly portable, easily fitting into your pocket, bag, or on a keychain.
A built-in LED indicator offers visual feedback during data transfers, helping you monitor the status of your files. With plug-and-play functionality, the drive requires no additional drivers or software, making it easy to use right out of the box.
Operating within a temperature range of 0°C to 60°C (32°F to 140°F) and capable of withstanding storage temperatures from -20°C to 70°C (-4°F to 158°F), the Dahua 8GB Flash Drive is built to perform reliably in various conditions.
Ideal for users seeking a straightforward and dependable flash drive for everyday file storage and transfer, the Dahua DHI-USB-U106-20-8GB is backed by a limited warranty, ensuring durability and peace of mind.
Technical Speci**cation
Product Model
DHI-USB-U106-20-8GB
DHI-USB-U106-20-16GB
DHI-USB-U106-20-32GB
DHI-USB-U106-20-64GB
Interface
USB2.0
Capacity
8 GB
16 GB
32 GB
64 GB
Read Speed
10–25 MB/s
Write Speed
3–10 MB/s
File System
FAT32
FAT32
FAT32
exFAT
Operating Temperature
0°C to 60°C (32°F to 140°F)
Storage Temperature
-20°C to 70°C (-4°F to 158°F)
Compatible System
Windows 7/8/10; macOS10.15 and later versions; Linux 2.4.x and later versions
Max Operating Voltage
5V
Max Operating Current
150mA
Warranty
5-year limited warranty
Product Dimensions
40.4 mm × 12.25 mm × 4.65 mm (1.59** × 0.48** × 0.18**)
Packaging Dimensions
100 mm × 132 mm × 5.6 mm (3.94** × 5.20** × 0.22**)
Net Weight
About 5.7g
Gross Weight
About 14.2g
Reference Information
1. The capacity written on the product and package is nominal capacity.
2. 1 GB = 1 billion bytes, and the nominal capacity is not all for data storage. According to internal testing, the transmission speed varies with the devices, ports, environments, and other factors. -
Add to cartDahua Access Control DHI-ASI 1212A (V2) Fingerprint Standalone
The Dahua DHI-ASI 1212A (V2) Fingerprint Standalone Access Control is a highly efficient and secure biometric access control solution designed to enhance security for a wide range of applications. It combines advanced optical fingerprint recognition with RFID card and PIN authentication methods, offering a multi-layered approach to user identification and entry access.
The device features a high-resolution optical fingerprint sensor, capable of storing up to 3,000 fingerprints, ensuring quick and accurate identification. It also supports 10,000 RFID cards (EM 125kHz), making it ideal for both small and medium-sized installations. In addition to the fingerprint and card-based access, the device allows for PIN authentication, offering flexibility in access control for users.
Equipped with a 2.8-inch color LCD display and an integrated numeric keypad, the DHI-ASI 1212A (V2) provides an intuitive interface for users to input their credentials and view system status. Its authentication speed is less than 1 second per fingerprint, ensuring fast and seamless access while maintaining high security.
The device’s log capacity of up to 100,000 records allows for comprehensive monitoring and tracking of access events, which is ideal for managing access in larger facilities. The device supports TCP/IP, RS-485, and Wiegand interfaces, offering seamless integration with other access control systems and networks.
The DHI-ASI 1212A (V2) is designed with robust security features, including anti-spoofing technology, which prevents unauthorized access through fake fingerprints. It also has an integrated relay output for controlling door locks and an alarm function for unauthorized access attempts, further enhancing its security capabilities.
With its versatile installation options and PoE support, the device is easy to set up and deploy in various environments. It operates in temperatures ranging from -20°C to +60°C, making it suitable for both indoor and outdoor use. This makes it a perfect solution for offices, factories, residential buildings, and other facilities looking to secure their premises with reliable and efficient access control technology.
-
Add to cart
Dahua Access Control DHI-ASI 1212A (V2) Fingerprint Standalone
The Dahua DHI-ASI 1212A (V2) Fingerprint Standalone Access Control is a highly efficient and secure biometric access control solution designed to enhance security for a wide range of applications. It combines advanced optical fingerprint recognition with RFID card and PIN authentication methods, offering a multi-layered approach to user identification and entry access.
The device features a high-resolution optical fingerprint sensor, capable of storing up to 3,000 fingerprints, ensuring quick and accurate identification. It also supports 10,000 RFID cards (EM 125kHz), making it ideal for both small and medium-sized installations. In addition to the fingerprint and card-based access, the device allows for PIN authentication, offering flexibility in access control for users.
Equipped with a 2.8-inch color LCD display and an integrated numeric keypad, the DHI-ASI 1212A (V2) provides an intuitive interface for users to input their credentials and view system status. Its authentication speed is less than 1 second per fingerprint, ensuring fast and seamless access while maintaining high security.
The device’s log capacity of up to 100,000 records allows for comprehensive monitoring and tracking of access events, which is ideal for managing access in larger facilities. The device supports TCP/IP, RS-485, and Wiegand interfaces, offering seamless integration with other access control systems and networks.
The DHI-ASI 1212A (V2) is designed with robust security features, including anti-spoofing technology, which prevents unauthorized access through fake fingerprints. It also has an integrated relay output for controlling door locks and an alarm function for unauthorized access attempts, further enhancing its security capabilities.
With its versatile installation options and PoE support, the device is easy to set up and deploy in various environments. It operates in temperatures ranging from -20°C to +60°C, making it suitable for both indoor and outdoor use. This makes it a perfect solution for offices, factories, residential buildings, and other facilities looking to secure their premises with reliable and efficient access control technology.
-
Dahua ASI1212D Standalone Fingerprint reader – Kenya
KSh17,000.00Add to cartDahua ASI1212D Standalone Fingerprint reader
The Dahua ASI1212D Standalone Fingerprint Reader is a high-performance access control device designed to provide secure and efficient fingerprint authentication. Ideal for businesses, offices, and residential settings, this standalone reader can store up to 3,000 fingerprints and handle up to 30,000 transaction logs, ensuring robust performance for mid-sized to large installations.
This device utilizes optical fingerprint recognition technology with a 500 DPI resolution, ensuring quick and accurate identification. With multi-factor authentication options, users can choose to secure access using only fingerprints, or combine it with an optional RFID card for added security.
The 2.4-inch color LCD screen and LED indicators offer intuitive feedback, making setup and operation straightforward. The ASI1212D features TCP/IP communication for remote management and Wiegand output for integration with other access control systems. It operates on 12V DC power and is designed for easy wall-mount installation in a variety of environments.
Designed with anti-spoofing technology and encryption, it ensures a high level of security, protecting sensitive user data. The compact and sleek design allows it to fit seamlessly into any access control setup. Whether used as a standalone solution or integrated into a larger system, the Dahua ASI1212D provides a reliable, high-security solution for modern access control needs.
-
Dahua ASI1212D Standalone Fingerprint reader – Kenya
KSh17,000.00Add to cartDahua ASI1212D Standalone Fingerprint reader
The Dahua ASI1212D Standalone Fingerprint Reader is a high-performance access control device designed to provide secure and efficient fingerprint authentication. Ideal for businesses, offices, and residential settings, this standalone reader can store up to 3,000 fingerprints and handle up to 30,000 transaction logs, ensuring robust performance for mid-sized to large installations.
This device utilizes optical fingerprint recognition technology with a 500 DPI resolution, ensuring quick and accurate identification. With multi-factor authentication options, users can choose to secure access using only fingerprints, or combine it with an optional RFID card for added security.
The 2.4-inch color LCD screen and LED indicators offer intuitive feedback, making setup and operation straightforward. The ASI1212D features TCP/IP communication for remote management and Wiegand output for integration with other access control systems. It operates on 12V DC power and is designed for easy wall-mount installation in a variety of environments.
Designed with anti-spoofing technology and encryption, it ensures a high level of security, protecting sensitive user data. The compact and sleek design allows it to fit seamlessly into any access control setup. Whether used as a standalone solution or integrated into a larger system, the Dahua ASI1212D provides a reliable, high-security solution for modern access control needs.
-
Add to cartDahua ASI3213G-MW Access control reader – User data can be stored at the access controller, can hold 1500, face images, and work without network Key features 4.3 inch LCD touch screen; resolution 480×272 With a 2 MP wide-angle dual lens, white fill light, IR light Support face, card, and password unlock; unlock by period User data can be stored at the access controller; can hold 1500 face images and work without network Face-camera distance: 0.3m-1.5m Face verification accuracy 99.5%; face comparison speed 0.3s per person; low false recognition rate Support liveness detection
-
Add to cartDAHUA ASR1101A – Reader for MIFARE and PASSWORD cards
The Dahua ASR1101A is a compact and versatile card reader designed to provide secure access control in residential, commercial, and industrial environments. Supporting MIFARE cards and password-based authentication, it offers flexible access methods, ensuring enhanced security and convenience for users. Its touch-sensitive keypad allows for standalone password entry or a combination of card and password for dual-factor authentication.
Built for durability, the ASR1101A features a rugged housing with an IP55 rating, making it suitable for both indoor and outdoor applications. With a reading range of 3–5 cm and a fast response time of under 0.1 seconds, it ensures efficient and seamless operation. The device integrates seamlessly with Dahua systems or third-party setups via RS-485 and Wiegand protocols, offering compatibility and adaptability to various security frameworks.
Equipped with LED indicators and an audible buzzer, the Dahua ASR1101A provides clear feedback during operation. Its tamper detection feature adds an additional layer of protection against unauthorized handling. Designed for environments with temperatures ranging from -30°C to +60°C, it performs reliably even under challenging conditions.
The Dahua ASR1101A is an ideal solution for businesses and homeowners seeking a reliable, high-security access control device with advanced features and robust performance.
-
Add to cart
DAHUA ASR1101A – Reader for MIFARE and PASSWORD cards
The Dahua ASR1101A is a compact and versatile card reader designed to provide secure access control in residential, commercial, and industrial environments. Supporting MIFARE cards and password-based authentication, it offers flexible access methods, ensuring enhanced security and convenience for users. Its touch-sensitive keypad allows for standalone password entry or a combination of card and password for dual-factor authentication.
Built for durability, the ASR1101A features a rugged housing with an IP55 rating, making it suitable for both indoor and outdoor applications. With a reading range of 3–5 cm and a fast response time of under 0.1 seconds, it ensures efficient and seamless operation. The device integrates seamlessly with Dahua systems or third-party setups via RS-485 and Wiegand protocols, offering compatibility and adaptability to various security frameworks.
Equipped with LED indicators and an audible buzzer, the Dahua ASR1101A provides clear feedback during operation. Its tamper detection feature adds an additional layer of protection against unauthorized handling. Designed for environments with temperatures ranging from -30°C to +60°C, it performs reliably even under challenging conditions.
The Dahua ASR1101A is an ideal solution for businesses and homeowners seeking a reliable, high-security access control device with advanced features and robust performance.
-
Dahua C800N 1TB Internal SSD – M.2 SATA III Soft State Drive (DHI-SSD-C800N1TB) – Kenya
KSh11,000.00Add to cartDahua C800N 1TB Internal SSD – M.2 SATA III Soft State Drive (DHI-SSD-C800N1TB) Key Features High-Speed Performance: Utilizes the SATA III 6Gbps interface, providing faster read and write speeds compared to traditional HDDs. Capacity: 1TB storage capacity, ideal for large files, operating systems, applications, and gaming libraries. Reliable 3D NAND Technology: 3D NAND Flash technology enhances durability and efficiency, ensuring long-term stability and reliability. Compact M.2 Form Factor: Compact M.2 2280 form factor, suitable for ultra-thin laptops, desktops, and mini-PCs, optimizing space and reducing weight. Enhanced Endurance and Reliability: Built for longevity with an MTBF of up to 1.5 million hours, delivering consistent performance under heavy usage. Low Power Consumption: Energy-efficient design, ideal for mobile devices and power-sensitive systems. Advanced Data Protection: Features error correction technologies to prevent data loss or corruption, enhancing data integrity and security. Shock and Vibration Resistant: Designed to withstand physical shock and vibrations, increasing reliability, especially in portable devices.
-
Add to cartDAHUA CAMERAS Dahua DH-IPC-HFW3441EP-AS-0280B 4MP Bullet Network camera
Camera
Image Sensor
1/3”4Megapixel progressive CMOS
Max. Resolution
2688 (H) ×1520 (V)
ROM
128 MB
RAM
512 MB
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual 1/3 s–1/100000 s
Min. Illumination
0.005 Lux@F1.6 (Color, 30IRE)
0.0005 Lux@F1.6 (B/W, 30IRE)
0 Lux (Illuminator on)
S/N Ratio
> 56 dB
Illumination Distance
50 m (164.0 ft)
Illuminator On/Off Control
Auto/Manual
Illuminator Number
1 (IR LED)
Pan/Tilt/Rotation Range
Pan: 0°–360°; Tilt: 0°–90°; Rotation: 0°–360°
Lens
Lens Type
Fixed-focal
Mount Type
M12
Focal Length
2.8 mm; 3.6 mm; 6 mm
Max. Aperture
F1.6
Field of View
2.8 mm: Horizontal:103°; vertical: 55°; diagonal: 122°
3.6 mm: Horizontal:84°; vertical: 45° ; diagonal: 100°
6 mm: Horizontal:52°; vertical: 28°; diagonal: 61°Iris Type
Fixed
Close Focus Distance
2.8 mm: 0.9 m (3.0 ft)
3.6 mm: 1.6 m (5.3 ft)
6 mm: 3.2 m (10.5 ft)DORI Distance
Lens
Detect
Observe
Recognize
Identify
2.8mm
56.0 m
(183.7 ft)
22.4 m
(73.5 ft)
11.2 m
(36.8 ft)
5.6 m
(18.4 ft)
3.6mm
80.0 m
(262.5 ft)
32.0 m
(105.0 ft)
16.0 m
(52.5 ft)
8.0 m
(26.3 ft)
6mm
120.0 m (393.7 ft)
48.0 m
(157.5 ft)
24.0 m
(78.7 ft)
12.0 m (39.4ft)
Professional, Intelligent
Perimeter Protection
Tripwire; intrusion (Recognition of human and vehicle)
Intelligent Search
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos
Video
Video Compression
H.265; H.264; H.264H; H.264B; MJPEG(only supported
by sub stream)
Smart Codec
Smart H.265+/ Smart H.264+
Video Frame Rate
Main stream (2688 × 1520@1–25/30 fps)
sub stream (704 × 576@1–25 fps/704 × 480@1–30 fps)
third stream (1280 × 720@1–25/30 fps)Stream Capability
3 streams
Resolution
4M (2688 × 1520); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
Bit Rate Control
CBR/VBR
Video Bit Rate
H.264: 3 Kbps–8192 Kbps
H.265: 3 Kbps–8192 KbpsDay/Night
Auto(ICR)/Color/B/W
BLC
Yes
HLC
Yes
WDR
120 dB
White Balance
Auto/natural/street lamp/outdoor/manual/regional custom
Gain Control
Auto/Manual
Noise Reduction
3D DNR
Motion Detection
OFF/ON (4 areas, rectangular)
Region of Interest(RoI)
Yes (4 areas)
Smart Illumination
Yes
Image Rotation
0°/90°/180°/270° (Support 90°/270° with 1920 × 1080 resolution and lower.)
Mirror
Yes
Privacy Masking
4 areas
Audio
Built-in MIC
Yes
Audio Compression
G.711a; G.711Mu; G726
Alarm
Alarm Event
No SD card; SD card full; SD card error; less service time of SD card (smart card supports); network disconnection; IP conflict; illegal access; voltage detection; security exception; motion detection; video tampering; scene changing; input abnormal; intensity change; tripwire; intrusion; SMD
Network
Network
RJ-45 (10/100 Base-T)
SDK and API
Yes
Protocol
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; SNMP
Cyber Security
Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade
Interoperability
ONVIF(Profile S/Profile G/Profile T);CGI;P2P;Milestone;
Genetec
Scene Self-adaptation (SSA)
Yes
User/Host
20 (Total bandwidth: 64 M)
Storage
FTP; SFTP; Micro SD Card (support max. 256 G); NAS
Browser
IE: IE8, IE9, IE11
Chrome
Firefox
Management Software
Smart PSS, DSS, DMSS
Mobile Phone
IOS; Android
Certification
Certifications
CE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07Port
Audio Input
1-channel (RCA port)
Audio Output
1-channel (RCA port)
Alarm Input
1 channel in: 5mA 3V–5V DC
Alarm Output
1 channel out: 300mA 12V DC
Power
Power Supply
12V DC/PoE (802.3af)
Power Consumption
<5.4W Environment Operating Conditions -40°C to +60°C (-40°F to +140°F)/less than 95% Storage Conditions -40°C to +60°C (-40°F to +140°F) Protection Grade IP67 Structure Casing Metal Dimensions 192.7 mm × 70.5 mm × 66.4 mm (7.6”×2.8”×2.6”) (L × W × H) Net Weight 590 g (1.3lb) Gross Weight 780 g (1.7lb)
-
Add to cart
DAHUA CAMERAS Dahua DH-IPC-HFW3441EP-AS-0280B 4MP Bullet Network camera
Camera
Image Sensor
1/3”4Megapixel progressive CMOS
Max. Resolution
2688 (H) ×1520 (V)
ROM
128 MB
RAM
512 MB
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual 1/3 s–1/100000 s
Min. Illumination
0.005 Lux@F1.6 (Color, 30IRE)
0.0005 Lux@F1.6 (B/W, 30IRE)
0 Lux (Illuminator on)
S/N Ratio
> 56 dB
Illumination Distance
50 m (164.0 ft)
Illuminator On/Off Control
Auto/Manual
Illuminator Number
1 (IR LED)
Pan/Tilt/Rotation Range
Pan: 0°–360°; Tilt: 0°–90°; Rotation: 0°–360°
Lens
Lens Type
Fixed-focal
Mount Type
M12
Focal Length
2.8 mm; 3.6 mm; 6 mm
Max. Aperture
F1.6
Field of View
2.8 mm: Horizontal:103°; vertical: 55°; diagonal: 122°
3.6 mm: Horizontal:84°; vertical: 45° ; diagonal: 100°
6 mm: Horizontal:52°; vertical: 28°; diagonal: 61°Iris Type
Fixed
Close Focus Distance
2.8 mm: 0.9 m (3.0 ft)
3.6 mm: 1.6 m (5.3 ft)
6 mm: 3.2 m (10.5 ft)DORI Distance
Lens
Detect
Observe
Recognize
Identify
2.8mm
56.0 m
(183.7 ft)
22.4 m
(73.5 ft)
11.2 m
(36.8 ft)
5.6 m
(18.4 ft)
3.6mm
80.0 m
(262.5 ft)
32.0 m
(105.0 ft)
16.0 m
(52.5 ft)
8.0 m
(26.3 ft)
6mm
120.0 m (393.7 ft)
48.0 m
(157.5 ft)
24.0 m
(78.7 ft)
12.0 m (39.4ft)
Professional, Intelligent
Perimeter Protection
Tripwire; intrusion (Recognition of human and vehicle)
Intelligent Search
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos
Video
Video Compression
H.265; H.264; H.264H; H.264B; MJPEG(only supported
by sub stream)
Smart Codec
Smart H.265+/ Smart H.264+
Video Frame Rate
Main stream (2688 × 1520@1–25/30 fps)
sub stream (704 × 576@1–25 fps/704 × 480@1–30 fps)
third stream (1280 × 720@1–25/30 fps)Stream Capability
3 streams
Resolution
4M (2688 × 1520); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
Bit Rate Control
CBR/VBR
Video Bit Rate
H.264: 3 Kbps–8192 Kbps
H.265: 3 Kbps–8192 KbpsDay/Night
Auto(ICR)/Color/B/W
BLC
Yes
HLC
Yes
WDR
120 dB
White Balance
Auto/natural/street lamp/outdoor/manual/regional custom
Gain Control
Auto/Manual
Noise Reduction
3D DNR
Motion Detection
OFF/ON (4 areas, rectangular)
Region of Interest(RoI)
Yes (4 areas)
Smart Illumination
Yes
Image Rotation
0°/90°/180°/270° (Support 90°/270° with 1920 × 1080 resolution and lower.)
Mirror
Yes
Privacy Masking
4 areas
Audio
Built-in MIC
Yes
Audio Compression
G.711a; G.711Mu; G726
Alarm
Alarm Event
No SD card; SD card full; SD card error; less service time of SD card (smart card supports); network disconnection; IP conflict; illegal access; voltage detection; security exception; motion detection; video tampering; scene changing; input abnormal; intensity change; tripwire; intrusion; SMD
Network
Network
RJ-45 (10/100 Base-T)
SDK and API
Yes
Protocol
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; SNMP
Cyber Security
Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade
Interoperability
ONVIF(Profile S/Profile G/Profile T);CGI;P2P;Milestone;
Genetec
Scene Self-adaptation (SSA)
Yes
User/Host
20 (Total bandwidth: 64 M)
Storage
FTP; SFTP; Micro SD Card (support max. 256 G); NAS
Browser
IE: IE8, IE9, IE11
Chrome
Firefox
Management Software
Smart PSS, DSS, DMSS
Mobile Phone
IOS; Android
Certification
Certifications
CE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07Port
Audio Input
1-channel (RCA port)
Audio Output
1-channel (RCA port)
Alarm Input
1 channel in: 5mA 3V–5V DC
Alarm Output
1 channel out: 300mA 12V DC
Power
Power Supply
12V DC/PoE (802.3af)
Power Consumption
<5.4W Environment Operating Conditions -40°C to +60°C (-40°F to +140°F)/less than 95% Storage Conditions -40°C to +60°C (-40°F to +140°F) Protection Grade IP67 Structure Casing Metal Dimensions 192.7 mm × 70.5 mm × 66.4 mm (7.6”×2.8”×2.6”) (L × W × H) Net Weight 590 g (1.3lb) Gross Weight 780 g (1.7lb)
-
Dahua CAT6 UTP 305m Cable , PFM920I-6UN-C/U – Kenya
KSh16,500.00Add to cartDahua UTP CAT6 Cable 305m PFM920I-6UN-C/U
The Dahua CAT6 UTP 305m Cable (PFM920I-6UN-C/U) is a high-performance networking solution designed to meet the demands of modern data transmission applications. With a length of 305 meters, this cable provides ample reach for various installation scenarios, making it ideal for structured cabling systems in commercial and residential environments.
Engineered to support data rates of up to 1 Gbps and bandwidths of 250 MHz, the CAT6 cable ensures fast and reliable connectivity for high-speed internet, VoIP, and video applications. The cable features four pairs of solid copper conductors with a 23 AWG wire gauge, which contribute to reduced crosstalk and enhanced signal integrity. This unshielded twisted pair (UTP) design allows for efficient data transmission, making it suitable for a wide range of indoor networking tasks.
The PVC (Polyvinyl Chloride) jacket not only provides durability but also protects the cable from physical damage and environmental factors, ensuring long-lasting performance. With an operating temperature range of -20°C to 60°C, the Dahua CAT6 UTP cable can perform reliably under various conditions, making it versatile for different installations.
Designed to meet or exceed ANSI/TIA-568-C.2 standards, this cable guarantees compatibility with existing networking infrastructure, facilitating seamless integration into your network setup. The cable is easy to strip and terminate, simplifying the installation process for professionals and DIY enthusiasts alike.
Whether you are upgrading your home network or setting up a robust commercial infrastructure, the Dahua CAT6 UTP 305m Cable provides the speed, reliability, and flexibility needed for today’s demanding networking applications.
-
Dahua CAT6 UTP 305m Cable , PFM920I-6UN-C/U – Kenya
KSh16,500.00Add to cartDahua UTP CAT6 Cable 305m PFM920I-6UN-C/U
The Dahua CAT6 UTP 305m Cable (PFM920I-6UN-C/U) is a high-performance networking solution designed to meet the demands of modern data transmission applications. With a length of 305 meters, this cable provides ample reach for various installation scenarios, making it ideal for structured cabling systems in commercial and residential environments.
Engineered to support data rates of up to 1 Gbps and bandwidths of 250 MHz, the CAT6 cable ensures fast and reliable connectivity for high-speed internet, VoIP, and video applications. The cable features four pairs of solid copper conductors with a 23 AWG wire gauge, which contribute to reduced crosstalk and enhanced signal integrity. This unshielded twisted pair (UTP) design allows for efficient data transmission, making it suitable for a wide range of indoor networking tasks.
The PVC (Polyvinyl Chloride) jacket not only provides durability but also protects the cable from physical damage and environmental factors, ensuring long-lasting performance. With an operating temperature range of -20°C to 60°C, the Dahua CAT6 UTP cable can perform reliably under various conditions, making it versatile for different installations.
Designed to meet or exceed ANSI/TIA-568-C.2 standards, this cable guarantees compatibility with existing networking infrastructure, facilitating seamless integration into your network setup. The cable is easy to strip and terminate, simplifying the installation process for professionals and DIY enthusiasts alike.
Whether you are upgrading your home network or setting up a robust commercial infrastructure, the Dahua CAT6 UTP 305m Cable provides the speed, reliability, and flexibility needed for today’s demanding networking applications.
-
Add to cart>
Meets the requirements of
IEEE802.3,IEEE802.3u,IEEE802.3x,IEEE802.3ab,IEEE802.3z standards.>
Meets the requirements of IEEE802.3af, IEEE802.3at, Hi-PoE, and IEEE802.3bt
power supply standards.>
Manages PoE power consumption and PoE power on/off. Supports Intelligent
PoE.>
A wide operating temperature range and a full metal casing that is
fully-enclosed and dust-proof. -
Add to cart>
Meets the requirements of
IEEE802.3,IEEE802.3u,IEEE802.3x,IEEE802.3ab,IEEE802.3z standards.>
Meets the requirements of IEEE802.3af, IEEE802.3at, Hi-PoE, and IEEE802.3bt
power supply standards.>
Manages PoE power consumption and PoE power on/off. Supports Intelligent
PoE.>
A wide operating temperature range and a full metal casing that is
fully-enclosed and dust-proof. -
Add to cart>
Meets the requirements of
IEEE802.3,IEEE802.3u,IEEE802.3x,IEEE802.3ab,IEEE802.3z standards.>
Meets the requirements of IEEE802.3af, IEEE802.3at, Hi-PoE, and IEEE802.3bt
power supply standards.>
Manages PoE power consumption and PoE power on/off. Supports Intelligent
PoE.>
A wide operating temperature range and a full metal casing that is
fully-enclosed and dust-proof. -
Dahua DEE1010B-S2 Access Control Extension Module
KSh695,393.88 -
Add to cartDahua DH-HAC-B1A11P Analog Camera HD and SD output switchable Key Features: Max 30fps@720P HD and SD output switchable 3.6mm fixed lens (2.8mm optional) Max. IR length 20m, Smart IR IP67, DC12V
-
Add to cartDahua DH-IPC- HDBW4631EP-ASE 6MP Mini Dome Network Camera
1/2.9** 6Megapixel progressive scan STARVIS™ CMOS. H.265 & H.264 triple-stream encoding. 20fps@6MP(3072×2048). 25/30fps®4MP(2688xl520). Smart Detection supported. WDR(l20dB). Day/Night(ICR). 3DNR. AWB.AGC.BLC. Multiple network monitoring: Web viewer. MS(DSS/PSS) & DMSS. 2.8mm fixed lens. 1/1 Alarm in/out. 1/1 Audio in/out. Max. lR LEDs Length 30m. Micro SD memory. IP67. IKlO. ePoE
Key Features
1/2.9” 6Megapixel progressive scan STARVIS™ CMOS
H.265&H.264 triple-stream encoding
20fps@6MP(3072×2048), 25/30fps@4MP(2688×1520)
Smart Detection supported
WDR(120dB), Day/Night(ICR), 3DNR,AWB,AGC,BLC
Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
2.8mm fixed lens (3.6mm optional)
1/1 Alarm in/out, 1/1 audio in/out
Max. IR LEDs Length 30m
Micro SD memory, IP67, IK10, PoE -
Add to cart
Dahua DH-IPC- HDBW4631EP-ASE 6MP Mini Dome Network Camera
1/2.9** 6Megapixel progressive scan STARVIS™ CMOS. H.265 & H.264 triple-stream encoding. 20fps@6MP(3072×2048). 25/30fps®4MP(2688xl520). Smart Detection supported. WDR(l20dB). Day/Night(ICR). 3DNR. AWB.AGC.BLC. Multiple network monitoring: Web viewer. MS(DSS/PSS) & DMSS. 2.8mm fixed lens. 1/1 Alarm in/out. 1/1 Audio in/out. Max. lR LEDs Length 30m. Micro SD memory. IP67. IKlO. ePoE
Key Features
1/2.9” 6Megapixel progressive scan STARVIS™ CMOS
H.265&H.264 triple-stream encoding
20fps@6MP(3072×2048), 25/30fps@4MP(2688×1520)
Smart Detection supported
WDR(120dB), Day/Night(ICR), 3DNR,AWB,AGC,BLC
Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
2.8mm fixed lens (3.6mm optional)
1/1 Alarm in/out, 1/1 audio in/out
Max. IR LEDs Length 30m
Micro SD memory, IP67, IK10, PoE -
Add to cartDahua DH-IPC-B2B40P-ZS 4MP IR HD Bullet IP Network Camera
Camera
Image Sensor
1/3” 4Megapixel progresive CMOS
Effective Pixels
2560(H)x1440(V)
RAM/ROM
256MB/16MB
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual, 1/3~1/100000s
Minimum Illumination
0.05Lux/F1.8( Color,1/3s,30IRE)
0.3Lux/F1.8( Color,1/30s,30IRE)
0Lux/F1.8(IR on)
S/N Ratio
More than 50dB
IR Distance
Distance up to 40m(131ft)
IR On/Off Control
Auto/ Manual
IR LEDs
2
Lens
Lens Type
Motorized
Mount Type
Board-in
Focal Length
2.8mm~12mm
Max. Aperture
F1.8
Angle of View
H:97°~31°, V:54°~17°
Focus Control
Fixed
Close Focus Distance
0.2m(0.66ft)
DORI Distance
Lens
Detect
Observe
Recognize
Identify
W
66m(216.5ft)
26.4m(86.6ft)
13.2m(43.3ft)
6.6m(21.7ft)
T
200m(656.2ft)
80m(262.5ft)
40m(131.2ft)
20m(65.6ft)
PTZ
Pan/Tilt Range
Pan:0° ~360° ;Tilt:0° ~90° ;Rotation:0° ~360°
Intelligence
Event Trigger
Motion detection, Video tampering , Network disconnection , Scene change, IP address conflict, Illegal Access,Storage anomaly
Video
Compression
H.265/H.264/H.264B/MJPEG(Sub Stream)
Smart Codec
Support H.265+/H.264+
Streaming Capability
2 Streams
Resolution
4M(2560×1440)/3M(2304×1296)/1080P(1920×1080)/720P(1280×720)/VGA(640×480)/D1(704×576/704×480)/CIF(352×288/352×240)
Frame Rate
Main Stream: 4M(1 ~ 20fps)
Sub Stream: D1(1 ~ 25/30fps)
Bit Rate Control
CBR/VBR
Bit Rate
H.264: 32K~6144K
H.265: 12K~ 6144K
Day/Night
Auto(ICR) / Color / B/W
BLC Mode
BLC / HLC / DWDR
White Balance
Auto/Natural/Street Lamp/Outdoor/Manual
Gain Control
Auto/Manual
Noise Reduction
3D DNR
Motion Detetion
Off / On (4 Zone, Rectangle)
Region of Interest
Off / On (4 Zone)
Electronic Image Stabilization (EIS)
N/A
Smart IR
Support
Digital Zoom
16x
Flip
0°/90°/180°/270°
Mirror
Off / On
Privacy Masking
Off / On (4 Area, Rectangle)
Audio
Compression
N/A
Network
Ethernet
RJ-45 (10/100Base-T)
Protocol
HTTP;HTTPS;TCP;ARP;RTSP;RTP;RTCP;UDP;SMTP;
FTP;DHCP;DNS;DDNS;IPV4/V6;QoS;UPnP;
NTP;Bonjour;Multicast;ICMP;IGMP;TLS;SSH
Streaming Method
Unicast / Multicast
Max. User Access
10 Users/20 Users
Edge Storage
NAS(Network Attached Storage)
Local PC for instant recording
Micro SD Card 128GB
Web Viewer
IE, Chrome, Firefox, Safari
Management Software
Smart PSS, DSS,DMSS
Smart Phone
IOS, Android
Certifications
Certifications
CE: (EN 60950:2000)
FCC: FCC Part 15 Subpart B
Interface
Video Interface
N/A
Audio Interface
N/A
RS485
N/A
Alarm
N/A
Electrical
Power Supply
DC12V, PoE (802.3af)(Class 0)
Power Consumption
DC12V: 1.8W, 5.3W(IR On)
PoE: 2.2W, 6.3W(IR On)
Environmental
Operating Conditions
-30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH
Strorage Conditions
-30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH
Ingress Protection
IP67
Vandal Resistance
N/A
Construction
Casing
Metal+Plastic
Dimensions
243.6mm×90.7mm×90.2mm (9.59”×3.57”×3.55”)
Net Weight
0.434Kg(0.957lb)
Gross Weight
0.693Kg(1.53b)
-
Add to cart
Dahua DH-IPC-B2B40P-ZS 4MP IR HD Bullet IP Network Camera
Camera
Image Sensor
1/3” 4Megapixel progresive CMOS
Effective Pixels
2560(H)x1440(V)
RAM/ROM
256MB/16MB
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual, 1/3~1/100000s
Minimum Illumination
0.05Lux/F1.8( Color,1/3s,30IRE)
0.3Lux/F1.8( Color,1/30s,30IRE)
0Lux/F1.8(IR on)
S/N Ratio
More than 50dB
IR Distance
Distance up to 40m(131ft)
IR On/Off Control
Auto/ Manual
IR LEDs
2
Lens
Lens Type
Motorized
Mount Type
Board-in
Focal Length
2.8mm~12mm
Max. Aperture
F1.8
Angle of View
H:97°~31°, V:54°~17°
Focus Control
Fixed
Close Focus Distance
0.2m(0.66ft)
DORI Distance
Lens
Detect
Observe
Recognize
Identify
W
66m(216.5ft)
26.4m(86.6ft)
13.2m(43.3ft)
6.6m(21.7ft)
T
200m(656.2ft)
80m(262.5ft)
40m(131.2ft)
20m(65.6ft)
PTZ
Pan/Tilt Range
Pan:0° ~360° ;Tilt:0° ~90° ;Rotation:0° ~360°
Intelligence
Event Trigger
Motion detection, Video tampering , Network disconnection , Scene change, IP address conflict, Illegal Access,Storage anomaly
Video
Compression
H.265/H.264/H.264B/MJPEG(Sub Stream)
Smart Codec
Support H.265+/H.264+
Streaming Capability
2 Streams
Resolution
4M(2560×1440)/3M(2304×1296)/1080P(1920×1080)/720P(1280×720)/VGA(640×480)/D1(704×576/704×480)/CIF(352×288/352×240)
Frame Rate
Main Stream: 4M(1 ~ 20fps)
Sub Stream: D1(1 ~ 25/30fps)
Bit Rate Control
CBR/VBR
Bit Rate
H.264: 32K~6144K
H.265: 12K~ 6144K
Day/Night
Auto(ICR) / Color / B/W
BLC Mode
BLC / HLC / DWDR
White Balance
Auto/Natural/Street Lamp/Outdoor/Manual
Gain Control
Auto/Manual
Noise Reduction
3D DNR
Motion Detetion
Off / On (4 Zone, Rectangle)
Region of Interest
Off / On (4 Zone)
Electronic Image Stabilization (EIS)
N/A
Smart IR
Support
Digital Zoom
16x
Flip
0°/90°/180°/270°
Mirror
Off / On
Privacy Masking
Off / On (4 Area, Rectangle)
Audio
Compression
N/A
Network
Ethernet
RJ-45 (10/100Base-T)
Protocol
HTTP;HTTPS;TCP;ARP;RTSP;RTP;RTCP;UDP;SMTP;
FTP;DHCP;DNS;DDNS;IPV4/V6;QoS;UPnP;
NTP;Bonjour;Multicast;ICMP;IGMP;TLS;SSH
Streaming Method
Unicast / Multicast
Max. User Access
10 Users/20 Users
Edge Storage
NAS(Network Attached Storage)
Local PC for instant recording
Micro SD Card 128GB
Web Viewer
IE, Chrome, Firefox, Safari
Management Software
Smart PSS, DSS,DMSS
Smart Phone
IOS, Android
Certifications
Certifications
CE: (EN 60950:2000)
FCC: FCC Part 15 Subpart B
Interface
Video Interface
N/A
Audio Interface
N/A
RS485
N/A
Alarm
N/A
Electrical
Power Supply
DC12V, PoE (802.3af)(Class 0)
Power Consumption
DC12V: 1.8W, 5.3W(IR On)
PoE: 2.2W, 6.3W(IR On)
Environmental
Operating Conditions
-30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH
Strorage Conditions
-30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH
Ingress Protection
IP67
Vandal Resistance
N/A
Construction
Casing
Metal+Plastic
Dimensions
243.6mm×90.7mm×90.2mm (9.59”×3.57”×3.55”)
Net Weight
0.434Kg(0.957lb)
Gross Weight
0.693Kg(1.53b)
-
Dahua DH-IPC-HDBW1431EP-S4 IP Camera – Kenya
KSh8,000.00Add to cartDahua DH-IPC-HDBW1431EP-S4 IP Camera
Camera
Image Sensor
1/3” 4Megapixel progresive CMOS
Effective Pixels
2688(H)x1520(V)
RAM/ROM
128MB/128MB
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual, 1/3~1/100000s
Minimum Illumination
0.03 Lux @ F2.0
S/N Ratio
More than 56dB
IR Distance
Distance up to 30m(98ft)
IR On/Off Control
Auto/ Manual
IR LEDs
3
Lens
Lens Type
Fixed
Mount Type
M12
Focal Length
2.8mm, 3.6mm
Max. Aperture
F2.0/F2.0
Angle of View
2.8 mm: Horizontal: 93° Vertical: 53° Diagonal: 111°
3.6 mm: Horizontal: 81° Vertical: 44° Diagonal: 95°
Focus Control
Fixed
Close Focus Distance
2.8 mm: 0.8 m (2.6 ft)
3.6 mm: 1.4 m (4.6 ft)
DORI Distance
Lens
Detect
Observe
Recognize
Identify
2.8 mm
50.0 m (183.7 ft)
22.4 m (73.5 ft)
11.2 m (36.7 ft)
15.1 m (18.4 ft)
3.6 mm
80.0 m (262.5 ft)
32.0 m (105.0 ft)
16.0 m (52.5 ft)
8.0 m (26.2 ft)
PTZ
Pan/Tilt Range
Pan:0° ~355° ;Tilt:0° ~65° ;Rotation:0° ~355°
Intelligence
Event Trigger
Motion detection, Video tampering, Scene changing, Network disconnection, Ip address conflict, Illegal access, Storage anomaly
IVS
N/A
Video
Compression
H.265; H.264; H.264B; MJPEG (only supported by sub stream)
Smart Codec
Smart H.265+/ Smart H.264+
Streaming Capability
2 Streams
Resolution
2688 × 1520 (2688 × 1520); 2560 × 1440 (2560 × 1440); 2304 × 1296 (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 ×240)
Frame Rate
Main Stream: 2688 × 1520 (1 fps–20 fps) 2560 × 1440 (1 fps–25/30 fps)
Sub Stream: 704 × 576 (1 fps–20/25 fps) 704 × 480 (1 fps–20/30 fps)
Bit Rate Control
CBR/VBR
Bit Rate
H.264: 32 kbps–6144 kbps
H.265: 12 kbps–6144 kbps
Day/Night
Auto(ICR) / Color / B/W
BLC Mode
BLC / HLC / WDR(120dB)
White Balance
Auto/Natural/Street Lamp/Outdoor/Manual
Gain Control
Auto/Manual
Noise Reduction
3D DNR
Motion Detection
Off / On (4 Zone, Rectangle)
Region of Interest
Off / On (4 Zone)
Electronic Image Stabilization (EIS)
N/A
Smart IR
Support
WDR
120db
Flip
0°/90°/180°/270°
Mirror
Off / On
Privacy Masking
Off / On (4 Area, Rectangle)
Audio
Compression
N/A
Network
Ethernet
RJ-45 (10/100Base-T)
Protocol
HTTP;HTTPS;TCP;ARP;RTSP;RTP;RTCP;UDP;SMTP;
FTP;DHCP;DNS;DDNS;PPPoE;IPV4/V6;QoS;UPnP;
NTP;Bonjour;IEEE 802.1X;Multicast;ICMP;IGMP;TLS
Interoperability
ONVIF Profile S&G, API
Streaming Method
Unicast / Multicast
Max. User Access
10 Users / 20 Users
Edge Storage
NAS
Local PC for instant recording
Web Viewer
IE, Chrome, Firefox, Safari
Management Software
Smart PSS, DSS, DMSS
Smart Phone
IOS, Android
Certifications
Certifications
CE (EN 60950:2000)
UL:UL60950-1
FCC: FCC Part 15 Subpart B
Interface
Video Interface
N/A
Audio Interface
N/A
RS485
N/A
Alarm
N/A
Electrical
Power Supply
DC12V, PoE(IEEE 802.3af)(Class 0)
Power Consumption
< 5.5W Environmental Operating Conditions -30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH Stroage Conditions -30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH Ingress Protection IP67 Vandal Resistance IK10 Construction Casing Metal Dimensions 81 mm × **109.9 mm (3.2** × **4.3**) Net Weight 0.35 kg (0.8 lb) Gross Weight 0.48 kg (1.1 lb)
-
Dahua DH-IPC-HDBW1431EP-S4 IP Camera – Kenya
KSh8,000.00Add to cartDahua DH-IPC-HDBW1431EP-S4 IP Camera
Camera
Image Sensor
1/3” 4Megapixel progresive CMOS
Effective Pixels
2688(H)x1520(V)
RAM/ROM
128MB/128MB
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual, 1/3~1/100000s
Minimum Illumination
0.03 Lux @ F2.0
S/N Ratio
More than 56dB
IR Distance
Distance up to 30m(98ft)
IR On/Off Control
Auto/ Manual
IR LEDs
3
Lens
Lens Type
Fixed
Mount Type
M12
Focal Length
2.8mm, 3.6mm
Max. Aperture
F2.0/F2.0
Angle of View
2.8 mm: Horizontal: 93° Vertical: 53° Diagonal: 111°
3.6 mm: Horizontal: 81° Vertical: 44° Diagonal: 95°
Focus Control
Fixed
Close Focus Distance
2.8 mm: 0.8 m (2.6 ft)
3.6 mm: 1.4 m (4.6 ft)
DORI Distance
Lens
Detect
Observe
Recognize
Identify
2.8 mm
50.0 m (183.7 ft)
22.4 m (73.5 ft)
11.2 m (36.7 ft)
15.1 m (18.4 ft)
3.6 mm
80.0 m (262.5 ft)
32.0 m (105.0 ft)
16.0 m (52.5 ft)
8.0 m (26.2 ft)
PTZ
Pan/Tilt Range
Pan:0° ~355° ;Tilt:0° ~65° ;Rotation:0° ~355°
Intelligence
Event Trigger
Motion detection, Video tampering, Scene changing, Network disconnection, Ip address conflict, Illegal access, Storage anomaly
IVS
N/A
Video
Compression
H.265; H.264; H.264B; MJPEG (only supported by sub stream)
Smart Codec
Smart H.265+/ Smart H.264+
Streaming Capability
2 Streams
Resolution
2688 × 1520 (2688 × 1520); 2560 × 1440 (2560 × 1440); 2304 × 1296 (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 ×240)
Frame Rate
Main Stream: 2688 × 1520 (1 fps–20 fps) 2560 × 1440 (1 fps–25/30 fps)
Sub Stream: 704 × 576 (1 fps–20/25 fps) 704 × 480 (1 fps–20/30 fps)
Bit Rate Control
CBR/VBR
Bit Rate
H.264: 32 kbps–6144 kbps
H.265: 12 kbps–6144 kbps
Day/Night
Auto(ICR) / Color / B/W
BLC Mode
BLC / HLC / WDR(120dB)
White Balance
Auto/Natural/Street Lamp/Outdoor/Manual
Gain Control
Auto/Manual
Noise Reduction
3D DNR
Motion Detection
Off / On (4 Zone, Rectangle)
Region of Interest
Off / On (4 Zone)
Electronic Image Stabilization (EIS)
N/A
Smart IR
Support
WDR
120db
Flip
0°/90°/180°/270°
Mirror
Off / On
Privacy Masking
Off / On (4 Area, Rectangle)
Audio
Compression
N/A
Network
Ethernet
RJ-45 (10/100Base-T)
Protocol
HTTP;HTTPS;TCP;ARP;RTSP;RTP;RTCP;UDP;SMTP;
FTP;DHCP;DNS;DDNS;PPPoE;IPV4/V6;QoS;UPnP;
NTP;Bonjour;IEEE 802.1X;Multicast;ICMP;IGMP;TLS
Interoperability
ONVIF Profile S&G, API
Streaming Method
Unicast / Multicast
Max. User Access
10 Users / 20 Users
Edge Storage
NAS
Local PC for instant recording
Web Viewer
IE, Chrome, Firefox, Safari
Management Software
Smart PSS, DSS, DMSS
Smart Phone
IOS, Android
Certifications
Certifications
CE (EN 60950:2000)
UL:UL60950-1
FCC: FCC Part 15 Subpart B
Interface
Video Interface
N/A
Audio Interface
N/A
RS485
N/A
Alarm
N/A
Electrical
Power Supply
DC12V, PoE(IEEE 802.3af)(Class 0)
Power Consumption
< 5.5W Environmental Operating Conditions -30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH Stroage Conditions -30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH Ingress Protection IP67 Vandal Resistance IK10 Construction Casing Metal Dimensions 81 mm × **109.9 mm (3.2** × **4.3**) Net Weight 0.35 kg (0.8 lb) Gross Weight 0.48 kg (1.1 lb)
-
Add to cartDAHUA DH-IPC-HDBW2431RP-ZS-27135 4MP IR Dome Network Camera
Camera
Image Sensor
1/3” 4Megapixel progressive CMOS
Max. Resolution
2688 (H) × 1520 (V)
ROM
128 MB
RAM
128 MB
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual 1/3 s–1/100000 s
Min. Illumination
0.008 Lux @ F1.5
S/N Ratio
>56 dB
Illumination Distance
40 m (131.23 ft)
Illuminator On/Off Control
Auto/Manual
Illuminator Number
2 (IR LED)
Pan/Tilt/Rotation Range
Pan: 0°–355°
Tilt: 0°–75°
Rotation: 0°–355°Lens
Lens Type
Motorized vari-focal
Mount Type
**14
Focal Length
2.7 mm–13.5 mm
Max. Aperture
F1.5
Field of View
Horizontal: 104°–27°
Vertical: 55°–15°
Diagonal: 124°–31°Iris Type
Fixed
Close Focus Distance
0.8 m–0.8 m (2.62 ft–2.62 ft)
DORI Distance
Lens
Detect
Observe
Recognize
Identify
W
64 m
(209.97 ft)25.6 m
(83.99 ft)12.8 m
(41.99 ft)6.4 m
(21 ft)T
220 m
(721.78 ft)88 m
(288.71 ft)44 m
(144.36 ft)22 m
(72.18 ft)Smart Event
IVS
Tripwire; intrusion
Video
Video Compression
H.265; H.264; H.264B; MJPEG (only supported by the sub stream)
Smart Codec
Smart H.265+/ Smart H.264+
Video Frame Rate
Main stream:
2688 × 1520 (1 fps-20 fps)
2560 × 1440 (1 fps-25/30 fps)
Sub stream:
704 × 576 (1 fps-25 fps)
704 × 480 (1 fps-30 fps)
Stream Capability
2 streams
Resolution
2688 × 1520 (2688 × 1520); 2560 × 1440 (2560 × 1440); 2304 × 1296 (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 ×480); CIF (352 × 288/352 × 240)
Bit Rate Control
CBR/VBR
Video Bit Rate
H.264: 32 kbps–6144 kbps
H.265: 12 kbps–6144 kbps
Day/Night
Auto(ICR)/Color/B/W
BLC
Yes
HLC
Yes
WDR
120 dB
White Balance
Auto/natural/street lamp/outdoor/manual/regional custom
Gain Control
Auto/Manual
Noise Reduction
3D NR
Motion Detection
OFF/ON (4 areas, rectangular)
Region of Interest(RoI)
Yes (4 areas)
Smart Illumination
Yes
Image Rotation
0°/90°/180°/270° (Supports 90°/270° with 2688 × 1520 resolution and lower.)
Mirror
Yes
Privacy Masking
4 areas
Alarm
Alarm Event
No SD card; SD card full; SD card error; network disconnection; IP conflict; motion detection; video tampering; tripwire; intrusion; illegal access; voltage detection; safety exception
Network
Network
RJ-45 (10/100 Base-T)
SDK and API
Yes
Cyber Security
Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade
Protocol
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; Bonjour
Interoperability
ONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone; Genetec
User/Host
20
Storage
FTP; Micro SD card (support max. 256 G); NAS; SFTP
Browser
IE
Chrome
FirefoxManagement Software
Smart PSS; DSS; DMSS
Mobile Phone
IOS; Android
Certification
Certification
CE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07Power
Power Supply
12V DC/PoE (802.3af)
Power Consumption
< 6.5W Environment Operating Conditions -30°C to +60°C (-22°F to +140°F)/less than ** 95% RH Storage Temperature -40°C to +60°C (-40°F to +140°F) Protection IP67; IK10 Structure Casing Metal Dimensions **122 mm × 88.9 mm (**4.80** × 3.50**) Net Weight 0.47 kg (1.04 lb) Gross Weight 0.63 kg (1.39 lb)
-
Add to cart
DAHUA DH-IPC-HDBW2431RP-ZS-27135 4MP IR Dome Network Camera
Camera
Image Sensor
1/3” 4Megapixel progressive CMOS
Max. Resolution
2688 (H) × 1520 (V)
ROM
128 MB
RAM
128 MB
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual 1/3 s–1/100000 s
Min. Illumination
0.008 Lux @ F1.5
S/N Ratio
>56 dB
Illumination Distance
40 m (131.23 ft)
Illuminator On/Off Control
Auto/Manual
Illuminator Number
2 (IR LED)
Pan/Tilt/Rotation Range
Pan: 0°–355°
Tilt: 0°–75°
Rotation: 0°–355°Lens
Lens Type
Motorized vari-focal
Mount Type
**14
Focal Length
2.7 mm–13.5 mm
Max. Aperture
F1.5
Field of View
Horizontal: 104°–27°
Vertical: 55°–15°
Diagonal: 124°–31°Iris Type
Fixed
Close Focus Distance
0.8 m–0.8 m (2.62 ft–2.62 ft)
DORI Distance
Lens
Detect
Observe
Recognize
Identify
W
64 m
(209.97 ft)25.6 m
(83.99 ft)12.8 m
(41.99 ft)6.4 m
(21 ft)T
220 m
(721.78 ft)88 m
(288.71 ft)44 m
(144.36 ft)22 m
(72.18 ft)Smart Event
IVS
Tripwire; intrusion
Video
Video Compression
H.265; H.264; H.264B; MJPEG (only supported by the sub stream)
Smart Codec
Smart H.265+/ Smart H.264+
Video Frame Rate
Main stream:
2688 × 1520 (1 fps-20 fps)
2560 × 1440 (1 fps-25/30 fps)
Sub stream:
704 × 576 (1 fps-25 fps)
704 × 480 (1 fps-30 fps)
Stream Capability
2 streams
Resolution
2688 × 1520 (2688 × 1520); 2560 × 1440 (2560 × 1440); 2304 × 1296 (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 ×480); CIF (352 × 288/352 × 240)
Bit Rate Control
CBR/VBR
Video Bit Rate
H.264: 32 kbps–6144 kbps
H.265: 12 kbps–6144 kbps
Day/Night
Auto(ICR)/Color/B/W
BLC
Yes
HLC
Yes
WDR
120 dB
White Balance
Auto/natural/street lamp/outdoor/manual/regional custom
Gain Control
Auto/Manual
Noise Reduction
3D NR
Motion Detection
OFF/ON (4 areas, rectangular)
Region of Interest(RoI)
Yes (4 areas)
Smart Illumination
Yes
Image Rotation
0°/90°/180°/270° (Supports 90°/270° with 2688 × 1520 resolution and lower.)
Mirror
Yes
Privacy Masking
4 areas
Alarm
Alarm Event
No SD card; SD card full; SD card error; network disconnection; IP conflict; motion detection; video tampering; tripwire; intrusion; illegal access; voltage detection; safety exception
Network
Network
RJ-45 (10/100 Base-T)
SDK and API
Yes
Cyber Security
Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade
Protocol
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; Bonjour
Interoperability
ONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone; Genetec
User/Host
20
Storage
FTP; Micro SD card (support max. 256 G); NAS; SFTP
Browser
IE
Chrome
FirefoxManagement Software
Smart PSS; DSS; DMSS
Mobile Phone
IOS; Android
Certification
Certification
CE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07Power
Power Supply
12V DC/PoE (802.3af)
Power Consumption
< 6.5W Environment Operating Conditions -30°C to +60°C (-22°F to +140°F)/less than ** 95% RH Storage Temperature -40°C to +60°C (-40°F to +140°F) Protection IP67; IK10 Structure Casing Metal Dimensions **122 mm × 88.9 mm (**4.80** × 3.50**) Net Weight 0.47 kg (1.04 lb) Gross Weight 0.63 kg (1.39 lb)
-
Add to cartDahua DH-IPC-HDBW2531EP-S-S2-0280B CCTV Camera
Camera
Image Sensor
1/2.7” 5Megapixel progressive CMOS
Max. Resolution
2592 (H) × 1944 (V)
ROM
128 MB
RAM
256 MB
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual 1/3 s–1/100000 s
Min. Illumination
0.008 Lux @ F1.6
S/N Ratio
> 56 dB
Illumination Distance
30 m (98.43 ft)
Illuminator On/Off Control
Auto/Manual
Illuminator Number
3 (IR LED)
Pan/Tilt/Rotation Range
Pan: 0°–355°
Tilt: 0°–65°Rotation: 0°–355°
Lens
Lens Type
Fixed
Mount Type
M12
Focal Length
2.8 mm
3.6 mmMax. Aperture
F1.6
F1.6
Field of View
2.8 mm:
Horizontal 103.0° × Vertical 71.0° × Diagonal 132.0°
3.6 mm:
Horizontal: 84.0° × Vertical 58.0° × Diagonal 110.0°
Iris Type
Fixed
Close Focus Distance
2.8 mm: 0.9 m (2.95 ft)
3.6 mm: 1.6 m (5.25 ft)DORI Distance
Lens
Detect
Observe
Recognize
Identify
2.8mm
56 m
(183.73 ft)22.4 m
(73.49 ft)11.2 m
(36.75 ft)5.6 m
(19.37 ft)3.6mm
80 m
(262.47 ft)32 m
(104.99 ft)16 m
(52.49 ft)8 m
(26.25 ft)Smart Event
IVS
Tripwire; intrusion
Video
Video Compression
H.265; H.264; H.264B; MJPEG (only supported
by the sub stream)
Smart Codec
Smart H.265+/ Smart H.264+
Video Frame Rate
Main stream:
2592 × 1944 (1 fps-20 fps)
2688 × 1520 (1 fps-25/30 fps)
Sub stream:
704 × 576 (1 fps-25 fps)
704 × 480 (1 fps-30 fps)Stream Capability
2 streams
Resolution
2592×1944(2592×1944); 2688×1520(2688×1520); 3M(2048×1536); 2304×1296(2304×1296); 1080p(1920×1080); 1.3M (1280 × 960); 720p(1280×720); D1(704× 576/704×480); VGA(640×480); CIF(352×288/352×240)
Bit Rate Control
CBR/VBR
Video Bit Rate
H.264: 32 Kbps–8192 Kbps
H.265: 12 Kbps–8192 Kbps
Day/Night
Auto(ICR)/Color/B/W
BLC
Yes
HLC
Yes
WDR
120 dB
White Balance
Auto/natural/street lamp/outdoor/manual/regional custom
Gain Control
Auto/Manual
Noise Reduction
3D NR
Motion Detection
OFF/ON (4 areas, rectangular)
Region of Interest(RoI)
Yes (4 areas)
Smart Illumination
Yes
Image Rotation
0°/90°/180°/270° (Supports 90°/270° with 2592 × 1944 resolution and lower.)
Mirror
Yes
Privacy Masking
4 areas
Alarm
Alarm Event
No SD card; SD card full; SD card error; network disconnection; IP conflict; motion detection; video tampering; tripwire; intrusion; illegal access; voltage detection; safety exception
Network
Network
RJ-45 (10/100 Base-T)
SDK and API
Yes
Cyber Security
Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade
Protocol
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; Bonjour
Interoperability
ONVIF(Profile S/Profile G/Profile T);CGI; P2P; Milestone; Genetec
User/Host
20
Storage
FTP; Micro SD card (support max. 256 G); NAS; SFTP
Browser
IE
Chrome
Firefox
Management Software
Smart PSS; DSS; DMSS
Mobile Phone
IOS; Android
Certification
Certifications
CE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07Power
Power Supply
12V DC/PoE (802.3af)
Power Consumption
< 6.1W Environment Power Consumption -40°C to +60°C (-40°F to +140°F)/less than ** 95% RH Storage Temperature -40°C to +60°C (-40°F to +140°F) Protection IP67, IK10 Structure Casing Metal Dimensions 81 mm × **109.9 mm (3.19** × **4.33**) Net Weight 0.350 kg (0.77 lb) Gross Weight 0.491 kg (1.08 lb)
-
Add to cart
Dahua DH-IPC-HDBW2531EP-S-S2-0280B CCTV Camera
Camera
Image Sensor
1/2.7” 5Megapixel progressive CMOS
Max. Resolution
2592 (H) × 1944 (V)
ROM
128 MB
RAM
256 MB
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual 1/3 s–1/100000 s
Min. Illumination
0.008 Lux @ F1.6
S/N Ratio
> 56 dB
Illumination Distance
30 m (98.43 ft)
Illuminator On/Off Control
Auto/Manual
Illuminator Number
3 (IR LED)
Pan/Tilt/Rotation Range
Pan: 0°–355°
Tilt: 0°–65°Rotation: 0°–355°
Lens
Lens Type
Fixed
Mount Type
M12
Focal Length
2.8 mm
3.6 mmMax. Aperture
F1.6
F1.6
Field of View
2.8 mm:
Horizontal 103.0° × Vertical 71.0° × Diagonal 132.0°
3.6 mm:
Horizontal: 84.0° × Vertical 58.0° × Diagonal 110.0°
Iris Type
Fixed
Close Focus Distance
2.8 mm: 0.9 m (2.95 ft)
3.6 mm: 1.6 m (5.25 ft)DORI Distance
Lens
Detect
Observe
Recognize
Identify
2.8mm
56 m
(183.73 ft)22.4 m
(73.49 ft)11.2 m
(36.75 ft)5.6 m
(19.37 ft)3.6mm
80 m
(262.47 ft)32 m
(104.99 ft)16 m
(52.49 ft)8 m
(26.25 ft)Smart Event
IVS
Tripwire; intrusion
Video
Video Compression
H.265; H.264; H.264B; MJPEG (only supported
by the sub stream)
Smart Codec
Smart H.265+/ Smart H.264+
Video Frame Rate
Main stream:
2592 × 1944 (1 fps-20 fps)
2688 × 1520 (1 fps-25/30 fps)
Sub stream:
704 × 576 (1 fps-25 fps)
704 × 480 (1 fps-30 fps)Stream Capability
2 streams
Resolution
2592×1944(2592×1944); 2688×1520(2688×1520); 3M(2048×1536); 2304×1296(2304×1296); 1080p(1920×1080); 1.3M (1280 × 960); 720p(1280×720); D1(704× 576/704×480); VGA(640×480); CIF(352×288/352×240)
Bit Rate Control
CBR/VBR
Video Bit Rate
H.264: 32 Kbps–8192 Kbps
H.265: 12 Kbps–8192 Kbps
Day/Night
Auto(ICR)/Color/B/W
BLC
Yes
HLC
Yes
WDR
120 dB
White Balance
Auto/natural/street lamp/outdoor/manual/regional custom
Gain Control
Auto/Manual
Noise Reduction
3D NR
Motion Detection
OFF/ON (4 areas, rectangular)
Region of Interest(RoI)
Yes (4 areas)
Smart Illumination
Yes
Image Rotation
0°/90°/180°/270° (Supports 90°/270° with 2592 × 1944 resolution and lower.)
Mirror
Yes
Privacy Masking
4 areas
Alarm
Alarm Event
No SD card; SD card full; SD card error; network disconnection; IP conflict; motion detection; video tampering; tripwire; intrusion; illegal access; voltage detection; safety exception
Network
Network
RJ-45 (10/100 Base-T)
SDK and API
Yes
Cyber Security
Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade
Protocol
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; Bonjour
Interoperability
ONVIF(Profile S/Profile G/Profile T);CGI; P2P; Milestone; Genetec
User/Host
20
Storage
FTP; Micro SD card (support max. 256 G); NAS; SFTP
Browser
IE
Chrome
Firefox
Management Software
Smart PSS; DSS; DMSS
Mobile Phone
IOS; Android
Certification
Certifications
CE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07Power
Power Supply
12V DC/PoE (802.3af)
Power Consumption
< 6.1W Environment Power Consumption -40°C to +60°C (-40°F to +140°F)/less than ** 95% RH Storage Temperature -40°C to +60°C (-40°F to +140°F) Protection IP67, IK10 Structure Casing Metal Dimensions 81 mm × **109.9 mm (3.19** × **4.33**) Net Weight 0.350 kg (0.77 lb) Gross Weight 0.491 kg (1.08 lb)
-
Add to cartDahua DH-IPC-HDBW2531RP-ZAS 5MP IP AI Lite Dome 40m IR Camera
Camera
Image Sensor
1/2.7” 5Megapixel progressive CMOS
Max. Resolution
2592 (H) × 1944 (V)
ROM
128 MB
RAM
256 MB
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual 1/3 s–1/100000 s
Min. Illumination
0.008 Lux @ F1.5
S/N Ratio
>56 dB
Illumination Distance
40 m (131.2 ft)
Illuminator On/Off Control
Auto/Manual
Illuminator Number
2 (IR LED)
Pan/Tilt/Rotation Range
Pan: 0°–355°
Tilt: 0°–75°
Rotation: 0°–355°Lens
Lens Type
Motorized vari-focal
Mount Type
**14
Focal Length
2.7 mm–13.5 mm
Max. Aperture
F1.5
Field of View
Horizontal: 100°–26°
Vertical: 72°–20°
Diagonal: 133°–33°
Iris Type
Fixed
Close Focus Distance
0.8m–0.8m (2.62 ft–2.62 ft)
DORI Distance
Lens
Detect
Observe
Recognize
Identify
W
64 m
(209.97 ft)25.6 m
(83.99 ft)12.8 m
(41.99 ft)6.4 m
(21 ft)T
220 m
(721.78 ft)88 m
(288.71 ft)44 m
(144.36 ft)22 m
(72.18 ft)Smart Event
IVS
Tripwire; intrusion
Video
Video Compression
H.265; H.264; H.264B; MJPEG (only supported by the sub stream)
Smart Codec
Smart H.265+/ Smart H.264+
Video Frame Rate
Main stream:
2592 × 1944 (1 fps-20 fps)
2688 × 1520 (1 fps-25/30 fps)
Sub stream:
704 × 576 (1 fps-25 fps)
704 × 480 (1 fps-30 fps)Stream Capability
2 streams
Resolution
2592×1944(2592×1944); 2688×1520(2688×1520); 3M(2048×1536); 2304×1296(2304×1296); 1080p(1920×1080); 1.3M(1280 × 960); 720p(1280×720); D1(704× 576/704×480); VGA(640×480);
CIF(352×288/352×240)
Bit Rate Control
CBR/VBR
Video Bit Rate
H.264: 32 kbps–8192 kbps
H.265: 12 kbps–8192 kbps
Day/Night
Auto(ICR)/Color/B/W
BLC
Yes
HLC
Yes
WDR
120 dB
White Balance
Auto/natural/street lamp/outdoor/manual/regional custom
Gain Control
Auto/Manual
Noise Reduction
3D NR
Motion Detection
OFF/ON (4 areas, rectangular)
Region of Interest(RoI)
Yes (4 areas)
Smart Illumination
Yes
Image Rotation
0°/90°/180°/270° (Supports 90°/270° with 2592 × 1944 resolution and lower.)
Mirror
Yes
Privacy Masking
4 areas
Audio
Audio Compression
G.711a; G.711Mu; G.726
Alarm
Alarm Event
No SD card; SD card full; SD card error; network disconnection; IP conflict; motion detection; video tampering; tripwire; intrusion; illegal access; voltage detection; audio detection; safety exception; local alarm
Network
Network
RJ-45 (10/100 Base-T)
SDK and API
Yes
Cyber Security
Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade
Protocol
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; Bonjour
Interoperability
ONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone; Genetec
User/Host
20
Storage
FTP; Micro SD card (support max. 256 G); NAS; SFTP
Browser
IE
Chrome
FirefoxManagement Software
Smart PSS; DSS; DMSS
Mobile Phone
IOS; Android
Certification
Certifications
CE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07Port
Audio Input
1 channel (RCA port)
Audio Output
1 channel (RCA port)
Alarm Input
1 channel In: 5mA 5VDC
Alarm Output
1 channel Out: 300mA 12VDC
Power
Power Supply
12V DC/PoE (802.3af)
Power Consumption
< 8.0W Environment Operating Conditions -30°C to +60°C (-22°F to +140°F)/less than ** 95% Storage Temperature -40°C to +60°C (-40°F to +140°F) Protection IP67, IK10 Structure Casing Metal Dimensions **122 mm × 88.9 mm (**4.80** × 3.50**) Net Weight 0.47 kg (1.1 lb) Gross Weight 0.63 kg (1.4 lb)
-
Add to cart
Dahua DH-IPC-HDBW2531RP-ZAS 5MP IP AI Lite Dome 40m IR Camera
Camera
Image Sensor
1/2.7” 5Megapixel progressive CMOS
Max. Resolution
2592 (H) × 1944 (V)
ROM
128 MB
RAM
256 MB
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual 1/3 s–1/100000 s
Min. Illumination
0.008 Lux @ F1.5
S/N Ratio
>56 dB
Illumination Distance
40 m (131.2 ft)
Illuminator On/Off Control
Auto/Manual
Illuminator Number
2 (IR LED)
Pan/Tilt/Rotation Range
Pan: 0°–355°
Tilt: 0°–75°
Rotation: 0°–355°Lens
Lens Type
Motorized vari-focal
Mount Type
**14
Focal Length
2.7 mm–13.5 mm
Max. Aperture
F1.5
Field of View
Horizontal: 100°–26°
Vertical: 72°–20°
Diagonal: 133°–33°
Iris Type
Fixed
Close Focus Distance
0.8m–0.8m (2.62 ft–2.62 ft)
DORI Distance
Lens
Detect
Observe
Recognize
Identify
W
64 m
(209.97 ft)25.6 m
(83.99 ft)12.8 m
(41.99 ft)6.4 m
(21 ft)T
220 m
(721.78 ft)88 m
(288.71 ft)44 m
(144.36 ft)22 m
(72.18 ft)Smart Event
IVS
Tripwire; intrusion
Video
Video Compression
H.265; H.264; H.264B; MJPEG (only supported by the sub stream)
Smart Codec
Smart H.265+/ Smart H.264+
Video Frame Rate
Main stream:
2592 × 1944 (1 fps-20 fps)
2688 × 1520 (1 fps-25/30 fps)
Sub stream:
704 × 576 (1 fps-25 fps)
704 × 480 (1 fps-30 fps)Stream Capability
2 streams
Resolution
2592×1944(2592×1944); 2688×1520(2688×1520); 3M(2048×1536); 2304×1296(2304×1296); 1080p(1920×1080); 1.3M(1280 × 960); 720p(1280×720); D1(704× 576/704×480); VGA(640×480);
CIF(352×288/352×240)
Bit Rate Control
CBR/VBR
Video Bit Rate
H.264: 32 kbps–8192 kbps
H.265: 12 kbps–8192 kbps
Day/Night
Auto(ICR)/Color/B/W
BLC
Yes
HLC
Yes
WDR
120 dB
White Balance
Auto/natural/street lamp/outdoor/manual/regional custom
Gain Control
Auto/Manual
Noise Reduction
3D NR
Motion Detection
OFF/ON (4 areas, rectangular)
Region of Interest(RoI)
Yes (4 areas)
Smart Illumination
Yes
Image Rotation
0°/90°/180°/270° (Supports 90°/270° with 2592 × 1944 resolution and lower.)
Mirror
Yes
Privacy Masking
4 areas
Audio
Audio Compression
G.711a; G.711Mu; G.726
Alarm
Alarm Event
No SD card; SD card full; SD card error; network disconnection; IP conflict; motion detection; video tampering; tripwire; intrusion; illegal access; voltage detection; audio detection; safety exception; local alarm
Network
Network
RJ-45 (10/100 Base-T)
SDK and API
Yes
Cyber Security
Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade
Protocol
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; Bonjour
Interoperability
ONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone; Genetec
User/Host
20
Storage
FTP; Micro SD card (support max. 256 G); NAS; SFTP
Browser
IE
Chrome
FirefoxManagement Software
Smart PSS; DSS; DMSS
Mobile Phone
IOS; Android
Certification
Certifications
CE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07Port
Audio Input
1 channel (RCA port)
Audio Output
1 channel (RCA port)
Alarm Input
1 channel In: 5mA 5VDC
Alarm Output
1 channel Out: 300mA 12VDC
Power
Power Supply
12V DC/PoE (802.3af)
Power Consumption
< 8.0W Environment Operating Conditions -30°C to +60°C (-22°F to +140°F)/less than ** 95% Storage Temperature -40°C to +60°C (-40°F to +140°F) Protection IP67, IK10 Structure Casing Metal Dimensions **122 mm × 88.9 mm (**4.80** × 3.50**) Net Weight 0.47 kg (1.1 lb) Gross Weight 0.63 kg (1.4 lb)
-
Add to cartDAHUA DH-IPC-HDBW5241EP-ZE-27135-DC12AC24V 2MP IR Dome Camera
Camera
Image Sensor
1/2.8** CMOS
Max. Resolution
1920 (H) × 1080 (V)
ROM
128 MB
RAM
512 MB
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual 1/3 s–1/100,000 s
Min. Illumination
0.002 lux@F1.5 (Color, 30 IRE)
0.0002 lux@F1.5 (B/W, 30 IRE)
0 lux (Illuminator on)S/N Ratio
>56 dB
Illumination Distance
40 m (131.23 ft) (IR)
Illuminator On/Off Control
Auto
Illuminator Number
3 (IR LED)
Pan/Tilt/Rotation Range
Pan: 0°–355°
Tilt: 0°–65°
Rotation: 0°–355°Lens
Lens Type
Motorized vari-focal
Lens Mount
**14
Focal Length
2.7 mm–13.5 mm
Max. Aperture
F1.5
Field of View
Horizontal: 109°–30°
Vertical: 57°–17°
Diagonal: 131°–35°Iris Control
Auto
Close Focus Distance
0.8 m (2.62 ft)
DORI Distance
Lens
Detect
Observe
Recognize
Identify
W
44.1 m (144.69 ft)
17.6 m (57.74 ft)
8.8 m
(28.87 ft)
4.4 m
(14.44 ft)
T
146.2 m (479.66 ft)
58.4 m (191.60 ft)
29.2 m (85.80 ft)
14.6 m (47.90 ft)
Smart Event
IVS
Abandoned object; missing object
Heat Map
Yes
Professional, intelligent
IVS (Perimeter Protection)
Intrusion, tripwire, fast moving (the three functions support the classification and accurate detection of vehicle and human); loitering detection, people gathering, and parking detection
SMD 3.0
Less false alarm, longer detection distance
Face Detection
Face detection; track; snapshot; snapshot optimization; optimal face snapshot upload; face enhancement; face exposure; face attributes extraction including 6 attributes (gender, age, glasses, expressions, mask, and beard) and 8 expressions (angry, sad, disgusted, scared, surprised, calm, happy, confused); face snapshot set as face or one-inch photo; snapshot strategies (real-time snapshot, quality priority and optimization snapshot); face angle filter; optimization time setting
People Counting
Support the counting of enter number, leave number and pass number, and displaying and outputting yearly/monthly/daily reports.Support the counting of number in area, and 4 rules configuration. Count number of people or stay time and link alarm.Support queue management, and 4 rules configuration. Count number of people or stay time and link alarm.
Smart Search
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos
Video
Video Compression
H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream)
Smart Codec
Smart H.265+; Smart H.264+
AI Coding
AI H.265; AI H.264
Video Frame Rate
Main stream: 1920 × 1080@(1 fps–25/30 fps)
Sub stream: D1@(1 fps–25/30 fps)
Third stream: 1080p@(1 fps–25/30 fps)
*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.Stream Capability
3 streams
Resolution
1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
Bit Rate Control
CBR/VBR
Video Bit Rate
H.264: 32 kbps–8192 kbps
H.265: 32 kbps–8192 kbpsDay/Night
Auto (ICR)/Color/B/W
BLC
Yes
HLC
Yes
WDR
120 dB
Scene Self-adaptation (SSA)
Yes
White Balance
Auto; natural; street lamp; outdoor; manual; regional custom
Gain Control
Auto; manual
Noise Reduction
3D NR
Motion Detection
OFF/ON (4 areas, rectangular)
Region of Interest (RoI)
Yes (4 areas)
Image Stabilization
Electronic Image Stabilization (EIS)
Smart Illumination
Yes
Defog
Yes
Image Rotation
0°/90°/180°/270°
Mirror
Yes
Privacy Masking
8 areas
Audio
Audio Compression
PCM; G.711a; G.711Mu; G.726; G.723
Alarm
Alarm Event
No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; defocus detection; scene changing; tripwire; intrusion; abandoned object; missing object; fast moving; parking detection; loitering detection; people gathering; input error; intensity change; people counting; face detection; voltage detection; people counting in area; stay detection; people number error detection; queue management
Network
Network Port
RJ-45 (10/100 Enhancement Base-T)
SDK and API
Yes
Cyber Security
Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade
Network Protocol
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP; Bonjour
Interoperability
ONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone
User/Host
20 (Total bandwidth: 80 M)
Storage
FTP; SFTP; Micro SD card (support max. 256 GB); NAS
Browser
IE: IE8 and later
Chrome
FirefoxManagement Software
Smart PSS; DSS; DMSS
Mobile Client
iOS; Android
Certification
Certifications
CE-LVD: EN 62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07Port
Audio Input
1 channel (terminal)
Audio Output
1 channel (terminal)
Alarm Input
1 channels in: 5 mA 3 V–5 VDC
Alarm Output
1 channel out: 300 mA 12 VDC
Power
Power Supply
12 VDC (±25%)&24 VAC (±30%); PoE (802.3af); ePoE
Power Consumption
Basic: 4.6 W (12 VDC); 4.9 W (24 VAC); 4.9 W (PoE)
Max. (max. stream + intelligence + IR on + focus): 11.8 W (12 VDC); 11.5 W (24 VAC); 11.3 W (PoE)Environment
Operating Temperature
–30 °C to +60 °C (–22 °F to +140 °F)
Operating Humidity
** 95%
Storage Temperature
–40 °C to +60 °C (–40 °F to +140 °F)
Protection
IP67; IK10
Structure
Casing
Metal + plastic
Product Dimensions
**159 mm × 117.9 mm (6.26** × 4.64**)
Net Weight
950 g (2.09 lb)
Gross Weight
1200 g (2.65 l
-
Add to cart
DAHUA DH-IPC-HDBW5241EP-ZE-27135-DC12AC24V 2MP IR Dome Camera
Camera
Image Sensor
1/2.8** CMOS
Max. Resolution
1920 (H) × 1080 (V)
ROM
128 MB
RAM
512 MB
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual 1/3 s–1/100,000 s
Min. Illumination
0.002 lux@F1.5 (Color, 30 IRE)
0.0002 lux@F1.5 (B/W, 30 IRE)
0 lux (Illuminator on)S/N Ratio
>56 dB
Illumination Distance
40 m (131.23 ft) (IR)
Illuminator On/Off Control
Auto
Illuminator Number
3 (IR LED)
Pan/Tilt/Rotation Range
Pan: 0°–355°
Tilt: 0°–65°
Rotation: 0°–355°Lens
Lens Type
Motorized vari-focal
Lens Mount
**14
Focal Length
2.7 mm–13.5 mm
Max. Aperture
F1.5
Field of View
Horizontal: 109°–30°
Vertical: 57°–17°
Diagonal: 131°–35°Iris Control
Auto
Close Focus Distance
0.8 m (2.62 ft)
DORI Distance
Lens
Detect
Observe
Recognize
Identify
W
44.1 m (144.69 ft)
17.6 m (57.74 ft)
8.8 m
(28.87 ft)
4.4 m
(14.44 ft)
T
146.2 m (479.66 ft)
58.4 m (191.60 ft)
29.2 m (85.80 ft)
14.6 m (47.90 ft)
Smart Event
IVS
Abandoned object; missing object
Heat Map
Yes
Professional, intelligent
IVS (Perimeter Protection)
Intrusion, tripwire, fast moving (the three functions support the classification and accurate detection of vehicle and human); loitering detection, people gathering, and parking detection
SMD 3.0
Less false alarm, longer detection distance
Face Detection
Face detection; track; snapshot; snapshot optimization; optimal face snapshot upload; face enhancement; face exposure; face attributes extraction including 6 attributes (gender, age, glasses, expressions, mask, and beard) and 8 expressions (angry, sad, disgusted, scared, surprised, calm, happy, confused); face snapshot set as face or one-inch photo; snapshot strategies (real-time snapshot, quality priority and optimization snapshot); face angle filter; optimization time setting
People Counting
Support the counting of enter number, leave number and pass number, and displaying and outputting yearly/monthly/daily reports.Support the counting of number in area, and 4 rules configuration. Count number of people or stay time and link alarm.Support queue management, and 4 rules configuration. Count number of people or stay time and link alarm.
Smart Search
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos
Video
Video Compression
H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream)
Smart Codec
Smart H.265+; Smart H.264+
AI Coding
AI H.265; AI H.264
Video Frame Rate
Main stream: 1920 × 1080@(1 fps–25/30 fps)
Sub stream: D1@(1 fps–25/30 fps)
Third stream: 1080p@(1 fps–25/30 fps)
*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.Stream Capability
3 streams
Resolution
1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
Bit Rate Control
CBR/VBR
Video Bit Rate
H.264: 32 kbps–8192 kbps
H.265: 32 kbps–8192 kbpsDay/Night
Auto (ICR)/Color/B/W
BLC
Yes
HLC
Yes
WDR
120 dB
Scene Self-adaptation (SSA)
Yes
White Balance
Auto; natural; street lamp; outdoor; manual; regional custom
Gain Control
Auto; manual
Noise Reduction
3D NR
Motion Detection
OFF/ON (4 areas, rectangular)
Region of Interest (RoI)
Yes (4 areas)
Image Stabilization
Electronic Image Stabilization (EIS)
Smart Illumination
Yes
Defog
Yes
Image Rotation
0°/90°/180°/270°
Mirror
Yes
Privacy Masking
8 areas
Audio
Audio Compression
PCM; G.711a; G.711Mu; G.726; G.723
Alarm
Alarm Event
No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; defocus detection; scene changing; tripwire; intrusion; abandoned object; missing object; fast moving; parking detection; loitering detection; people gathering; input error; intensity change; people counting; face detection; voltage detection; people counting in area; stay detection; people number error detection; queue management
Network
Network Port
RJ-45 (10/100 Enhancement Base-T)
SDK and API
Yes
Cyber Security
Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade
Network Protocol
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP; Bonjour
Interoperability
ONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone
User/Host
20 (Total bandwidth: 80 M)
Storage
FTP; SFTP; Micro SD card (support max. 256 GB); NAS
Browser
IE: IE8 and later
Chrome
FirefoxManagement Software
Smart PSS; DSS; DMSS
Mobile Client
iOS; Android
Certification
Certifications
CE-LVD: EN 62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07Port
Audio Input
1 channel (terminal)
Audio Output
1 channel (terminal)
Alarm Input
1 channels in: 5 mA 3 V–5 VDC
Alarm Output
1 channel out: 300 mA 12 VDC
Power
Power Supply
12 VDC (±25%)&24 VAC (±30%); PoE (802.3af); ePoE
Power Consumption
Basic: 4.6 W (12 VDC); 4.9 W (24 VAC); 4.9 W (PoE)
Max. (max. stream + intelligence + IR on + focus): 11.8 W (12 VDC); 11.5 W (24 VAC); 11.3 W (PoE)Environment
Operating Temperature
–30 °C to +60 °C (–22 °F to +140 °F)
Operating Humidity
** 95%
Storage Temperature
–40 °C to +60 °C (–40 °F to +140 °F)
Protection
IP67; IK10
Structure
Casing
Metal + plastic
Product Dimensions
**159 mm × 117.9 mm (6.26** × 4.64**)
Net Weight
950 g (2.09 lb)
Gross Weight
1200 g (2.65 l
-
Add to cartDAHUA DH-IPC-HDBW5241RP-S-0280B 2MP WDR IR Dome Pro Cam 2.8mm CCTV
Camera
Image Sensor
1/2.8** CMOS
Max. Resolution
1920 (H) × 1080 (V)
ROM
128 MB
RAM
512 MB
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual 1/3 s–1/100,000 s
Min. Illumination
0.002 lux@F1.6 (Color, 30 IRE)
0.0002 lux@F1.6 (B/W, 30 IRE)
0 lux (Illuminator on)S/N Ratio
>56 dB
Illumination Distance
50 m (164.04 ft) (IR)
Illuminator On/Off Control
Auto; manual
Illuminator Number
1 (IR LED)
Pan/Tilt/Rotation Range
Pan: 0°–360°
Tilt: 0°–78°
Rotation: 0°–360°Lens
Lens Type
Fixed-focal
Lens Mount
M12
Focal Length
2.8 mm; 3.6 mm; 6 mm
Max. Aperture
F1.6
Field of View
2.8 mm: Horizontal: 106°; Vertical: 57°; Diagonal: 126°
3.6 mm: Horizontal: 87°; Vertical: 46°; Diagonal: 104°
6 mm: Horizontal: 53°; Vertical: 30°; Diagonal: 60°Iris Control
Fixed
Close Focus Distance
2.8 mm: 0.6 m (1.97 ft)
3.6 mm: 1.2 m (3.94 ft)
6 mm: 2.5 m (8.20 ft)DORI Distance
Lens
Detect
Observe
Recognize
Identify
2.8 mm
38.6 m (126.64 ft)
15.4 m (50.52 ft)
7.7 m
(25.26 ft)
3.9 m
(12.80 ft)
3.6 mm
55.2 m (181.10 ft)
22.1 m (72.51 ft)
11.0 m (36.09 ft)
5.5 m
(18.04 ft)
6 mm
82.8 m (271.65 ft)
33.1 m (108.60 ft)
16.6 m (54.46 ft)
8.3 m
(27.23 ft)
Smart Event
IVS
Abandoned object; missing object
Heat Map
Yes
Professional, intelligent
IVS (Perimeter Protection)
Intrusion, tripwire, fast moving (the three functions support the classification and accurate detection of vehicle and human); loitering detection, people gathering, and parking detection
SMD 3.0
Less false alarm, longer detection distance
Face Detection
Face detection; track; snapshot; snapshot optimization; optimal face snapshot upload; face enhancement; face exposure; face snapshot set as face, one-inch photo or custom; 3 snapshot strategies (real-time snapshot, optimization snapshot and quality first); face angle filter; optimization time setting
People Counting
Support the counting of enter number, leave number and pass number, and displaying and outputting yearly/monthly/daily reports.
Support the counting of number in area, and 4 rules configuration. Count number of people or stay time and link alarm.
Support queue management, and 4 rules configuration. Count number of people or stay time and link alarm.
Smart Search
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos
Video
Video Compression
H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream)
Smart Codec
Smart H.265+; Smart H.264+
AI Coding
AI H.265; AI H.264
Video Frame Rate
Main stream: 1080p@(1–25/30 fps)
Sub stream: D1@(1–25/30 fps)
Third stream: 1080p@(1–25/30 fps)
*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.Stream Capability
3 streams
Resolution
1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
Bit Rate Control
CBR/VBR
Video Bit Rate
H.264: 3 kbps–20480 kbps
H.265: 3 kbps–20480 kbpsDay/Night
Auto(ICR)/Color/B/W
BLC
Yes
HLC
Yes
WDR
120 dB
Scene Self-adaptation (SSA)
Yes
White Balance
Auto; natural; street lamp; outdoor; manual; regional custom
Gain Control
Auto; manual
Noise Reduction
3D NR
Motion Detection
OFF/ON (4 areas, rectangular)
Region of Interest (RoI)
Yes (4 areas)
Defog
Yes
Image Rotation
0°/90°/180°/270°
Mirror
Yes
Privacy Masking
8 areas
Alarm
Alarm Event
No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; voltage detection; motion detection; video tampering; tripwire; intrusion; fast moving; abandoned object; missing object; loitering detection; people gathering; parking detection; scene changing; face detection; SMD; people counting in area; stay detection; people counting; security exception
Network
Network Port
RJ-45 (10/100 Base-T)
SDK and API
Yes
Cyber Security
Video encryption; Firmware encryption; Configuration encryption; Digest; WSSE; Account lockout; Security logs; IP/MAC filtering; Generation and importing of X.509 certification; syslog; HTTPS; 802.1x; Trusted boot; Trusted execution; Trusted upgrade
Network Protocol
IPv4; IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; 802.1x; SNMP
Interoperability
ONVIF (Profile S/Profile G/Profile T); CGI; Milestone; P2P
User/Host
20 (Total bandwidth: 80 M)
Storage
FTP; SFTP; Micro SD card (support max. 256 GB); NAS
Browser
IE: IE 8 and later
Chrome
FirefoxManagement Software
Smart PSS; DSS; DMSS
Mobile Client
iOS; Android
Certification
Certifications
CE-LVD: EN60950-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL:
UL60950-1
CAN/CSA C22.2 No.60950-1-07Power
Power Supply
12 VDC/PoE (802.3af)
Power Consumption
Basic: 1.9 W (12 VDC); 2.4 W (PoE)
Max. (H.265 + three streams + intelligence on + IR on ): 4.5 W (12 VDC); 5 W (PoE)Environment
Operating Temperature
–40 °C to +60 °C (–40 °F to +140 °F)
Operating Humidity
**95%
Storage Temperature
–40 °C to +60 °C (–40 °F to +140 °F)
Protection
IP67; IK10
Structure
Casing
Metal + plastic
Product Dimensions
**122 mm × 88.9 mm (4.80** × **3.50**)
Net Weight
455 g (1.00 lb)
Gross Weight
615 g (1.36 lb)
-
Add to cart
DAHUA DH-IPC-HDBW5241RP-S-0280B 2MP WDR IR Dome Pro Cam 2.8mm CCTV
Camera
Image Sensor
1/2.8** CMOS
Max. Resolution
1920 (H) × 1080 (V)
ROM
128 MB
RAM
512 MB
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual 1/3 s–1/100,000 s
Min. Illumination
0.002 lux@F1.6 (Color, 30 IRE)
0.0002 lux@F1.6 (B/W, 30 IRE)
0 lux (Illuminator on)S/N Ratio
>56 dB
Illumination Distance
50 m (164.04 ft) (IR)
Illuminator On/Off Control
Auto; manual
Illuminator Number
1 (IR LED)
Pan/Tilt/Rotation Range
Pan: 0°–360°
Tilt: 0°–78°
Rotation: 0°–360°Lens
Lens Type
Fixed-focal
Lens Mount
M12
Focal Length
2.8 mm; 3.6 mm; 6 mm
Max. Aperture
F1.6
Field of View
2.8 mm: Horizontal: 106°; Vertical: 57°; Diagonal: 126°
3.6 mm: Horizontal: 87°; Vertical: 46°; Diagonal: 104°
6 mm: Horizontal: 53°; Vertical: 30°; Diagonal: 60°Iris Control
Fixed
Close Focus Distance
2.8 mm: 0.6 m (1.97 ft)
3.6 mm: 1.2 m (3.94 ft)
6 mm: 2.5 m (8.20 ft)DORI Distance
Lens
Detect
Observe
Recognize
Identify
2.8 mm
38.6 m (126.64 ft)
15.4 m (50.52 ft)
7.7 m
(25.26 ft)
3.9 m
(12.80 ft)
3.6 mm
55.2 m (181.10 ft)
22.1 m (72.51 ft)
11.0 m (36.09 ft)
5.5 m
(18.04 ft)
6 mm
82.8 m (271.65 ft)
33.1 m (108.60 ft)
16.6 m (54.46 ft)
8.3 m
(27.23 ft)
Smart Event
IVS
Abandoned object; missing object
Heat Map
Yes
Professional, intelligent
IVS (Perimeter Protection)
Intrusion, tripwire, fast moving (the three functions support the classification and accurate detection of vehicle and human); loitering detection, people gathering, and parking detection
SMD 3.0
Less false alarm, longer detection distance
Face Detection
Face detection; track; snapshot; snapshot optimization; optimal face snapshot upload; face enhancement; face exposure; face snapshot set as face, one-inch photo or custom; 3 snapshot strategies (real-time snapshot, optimization snapshot and quality first); face angle filter; optimization time setting
People Counting
Support the counting of enter number, leave number and pass number, and displaying and outputting yearly/monthly/daily reports.
Support the counting of number in area, and 4 rules configuration. Count number of people or stay time and link alarm.
Support queue management, and 4 rules configuration. Count number of people or stay time and link alarm.
Smart Search
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos
Video
Video Compression
H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream)
Smart Codec
Smart H.265+; Smart H.264+
AI Coding
AI H.265; AI H.264
Video Frame Rate
Main stream: 1080p@(1–25/30 fps)
Sub stream: D1@(1–25/30 fps)
Third stream: 1080p@(1–25/30 fps)
*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.Stream Capability
3 streams
Resolution
1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
Bit Rate Control
CBR/VBR
Video Bit Rate
H.264: 3 kbps–20480 kbps
H.265: 3 kbps–20480 kbpsDay/Night
Auto(ICR)/Color/B/W
BLC
Yes
HLC
Yes
WDR
120 dB
Scene Self-adaptation (SSA)
Yes
White Balance
Auto; natural; street lamp; outdoor; manual; regional custom
Gain Control
Auto; manual
Noise Reduction
3D NR
Motion Detection
OFF/ON (4 areas, rectangular)
Region of Interest (RoI)
Yes (4 areas)
Defog
Yes
Image Rotation
0°/90°/180°/270°
Mirror
Yes
Privacy Masking
8 areas
Alarm
Alarm Event
No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; voltage detection; motion detection; video tampering; tripwire; intrusion; fast moving; abandoned object; missing object; loitering detection; people gathering; parking detection; scene changing; face detection; SMD; people counting in area; stay detection; people counting; security exception
Network
Network Port
RJ-45 (10/100 Base-T)
SDK and API
Yes
Cyber Security
Video encryption; Firmware encryption; Configuration encryption; Digest; WSSE; Account lockout; Security logs; IP/MAC filtering; Generation and importing of X.509 certification; syslog; HTTPS; 802.1x; Trusted boot; Trusted execution; Trusted upgrade
Network Protocol
IPv4; IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; 802.1x; SNMP
Interoperability
ONVIF (Profile S/Profile G/Profile T); CGI; Milestone; P2P
User/Host
20 (Total bandwidth: 80 M)
Storage
FTP; SFTP; Micro SD card (support max. 256 GB); NAS
Browser
IE: IE 8 and later
Chrome
FirefoxManagement Software
Smart PSS; DSS; DMSS
Mobile Client
iOS; Android
Certification
Certifications
CE-LVD: EN60950-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL:
UL60950-1
CAN/CSA C22.2 No.60950-1-07Power
Power Supply
12 VDC/PoE (802.3af)
Power Consumption
Basic: 1.9 W (12 VDC); 2.4 W (PoE)
Max. (H.265 + three streams + intelligence on + IR on ): 4.5 W (12 VDC); 5 W (PoE)Environment
Operating Temperature
–40 °C to +60 °C (–40 °F to +140 °F)
Operating Humidity
**95%
Storage Temperature
–40 °C to +60 °C (–40 °F to +140 °F)
Protection
IP67; IK10
Structure
Casing
Metal + plastic
Product Dimensions
**122 mm × 88.9 mm (4.80** × **3.50**)
Net Weight
455 g (1.00 lb)
Gross Weight
615 g (1.36 lb)
-
Add to cartDAHUA DH-IPC-HDBW5442H-ZE 4MP Vari-focal Dome WizMind Network Camera
Camera
Image Sensor
1/1.8” CMOS
Max. Resolution
2688 (H) × 1520 (V)
ROM
128 MB
RAM
1 GB
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual 1/3 s–1/100,000 s
Min. Illumination
0.003 Lux@F1.8 (Color, 30IRE)
0.0003 Lux@F1.8 (B/W, 30IRE)
0 Lux (Illuminator on)
S/N Ratio
**56 dB
Illumination Distance
40 m (131.2 ft) (IR LED)
Illuminator On/Off Control
Auto/Manual
Illuminator Number
3 (IR LED)
Pan/Tilt/Rotation Range
Pan: 0°–355°
Tilt: 0°–80°
Rotation: 0°–355°Lens
Lens Type
Motorized vari-focal
Mount Type
**14
Focal Length
2.7 mm–12 mm
Max. Aperture
F1.8
Field of View
Horizontal: 107°–44°
Vertical: 69°–29°
Diagonal: 134°–53°Iris Type
Auto
Close Focus Distance
W/T: 1.2 m (3.9 ft)
DORI Distance
Lens
Detect
Observe
Recognize
Identify
W
57.0 m
(131.2 ft)
23.0 m
(75.5 ft)
11.0 m
(36.1 ft)
5.7 m
(18.7 ft)
T
130.7 m (428.8 ft)
52.0 m
(170.6 ft)
26.0 m
(85.3 ft)
13.0 m
(42.7 ft)
Smart Event
IVS
Abandoned object; missing object
Heat Map
Yes
Professional, intelligent
IVS (Perimeter Protection)
Tripwire; intrusion; fast moving (the three functions support the classification and accurate detection of vehicle and human); loitering detection; people gathering; parking detection
Face Detection
Face detection; track; optimization; snapshot; report high quality picture; face enhancement; face exposure; face attribute extract, 6 attributes and 8 expressions: Gender, age, glasses, expressions (anger, calm, happiness, sadness, disgust, surprise, confusion and fear), mask, beard; face matting setting: face, single inch photo; three snapshot methods: real-time snapshot, optimization snapshot, quality priority; face angle filter; optimization time setting
People Counting
Support the counting of enter number, leave number and pass number, and displaying and outputting yearly/monthly/daily reports.
Support the counting of number in area, and 4 rules configuration. Count number of people or stay time and link alarm.
Support queue management, and 4 rules configuration. Count number of people or stay time and link alarm.Intelligent Search
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos.
Video
Video Compression
H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream)
Smart Codec
Smart H.265+/H.264+
Video Frame Rate
Main stream: 2688 × 1520 (1 fps–25/30 fps) /1920 × 1080 (1 fps–50/60 fps)
Sub stream: D1 (1 fps–50/60 fps)
Third stream: 1080p (1 fps–25/30 fps)*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.
Stream Capability
3 streams
Resolution
2688 × 1520; 2560 × 1440; 2304 × 1296; 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
Bit Rate Control
CBR/VBR
Video Bit Rate
H.264: 32 kbps–8192 kbps
H.265: 32 kbps–8192 kbpsDay/Night
Auto (ICR)/Color/B/W
BLC
Yes
HLC
Yes
WDR
140 dB
Scene Self-adaptation (SSA)
Yes
White Balance
Auto/natural/street lamp/outdoor/manual/regional custom
Gain Control
Auto/Manual
Noise Reduction
3D NR
Motion Detection
OFF/ON (4 areas)
Region of Interest (RoI)
Yes (4 areas)
Electronic Image Stabilization (EIS)
Yes
Smart Illumination
Yes
Defog
Yes
Image Rotation
0°/90°/180°/270°
Mirror
Yes
Privacy Masking
8 areas
Audio
Audio Compression
PCM; G.711a; G.711Mu; G.726; G.723
Alarm
Alarm Event
No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; defocus detection; scene changing; intrusion; tripwire; abandoned object; missing object; fast moving; parking detection; loitering detection; people gathering; input abnormal detection; intensity change detection; people counting; face detection; people counting in area; stay alarm; people No. exception detection; queue management
Network
Network
RJ-45 (10/100 Base-T)
SDK and API
Yes
Cyber Security
Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade
Protocol
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP
Interoperability
ONVIF (Profile S/Profile G/Profile T); CGI; Milestone; Genetec; P2P
User/Host
20 (Total bandwidth: 80 M)
Storage
FTP; SFTP; Micro SD card (support max. 256 G); NAS
Browser
IE: IE8 and later
Chrome
FirefoxManagement Software
Smart PSS; DSS; DMSS
Mobile Phone
IOS; Android
Certification
Certification
CE-LVD: EN62368-1,EN60950-22 (optional)
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07, UL 50E NEMA Type 4X (optional)Port
Audio Input
1 channel (terminal)
Audio Output
1 channel (terminal)
Alarm Input
3 channels in: 5mA 3V–5V DC
Alarm Output
2 channels out: 300mA 12V DC
Power
Power Supply
12V DC (±25%)/24V AC (±30%)/PoE (802.3af)/ePoE
Power Consumption
Basic power consumption: 3.6W (12V DC); 3.1W (24V AC); 4.4W (PoE)
Max. power consumption (H.265 + max. stream + intelligent function + IR LED + focus): 11.7W (12V DC); 11.3W (24V AC); 11.9W (PoE)
Environment
Operating Conditions
–30°C to +60°C (–22°F to +140°F)/Less than 95% RH
Strorage Conditions
–40°C to +60°C (–40°F to +140°F)
Protection Grade
IP67, IK10, Anti-Corrosion Protection: NEMA 4X (optional)
Structure
Casing
Metal
Dimensions
129.1 mm × **157.9mm (5.1**× **6.2**)
Net Weight
1500.0 g (3.3 lb)
Gross Weight
1600.0 g (3.5 lb)
-
Add to cart
DAHUA DH-IPC-HDBW5442H-ZE 4MP Vari-focal Dome WizMind Network Camera
Camera
Image Sensor
1/1.8” CMOS
Max. Resolution
2688 (H) × 1520 (V)
ROM
128 MB
RAM
1 GB
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual 1/3 s–1/100,000 s
Min. Illumination
0.003 Lux@F1.8 (Color, 30IRE)
0.0003 Lux@F1.8 (B/W, 30IRE)
0 Lux (Illuminator on)
S/N Ratio
**56 dB
Illumination Distance
40 m (131.2 ft) (IR LED)
Illuminator On/Off Control
Auto/Manual
Illuminator Number
3 (IR LED)
Pan/Tilt/Rotation Range
Pan: 0°–355°
Tilt: 0°–80°
Rotation: 0°–355°Lens
Lens Type
Motorized vari-focal
Mount Type
**14
Focal Length
2.7 mm–12 mm
Max. Aperture
F1.8
Field of View
Horizontal: 107°–44°
Vertical: 69°–29°
Diagonal: 134°–53°Iris Type
Auto
Close Focus Distance
W/T: 1.2 m (3.9 ft)
DORI Distance
Lens
Detect
Observe
Recognize
Identify
W
57.0 m
(131.2 ft)
23.0 m
(75.5 ft)
11.0 m
(36.1 ft)
5.7 m
(18.7 ft)
T
130.7 m (428.8 ft)
52.0 m
(170.6 ft)
26.0 m
(85.3 ft)
13.0 m
(42.7 ft)
Smart Event
IVS
Abandoned object; missing object
Heat Map
Yes
Professional, intelligent
IVS (Perimeter Protection)
Tripwire; intrusion; fast moving (the three functions support the classification and accurate detection of vehicle and human); loitering detection; people gathering; parking detection
Face Detection
Face detection; track; optimization; snapshot; report high quality picture; face enhancement; face exposure; face attribute extract, 6 attributes and 8 expressions: Gender, age, glasses, expressions (anger, calm, happiness, sadness, disgust, surprise, confusion and fear), mask, beard; face matting setting: face, single inch photo; three snapshot methods: real-time snapshot, optimization snapshot, quality priority; face angle filter; optimization time setting
People Counting
Support the counting of enter number, leave number and pass number, and displaying and outputting yearly/monthly/daily reports.
Support the counting of number in area, and 4 rules configuration. Count number of people or stay time and link alarm.
Support queue management, and 4 rules configuration. Count number of people or stay time and link alarm.Intelligent Search
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos.
Video
Video Compression
H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream)
Smart Codec
Smart H.265+/H.264+
Video Frame Rate
Main stream: 2688 × 1520 (1 fps–25/30 fps) /1920 × 1080 (1 fps–50/60 fps)
Sub stream: D1 (1 fps–50/60 fps)
Third stream: 1080p (1 fps–25/30 fps)*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.
Stream Capability
3 streams
Resolution
2688 × 1520; 2560 × 1440; 2304 × 1296; 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
Bit Rate Control
CBR/VBR
Video Bit Rate
H.264: 32 kbps–8192 kbps
H.265: 32 kbps–8192 kbpsDay/Night
Auto (ICR)/Color/B/W
BLC
Yes
HLC
Yes
WDR
140 dB
Scene Self-adaptation (SSA)
Yes
White Balance
Auto/natural/street lamp/outdoor/manual/regional custom
Gain Control
Auto/Manual
Noise Reduction
3D NR
Motion Detection
OFF/ON (4 areas)
Region of Interest (RoI)
Yes (4 areas)
Electronic Image Stabilization (EIS)
Yes
Smart Illumination
Yes
Defog
Yes
Image Rotation
0°/90°/180°/270°
Mirror
Yes
Privacy Masking
8 areas
Audio
Audio Compression
PCM; G.711a; G.711Mu; G.726; G.723
Alarm
Alarm Event
No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; defocus detection; scene changing; intrusion; tripwire; abandoned object; missing object; fast moving; parking detection; loitering detection; people gathering; input abnormal detection; intensity change detection; people counting; face detection; people counting in area; stay alarm; people No. exception detection; queue management
Network
Network
RJ-45 (10/100 Base-T)
SDK and API
Yes
Cyber Security
Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade
Protocol
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP
Interoperability
ONVIF (Profile S/Profile G/Profile T); CGI; Milestone; Genetec; P2P
User/Host
20 (Total bandwidth: 80 M)
Storage
FTP; SFTP; Micro SD card (support max. 256 G); NAS
Browser
IE: IE8 and later
Chrome
FirefoxManagement Software
Smart PSS; DSS; DMSS
Mobile Phone
IOS; Android
Certification
Certification
CE-LVD: EN62368-1,EN60950-22 (optional)
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07, UL 50E NEMA Type 4X (optional)Port
Audio Input
1 channel (terminal)
Audio Output
1 channel (terminal)
Alarm Input
3 channels in: 5mA 3V–5V DC
Alarm Output
2 channels out: 300mA 12V DC
Power
Power Supply
12V DC (±25%)/24V AC (±30%)/PoE (802.3af)/ePoE
Power Consumption
Basic power consumption: 3.6W (12V DC); 3.1W (24V AC); 4.4W (PoE)
Max. power consumption (H.265 + max. stream + intelligent function + IR LED + focus): 11.7W (12V DC); 11.3W (24V AC); 11.9W (PoE)
Environment
Operating Conditions
–30°C to +60°C (–22°F to +140°F)/Less than 95% RH
Strorage Conditions
–40°C to +60°C (–40°F to +140°F)
Protection Grade
IP67, IK10, Anti-Corrosion Protection: NEMA 4X (optional)
Structure
Casing
Metal
Dimensions
129.1 mm × **157.9mm (5.1**× **6.2**)
Net Weight
1500.0 g (3.3 lb)
Gross Weight
1600.0 g (3.5 lb)
-
Add to cartDahua DH-IPC-HDBW5831RP-ZE 8MP WDR IR Dome Network Camera
The Dahua DH-IPC-HDBW5831RP-ZE is an advanced 8MP WDR IR Dome Network Camera designed for high-quality video surveillance in a wide range of environments. Equipped with a 1/2.5** progressive scan CMOS sensor, it delivers ultra-high-definition 3840 x 2160 resolution, ensuring crystal-clear image quality with fine detail. The camera features a motorized varifocal lens with a focal length ranging from 2.7mm to 13.5mm, allowing for flexible field of view adjustments from a wide 104° to a narrow 28° horizontal angle, making it suitable for both wide-area monitoring and focused observation.
The camera’s True Wide Dynamic Range (WDR) of 120dB ensures excellent image clarity even in challenging lighting conditions, such as areas with strong backlight or high contrast. Its powerful Smart IR technology provides night vision capabilities up to 50 meters (164 feet), allowing for reliable monitoring in complete darkness.
Built to withstand harsh environments, the DH-IPC-HDBW5831RP-ZE is encased in an IP67-rated weatherproof and IK10-rated vandal-resistant housing, making it ideal for both indoor and outdoor use. Its intelligent video system (IVS) includes features such as tripwire, intrusion, and abandoned/missing object detection, enhancing security and situational awareness.
The camera supports multiple network protocols and is ONVIF compliant, ensuring seamless integration with a wide range of network systems. With PoE support and low power consumption, it is easy to install and cost-effective to operate. Additional features include audio input/output for two-way communication, microSD card support for local storage, and advanced video compression technologies like H.265+, which optimize bandwidth and storage usage.
Overall, the Dahua DH-IPC-HDBW5831RP-ZE is a versatile and robust surveillance solution, offering exceptional video performance, intelligent analytics, and durable construction, making it suitable for critical security applications across various industries.
-
Add to cart
Dahua DH-IPC-HDBW5831RP-ZE 8MP WDR IR Dome Network Camera
The Dahua DH-IPC-HDBW5831RP-ZE is an advanced 8MP WDR IR Dome Network Camera designed for high-quality video surveillance in a wide range of environments. Equipped with a 1/2.5** progressive scan CMOS sensor, it delivers ultra-high-definition 3840 x 2160 resolution, ensuring crystal-clear image quality with fine detail. The camera features a motorized varifocal lens with a focal length ranging from 2.7mm to 13.5mm, allowing for flexible field of view adjustments from a wide 104° to a narrow 28° horizontal angle, making it suitable for both wide-area monitoring and focused observation.
The camera’s True Wide Dynamic Range (WDR) of 120dB ensures excellent image clarity even in challenging lighting conditions, such as areas with strong backlight or high contrast. Its powerful Smart IR technology provides night vision capabilities up to 50 meters (164 feet), allowing for reliable monitoring in complete darkness.
Built to withstand harsh environments, the DH-IPC-HDBW5831RP-ZE is encased in an IP67-rated weatherproof and IK10-rated vandal-resistant housing, making it ideal for both indoor and outdoor use. Its intelligent video system (IVS) includes features such as tripwire, intrusion, and abandoned/missing object detection, enhancing security and situational awareness.
The camera supports multiple network protocols and is ONVIF compliant, ensuring seamless integration with a wide range of network systems. With PoE support and low power consumption, it is easy to install and cost-effective to operate. Additional features include audio input/output for two-way communication, microSD card support for local storage, and advanced video compression technologies like H.265+, which optimize bandwidth and storage usage.
Overall, the Dahua DH-IPC-HDBW5831RP-ZE is a versatile and robust surveillance solution, offering exceptional video performance, intelligent analytics, and durable construction, making it suitable for critical security applications across various industries.
-
Dahua DH-IPC-HFW1230SP-S4, Dahua Camera – Kenya
KSh5,000.00Add to cartDahua DH-IPC-HFW1230SP-S4, Dahua Camera
Camera
Image Sensor
1/2.7” 2Megapixel progresive CMOS
Effective Pixels
1920(H) x1080(V)
RAM/ROM
256MB/32MB
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual, 1/3~1/100000s
Minimum Illumination
0.08Lux/F2.0( Color,1/3s,30IRE)
0.3Lux/F2.0( Color,1/30s,30IRE)
0Lux/F2.0(IR on)
S/N Ratio
More than 50dB
IR Distance
Distance up to 30m(98ft)
IR On/Off Control
Auto/ Manual
IR LEDs
18
Lens
Lens Type
Fixed
Mount Type
Board-in
Focal Length
2.8 mm (3.6 mm optional)
Max. Aperture
F2.0/F2.0
Angle of View
H:104°/92°,V:55°/50°
Focus Control
Fixed
Close Focus Distance
0.6m(0.9m)
DORI Distance
Lens
Detect
Observe
Recognize
Identify
2.8 mm
40(131ft)
16(52ft)
8(26ft)
4(13ft)
3.6 mm
53(174ft)
21(69ft)
11(36ft)
5(16ft)
PTZ
Pan/Tilt Range
Pan:0° ~360° ;Tilt:0° ~90° ;Rotation:0° ~360°
Intelligence
Event Trigger
Motion detection, Video tampering, Scene changing, Network disconnection, IP address conflict, Illegal access, Storage anomaly
IVS
Tripwire, Intrusion
Video
Compression
H.265/H.264H/MJPEG(Sub Stream)
Smart Codec
Support H.265+/H.264+
Streaming Capability
2 Streams
Resolution
1080P(1920×1080)/1.3M(1280×960)/
720P(1280×720)/D1(704×576/704×480)/ VGA(640×480)/CIF(352×288/352×240)
Frame Rate
Main Stream: 1080P(1 ~ 25/30fps)
Sub Stream: D1(1 ~ 25/30fps)
Bit Rate Control
CBR/VBR
Bit Rate
H.265: 12K ~ 6400Kbps
H.264: 32K ~ 10240Kbps
Day/Night
Auto(ICR) / Color / B/W
BLC Mode
BLC / HLC / DWDR
White Balance
Auto/Natural/Street Lamp/Outdoor/Manual
Gain Control
Auto/Manual
Noise Reduction
3D DNR
Motion Detection
Off / On (4 Zone, Rectangle)
Region of Interest
Off / On (4 Zone)
Electronic Image
Support
Smart IR
Support
Digital Zoom
16x
Flip
0°/90°/180°/270°
Mirror
Off / On
Privacy Masking
Off / On (4 Area, Rectangle)
Audio
Compression
N/A
Network
Ethernet
RJ-45 (10/100Base-T)
Protocol
HTTP;HTTPs;TCP;ARP;RTSP;RTP;RTCP;UDP;SMTP;
FTP;DHCP;DNS;DDNS;PPPoE;IPv4/v6;QoS;UPnP;
NTP;Bonjour;IEEE 802.1x;Multicast;ICMP;IGMP;
TLS
Interoperability
ONVIF Profile S&G, API
Streaming Method
Unicast / Multicast
Max. User Access
10 Users / 20 Users
Edge Storage
NAS
Local PC for instant recording
Web Viewer
IE, Chrome, Firefox, Safari
Management Software
Smart PSS, DSS, DMSS
Smart Phone
IOS, Android
Certifications
Certifications
CE (EN 60950:2000)
UL:UL60950-1
FCC: FCC Part 15 Subpart B
Interface
Video Interface
N/A
Audio Interface
N/A
RS485
N/A
Alarm
N/A
Electrical
Power Supply
DC12V, PoE (802.3af)(Class 0)
Power Consumption
<5.5W Environmental Operating Conditions -30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH Strorage Conditions -30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH Ingress Protection IP67 Vandal Resistance N/A Construction Casing Metal+Plastic Dimensions **70mm×164.7mm(2.76”x6.49”) Net Weight 0.38Kg(0.84lb) Gross Weight 0.44Kg(0.97lb
-
Dahua DH-IPC-HFW1230SP-S4, Dahua Camera – Kenya
KSh5,000.00Add to cartDahua DH-IPC-HFW1230SP-S4, Dahua Camera
Camera
Image Sensor
1/2.7” 2Megapixel progresive CMOS
Effective Pixels
1920(H) x1080(V)
RAM/ROM
256MB/32MB
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual, 1/3~1/100000s
Minimum Illumination
0.08Lux/F2.0( Color,1/3s,30IRE)
0.3Lux/F2.0( Color,1/30s,30IRE)
0Lux/F2.0(IR on)
S/N Ratio
More than 50dB
IR Distance
Distance up to 30m(98ft)
IR On/Off Control
Auto/ Manual
IR LEDs
18
Lens
Lens Type
Fixed
Mount Type
Board-in
Focal Length
2.8 mm (3.6 mm optional)
Max. Aperture
F2.0/F2.0
Angle of View
H:104°/92°,V:55°/50°
Focus Control
Fixed
Close Focus Distance
0.6m(0.9m)
DORI Distance
Lens
Detect
Observe
Recognize
Identify
2.8 mm
40(131ft)
16(52ft)
8(26ft)
4(13ft)
3.6 mm
53(174ft)
21(69ft)
11(36ft)
5(16ft)
PTZ
Pan/Tilt Range
Pan:0° ~360° ;Tilt:0° ~90° ;Rotation:0° ~360°
Intelligence
Event Trigger
Motion detection, Video tampering, Scene changing, Network disconnection, IP address conflict, Illegal access, Storage anomaly
IVS
Tripwire, Intrusion
Video
Compression
H.265/H.264H/MJPEG(Sub Stream)
Smart Codec
Support H.265+/H.264+
Streaming Capability
2 Streams
Resolution
1080P(1920×1080)/1.3M(1280×960)/
720P(1280×720)/D1(704×576/704×480)/ VGA(640×480)/CIF(352×288/352×240)
Frame Rate
Main Stream: 1080P(1 ~ 25/30fps)
Sub Stream: D1(1 ~ 25/30fps)
Bit Rate Control
CBR/VBR
Bit Rate
H.265: 12K ~ 6400Kbps
H.264: 32K ~ 10240Kbps
Day/Night
Auto(ICR) / Color / B/W
BLC Mode
BLC / HLC / DWDR
White Balance
Auto/Natural/Street Lamp/Outdoor/Manual
Gain Control
Auto/Manual
Noise Reduction
3D DNR
Motion Detection
Off / On (4 Zone, Rectangle)
Region of Interest
Off / On (4 Zone)
Electronic Image
Support
Smart IR
Support
Digital Zoom
16x
Flip
0°/90°/180°/270°
Mirror
Off / On
Privacy Masking
Off / On (4 Area, Rectangle)
Audio
Compression
N/A
Network
Ethernet
RJ-45 (10/100Base-T)
Protocol
HTTP;HTTPs;TCP;ARP;RTSP;RTP;RTCP;UDP;SMTP;
FTP;DHCP;DNS;DDNS;PPPoE;IPv4/v6;QoS;UPnP;
NTP;Bonjour;IEEE 802.1x;Multicast;ICMP;IGMP;
TLS
Interoperability
ONVIF Profile S&G, API
Streaming Method
Unicast / Multicast
Max. User Access
10 Users / 20 Users
Edge Storage
NAS
Local PC for instant recording
Web Viewer
IE, Chrome, Firefox, Safari
Management Software
Smart PSS, DSS, DMSS
Smart Phone
IOS, Android
Certifications
Certifications
CE (EN 60950:2000)
UL:UL60950-1
FCC: FCC Part 15 Subpart B
Interface
Video Interface
N/A
Audio Interface
N/A
RS485
N/A
Alarm
N/A
Electrical
Power Supply
DC12V, PoE (802.3af)(Class 0)
Power Consumption
<5.5W Environmental Operating Conditions -30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH Strorage Conditions -30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH Ingress Protection IP67 Vandal Resistance N/A Construction Casing Metal+Plastic Dimensions **70mm×164.7mm(2.76”x6.49”) Net Weight 0.38Kg(0.84lb) Gross Weight 0.44Kg(0.97lb
-
Add to cartDahua DH-IPC-HFW2831TP-AS-0600B-S2(80m IR) IP Camera
Camera
Image Sensor
1/2.7” 8Megapixel progressive CMOS
Max. Resolution
3840 (H) × 2160 (V)
ROM
128 MB
RAM
256 MB
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual 1/3 s–1/100,000 s
S/N Ratio
> 56 dB
Min. Illumination
0.009 Lux@F2.0
Illumination Distance
80 m (262.5 ft)
Illuminator On/Off Control
Auto/Manual
Illuminator Number
4 (IR LED)
Pan/Tilt/Rotation Range
Pan: 0°–360°
Tilt: 0°–90°
Rotation: 0°–360°
Lens
Lens Type
Fixed-focal
Mount Type
M12
Focal Length
3.6 mm
6 mm
Max. Aperture
3.6 mm: F2.0
6 mm: F2.0
Field of View
3.6 mm: Horizontal 87° × Vertical 47° × Diagonal 104°
6 mm: Horizontal 54° × Vertical 31° × Diagonal 61°
Iris Type
Fixed
Close Focus Distance
3.6 mm: 1.9 m (6.2 ft)
6 mm: 3.7 m (12.1 ft)
DORI Distance
Lens
Detect
Observe
Recognize
Identify
3.6 mm
106.7 m
(350.1 ft)42.7 m
(140.1 ft)21.3 m
(69.9 ft)10.7 m
(35.1 ft)6 mm
160 m
(524.9 ft)64.0 m
(210.0 ft)32.0 m
(105.0 ft)16.0 m
(52.5 ft)Smart Event
IVS
Tripwire; intrusion
Video
Video Compression
H.265; H.264; H.264B; MJPEG (only supported
by sub stream)
Smart Codec
Smart H.265+/ Smart H.264+
Video Frame Rate
Main stream:
3840 × 2160 (1 fps–15 fps)
2688 × 1520 (1 fps–25/30 fps)
Sub stream:
704 × 576 (1 fps–25 fps)
704 × 480 (1 fps–30 fps)
Stream Capability
2 streams
Resolution
3840 × 2160 (3840 × 2160); 3072 × 2048 (3072 × 2048); 3072 ×1728 (3072 × 1728); 2592 × 1944 (2592 × 1944); 2688 × 1520 (2688 × 1520); 3M (2048 × 1536); 2304 × 1296 (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
Bit Rate Control
CBR/VBR
Video Bit Rate
H.264: 32 kbps–8192 kbps
H.265: 12 kbps–8192 kbps
Day/Night
Auto(ICR)/Color/B/W
BLC
Yes
HLC
Yes
WDR
120 dB
White Balance
Auto/natural/street lamp/outdoor/manual/regional custom
Gain Control
Auto/Manual
Noise Reduction
3D DNR
Motion Detection
OFF/ON (4 areas, rectangular)
Region of Interest(RoI)
Yes (4 areas)
Smart Illumination
Yes
Image Rotation
0°/90°/180°/270° (Supports 90°/270° with 3840 × 2160 resolution and lower)
Mirror
Yes
Privacy Masking
4 areas
Audio
Audio Compression
G.711a; G.711Mu; G.726; AAC
Alarm
Alarm Event
No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; audio detection; voltage detection; security exception; local alarm
Network
Network
RJ-45 (10/100 Base-T)
SDK and API
Yes
Protocol
IPv4; IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; 802.1x; Bonjour
Interoperability
ONVIF (Profile S/Profile G/Profile T); CGI; Milestone; Genetec; P2P
User/Host
20
Edge Storage
Dahua Cloud; FTP; SFTP; Micro SD Card (support max. 256 GB); NAS
Browser
IE
Chrome
FirefoxManagement Software
Smart PSS; DSS; DMSS
Mobile Phone
IOS; Android
Certification
Certifications
CE-LVD: EN60950-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07Port
Audio Input
1 channel (RCA port)
Audio Output
1 channel (RCA port)
Alarm Input
1 channel in: 5mA 3V–5V DC
Alarm Output
1 channel out: 300mA 12V DC
Power
Power Supply
12V DC/PoE (802.3af)
Power Consumption
< 8.4W Environment Operating Conditions –40°C to +60°C (–40°F to +140°F)/less than ** 95% RH Storage Temperature –40°C to +60°C (–40°F to +140°F) Protection IP67; IK10(optional) Structure Casing Metal Dimensions 244.1 mm × **90.4 mm (9.61** × **3.26**) Net Weight 0.88 kg (1.9 lb) Gross Weight 1.15 kg (2.5 lb)
-
Add to cart
Dahua DH-IPC-HFW2831TP-AS-0600B-S2(80m IR) IP Camera
Camera
Image Sensor
1/2.7” 8Megapixel progressive CMOS
Max. Resolution
3840 (H) × 2160 (V)
ROM
128 MB
RAM
256 MB
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual 1/3 s–1/100,000 s
S/N Ratio
> 56 dB
Min. Illumination
0.009 Lux@F2.0
Illumination Distance
80 m (262.5 ft)
Illuminator On/Off Control
Auto/Manual
Illuminator Number
4 (IR LED)
Pan/Tilt/Rotation Range
Pan: 0°–360°
Tilt: 0°–90°
Rotation: 0°–360°
Lens
Lens Type
Fixed-focal
Mount Type
M12
Focal Length
3.6 mm
6 mm
Max. Aperture
3.6 mm: F2.0
6 mm: F2.0
Field of View
3.6 mm: Horizontal 87° × Vertical 47° × Diagonal 104°
6 mm: Horizontal 54° × Vertical 31° × Diagonal 61°
Iris Type
Fixed
Close Focus Distance
3.6 mm: 1.9 m (6.2 ft)
6 mm: 3.7 m (12.1 ft)
DORI Distance
Lens
Detect
Observe
Recognize
Identify
3.6 mm
106.7 m
(350.1 ft)42.7 m
(140.1 ft)21.3 m
(69.9 ft)10.7 m
(35.1 ft)6 mm
160 m
(524.9 ft)64.0 m
(210.0 ft)32.0 m
(105.0 ft)16.0 m
(52.5 ft)Smart Event
IVS
Tripwire; intrusion
Video
Video Compression
H.265; H.264; H.264B; MJPEG (only supported
by sub stream)
Smart Codec
Smart H.265+/ Smart H.264+
Video Frame Rate
Main stream:
3840 × 2160 (1 fps–15 fps)
2688 × 1520 (1 fps–25/30 fps)
Sub stream:
704 × 576 (1 fps–25 fps)
704 × 480 (1 fps–30 fps)
Stream Capability
2 streams
Resolution
3840 × 2160 (3840 × 2160); 3072 × 2048 (3072 × 2048); 3072 ×1728 (3072 × 1728); 2592 × 1944 (2592 × 1944); 2688 × 1520 (2688 × 1520); 3M (2048 × 1536); 2304 × 1296 (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
Bit Rate Control
CBR/VBR
Video Bit Rate
H.264: 32 kbps–8192 kbps
H.265: 12 kbps–8192 kbps
Day/Night
Auto(ICR)/Color/B/W
BLC
Yes
HLC
Yes
WDR
120 dB
White Balance
Auto/natural/street lamp/outdoor/manual/regional custom
Gain Control
Auto/Manual
Noise Reduction
3D DNR
Motion Detection
OFF/ON (4 areas, rectangular)
Region of Interest(RoI)
Yes (4 areas)
Smart Illumination
Yes
Image Rotation
0°/90°/180°/270° (Supports 90°/270° with 3840 × 2160 resolution and lower)
Mirror
Yes
Privacy Masking
4 areas
Audio
Audio Compression
G.711a; G.711Mu; G.726; AAC
Alarm
Alarm Event
No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; audio detection; voltage detection; security exception; local alarm
Network
Network
RJ-45 (10/100 Base-T)
SDK and API
Yes
Protocol
IPv4; IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; 802.1x; Bonjour
Interoperability
ONVIF (Profile S/Profile G/Profile T); CGI; Milestone; Genetec; P2P
User/Host
20
Edge Storage
Dahua Cloud; FTP; SFTP; Micro SD Card (support max. 256 GB); NAS
Browser
IE
Chrome
FirefoxManagement Software
Smart PSS; DSS; DMSS
Mobile Phone
IOS; Android
Certification
Certifications
CE-LVD: EN60950-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07Port
Audio Input
1 channel (RCA port)
Audio Output
1 channel (RCA port)
Alarm Input
1 channel in: 5mA 3V–5V DC
Alarm Output
1 channel out: 300mA 12V DC
Power
Power Supply
12V DC/PoE (802.3af)
Power Consumption
< 8.4W Environment Operating Conditions –40°C to +60°C (–40°F to +140°F)/less than ** 95% RH Storage Temperature –40°C to +60°C (–40°F to +140°F) Protection IP67; IK10(optional) Structure Casing Metal Dimensions 244.1 mm × **90.4 mm (9.61** × **3.26**) Net Weight 0.88 kg (1.9 lb) Gross Weight 1.15 kg (2.5 lb)
-
Add to cartDahua DH-IPC-HFW2831TP-ZS-27135-S2 8MP (4K) WDR IR Bullet Camera
Camera
Image Sensor
1/2.7” 8Megapixel progressive CMOS
Max. Resolution
3840 (H) × 2160 (V)
ROM
128 MB
RAM
256 MB
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual 1/3 s–1/100,000 s
Min. Illumination
0.008 Lux@F1.5
S/N Ratio
>56 dB
Illumination Distance
60 m (196.85 ft)
Illuminator On/Off Control
Auto/Manual
Illuminator Number
4 (IR LED)
Pan/Tilt/Rotation Range
Pan: 0°–360°
Tilt: 0°–90°
Rotation: 0°–360°
Lens
Lens Type
Motorized vari-focal
Mount Type
**14
Focal Length
2.7 mm–13.5 mm
Max. Aperture
F1.5
Field of View
Horizontal: 113°–31°
Vertical: 58°–17°
Diagonal: 138°–36°
Iris Type
Fixed
Close Focus Distance
0.8 m–0.8 m (2.62 ft–2.62 ft)
DORI Distance
Lens
Detect
Observe
Recognize
Identify
W
85.3 m
(279.9 ft)
34.1 m
(111.9 ft)
17 m
(55.8 ft)
8.5 m
(27.9 ft)
T
280 m
(918.6 ft)
112 m
(367.5 ft)
56 m
(183.7 ft)
28 m
(91.9 ft)
Smart Event
IVS
Tripwire; intrusion
Video
Video Compression
H.265; H.264; H.264B; MJPEG (only supported by the sub stream)
Smart Codec
Smart H.265+/ Smart H.264+
Video Frame Rate
Main stream:
3840 × 2160 (1 fps–15 fps)
2688 × 1520 (1 fps–25/30 fps)
Sub stream:
704 × 576 (1 fps–25 fps)
704 × 480 (1 fps–30 fps)
Stream Capability
2 streams
Resolution
3840 × 2160 (3840 × 2160); 3072 × 2048 (3072 × 2048); 3072 ×1728 (3072 × 1728); 2592 × 1944 (2592 × 1944); 2688 × 1520 (2688 × 1520); 3M (2048 × 1536); 2304 × 1296 (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
Bit Rate Control
CBR/VBR
Video Bit Rate
H.264: 32 kbps–8192 kbps
H.265: 12 kbps–8192 kbps
Day/Night
Auto(ICR)/Color/B/W
BLC
Yes
HLC
Yes
WDR
120 dB
White Balance
Auto/natural/street lamp/outdoor/manual/regional custom
Gain Control
Auto/Manual
Noise Reduction
3D NR
Motion Detection
OFF/ON (4 areas, rectangular)
Region of Interest(RoI)
Yes (4 areas)
Smart Illumination
Yes
Image Rotation
0°/90°/180°/270° (Supports 90°/270° with 2688 × 1520 resolution and lower.)
Mirror
Yes
Privacy Masking
4 areas
Alarm
Alarm Event
No SD card; SD card full; SD card error; network disconnection; IP conflict; motion detection; video tampering; tripwire; intrusion; illegal access; voltage detection; safety exception
Network
Network
RJ-45 (10/100 Base-T)
SDK and API
Yes
Cyber Security
Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade
Protocol
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; Bonjour
Interoperability
ONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone; Genetec
User/Host
20
Storage
FTP; Micro SD card (support max. 256 G); NAS; SFTP
Browser
IE
Chrome
FirefoxManagement Software
Smart PSS; DSS; DMSS
Mobile Phone
IOS; Android
Certification
Certifications
CE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07Power
Power Supply
12V DC/PoE (802.3af)
Power Consumption
< 9.9W Environment Operating Conditions –30°C to +60°C (–22°F to +140°F)/less than ** 95% RH Storage Temperature –40°C to +60°C (–40°F to +140°F) Protection IP67 Structure Casing Metal Dimensions **244.1 mm × 90.4 mm (**9.61** × 3.26**) Net Weight 0.86 kg (1.90 lb) Gross Weight 1.10 kg (2.43 lb)
-
Add to cart
Dahua DH-IPC-HFW2831TP-ZS-27135-S2 8MP (4K) WDR IR Bullet Camera
Camera
Image Sensor
1/2.7” 8Megapixel progressive CMOS
Max. Resolution
3840 (H) × 2160 (V)
ROM
128 MB
RAM
256 MB
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual 1/3 s–1/100,000 s
Min. Illumination
0.008 Lux@F1.5
S/N Ratio
>56 dB
Illumination Distance
60 m (196.85 ft)
Illuminator On/Off Control
Auto/Manual
Illuminator Number
4 (IR LED)
Pan/Tilt/Rotation Range
Pan: 0°–360°
Tilt: 0°–90°
Rotation: 0°–360°
Lens
Lens Type
Motorized vari-focal
Mount Type
**14
Focal Length
2.7 mm–13.5 mm
Max. Aperture
F1.5
Field of View
Horizontal: 113°–31°
Vertical: 58°–17°
Diagonal: 138°–36°
Iris Type
Fixed
Close Focus Distance
0.8 m–0.8 m (2.62 ft–2.62 ft)
DORI Distance
Lens
Detect
Observe
Recognize
Identify
W
85.3 m
(279.9 ft)
34.1 m
(111.9 ft)
17 m
(55.8 ft)
8.5 m
(27.9 ft)
T
280 m
(918.6 ft)
112 m
(367.5 ft)
56 m
(183.7 ft)
28 m
(91.9 ft)
Smart Event
IVS
Tripwire; intrusion
Video
Video Compression
H.265; H.264; H.264B; MJPEG (only supported by the sub stream)
Smart Codec
Smart H.265+/ Smart H.264+
Video Frame Rate
Main stream:
3840 × 2160 (1 fps–15 fps)
2688 × 1520 (1 fps–25/30 fps)
Sub stream:
704 × 576 (1 fps–25 fps)
704 × 480 (1 fps–30 fps)
Stream Capability
2 streams
Resolution
3840 × 2160 (3840 × 2160); 3072 × 2048 (3072 × 2048); 3072 ×1728 (3072 × 1728); 2592 × 1944 (2592 × 1944); 2688 × 1520 (2688 × 1520); 3M (2048 × 1536); 2304 × 1296 (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
Bit Rate Control
CBR/VBR
Video Bit Rate
H.264: 32 kbps–8192 kbps
H.265: 12 kbps–8192 kbps
Day/Night
Auto(ICR)/Color/B/W
BLC
Yes
HLC
Yes
WDR
120 dB
White Balance
Auto/natural/street lamp/outdoor/manual/regional custom
Gain Control
Auto/Manual
Noise Reduction
3D NR
Motion Detection
OFF/ON (4 areas, rectangular)
Region of Interest(RoI)
Yes (4 areas)
Smart Illumination
Yes
Image Rotation
0°/90°/180°/270° (Supports 90°/270° with 2688 × 1520 resolution and lower.)
Mirror
Yes
Privacy Masking
4 areas
Alarm
Alarm Event
No SD card; SD card full; SD card error; network disconnection; IP conflict; motion detection; video tampering; tripwire; intrusion; illegal access; voltage detection; safety exception
Network
Network
RJ-45 (10/100 Base-T)
SDK and API
Yes
Cyber Security
Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade
Protocol
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; Bonjour
Interoperability
ONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone; Genetec
User/Host
20
Storage
FTP; Micro SD card (support max. 256 G); NAS; SFTP
Browser
IE
Chrome
FirefoxManagement Software
Smart PSS; DSS; DMSS
Mobile Phone
IOS; Android
Certification
Certifications
CE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07Power
Power Supply
12V DC/PoE (802.3af)
Power Consumption
< 9.9W Environment Operating Conditions –30°C to +60°C (–22°F to +140°F)/less than ** 95% RH Storage Temperature –40°C to +60°C (–40°F to +140°F) Protection IP67 Structure Casing Metal Dimensions **244.1 mm × 90.4 mm (**9.61** × 3.26**) Net Weight 0.86 kg (1.90 lb) Gross Weight 1.10 kg (2.43 lb)
-
Add to cartDahua DH-IPC-HFW3449EP-AS-LED 4MP WizSense Bullet Camera
Camera
Image Sensor
1/2.7”4Megapixel progressive CMOS
Max. Resolution
2688 (H) ×1520 (V)
ROM
128 MB
RAM
512 MB
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual 1/3 s–1/100, 000 s
Min. Illumination
0.003 Lux@F1.0
S/N Ratio
> 56 dB
Illumination Distance
30 m (98.4 ft)
Illuminator On/Off Control
Auto/Manual
Illuminator Number
1 (warm LED)
Pan/Tilt/Rotation Range
Horizontal:0°-360°;Vertical:0°-90°;Rotation:0°-360°
Lens
Lens Type
Fixed-focal
Mount Type
M12
Focal Length
2.8 mm; 3.6 mm
Max. Aperture
F1.0
Field of View
2.8 mm: Horizontal 103° × vertical 53° × diagonal 122°
3.6 mm: Horizontal 80° × vertical 43° × diagonal 95°
Iris Type
Fixed
Close Focus Distance
2.8 mm: 1.2 m (3.9 ft)
3.6 mm: 2.4 m (7.9 ft)
DORI Distance
Lens
Detect
Observe
Recognize
Identify
2.8mm
56.0 m
(183.7 ft)
22.4 m
(73.5 ft)
11.2 m
(36.7 ft)
5.6 m
(18.4 ft)
3.6mm
80.0 m
(262.5 ft)
32.0 m
(105.0 ft)
16.0 m
(52.5 ft)
8.0 m
(26.3 ft)
Professional, Intelligent
Perimeter Protection
Tripwire, intrusion (Recognition of vehicle and people)
Intelligent Search
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos
Video
Video Compression
H.265; H.264; H.264H; H.264B; MJPEG(only supported by the sub stream)
Smart Codec
Smart H.265+/ Smart H.264+
Video Frame Rate
Main stream (2688 × 1520 @ 1–25/30 fps)
sub stream (704 × 576 @ 1–25/704 × 480 @ 1-30 fps)
third stream (1280 × 720 @ 1–25/30 fps)Stream Capability
3 streams
Resolution
4M (2688 × 1520); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
Bit Rate Control
CBR; VBR
Video Bit Rate
H.264: 3 kbps–8192 kbps
H.265: 3 kbps–8192 kbpsDay/Night
Color/B/W
BLC
Yes
WDR
120 dB
White Balance
Auto/natural/street lamp/outdoor/manual/regional custom
Gain Control
Auto/Manual
Noise Reduction
3D DNR
Motion Detection
OFF/ON (4 areas, rectangular)
Region of Interest (RoI)
Yes (4 areas)
Smart Illumination
Yes
Image Rotation
0°/90°/180°/270° (Support 90°/270° with 1920 × 1080 resolution and lower.)
Mirror
Yes
Privacy Masking
4 areas
Audio
Built-in MIC
Yes
Audio Compression
G.711a; G.711Mu; G726
Alarm
Alarm Event
No SD card; SD card full; SD card error; less service time of SD card (smart card supports); network disconnection; IP conflict; illegal access; voltage detection; security exception; motion detection; video tampering; scene changing; input abnormal; intensity change; tripwire; intrusion; SMD
Network
Network
RJ-45 (10/100 Base-T)
SDK and API
Yes
Protocol
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; SNMP
Cyber Security
Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade
Interoperability
ONVIF(Profile S/Profile G/Profile T);CGI;P2P;Milestone;
Genetec
Scene self-adaptation (SSA)
Yes
User/Host
20 (Total bandwidth: 64M.)
Storage
FTP; SFTP; Micro SD Card (support max. 256 G); NAS
Browser
IE: IE8; IE9; IE11
Chrome
FirefoxManagement Software
Smart PSS; DSS; DMSS
Mobile Phone
IOS; Android
Certification
Certifications
CE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07Port
Audio Input
1 channel (RCA port)
Audio Output
1 channel (RCA port)
Alarm Input
1 channel in: 5mA 3V–5V DC
Alarm Output
1 channel out: 300mA 12V DC
Power
Power Supply
12V DC/PoE
Power Consumption
< 8.4W Environment Operating Conditions -40°C to +60°C (-40°F to +140°F)/less than 95% Storage Conditions -40°C to +60°C (-40°F to +140°F) Protection Grade IP67 Structure Casing Metal Dimensions 192.7 mm × 70.5 mm × 66.4 mm (7.6”×2.8”×2.6”) (L × W × H) Net Weight 590 g (1.3 lb) Gross Weight 780 g (1.7 lb)
-
Add to cart
Dahua DH-IPC-HFW3449EP-AS-LED 4MP WizSense Bullet Camera
Camera
Image Sensor
1/2.7”4Megapixel progressive CMOS
Max. Resolution
2688 (H) ×1520 (V)
ROM
128 MB
RAM
512 MB
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual 1/3 s–1/100, 000 s
Min. Illumination
0.003 Lux@F1.0
S/N Ratio
> 56 dB
Illumination Distance
30 m (98.4 ft)
Illuminator On/Off Control
Auto/Manual
Illuminator Number
1 (warm LED)
Pan/Tilt/Rotation Range
Horizontal:0°-360°;Vertical:0°-90°;Rotation:0°-360°
Lens
Lens Type
Fixed-focal
Mount Type
M12
Focal Length
2.8 mm; 3.6 mm
Max. Aperture
F1.0
Field of View
2.8 mm: Horizontal 103° × vertical 53° × diagonal 122°
3.6 mm: Horizontal 80° × vertical 43° × diagonal 95°
Iris Type
Fixed
Close Focus Distance
2.8 mm: 1.2 m (3.9 ft)
3.6 mm: 2.4 m (7.9 ft)
DORI Distance
Lens
Detect
Observe
Recognize
Identify
2.8mm
56.0 m
(183.7 ft)
22.4 m
(73.5 ft)
11.2 m
(36.7 ft)
5.6 m
(18.4 ft)
3.6mm
80.0 m
(262.5 ft)
32.0 m
(105.0 ft)
16.0 m
(52.5 ft)
8.0 m
(26.3 ft)
Professional, Intelligent
Perimeter Protection
Tripwire, intrusion (Recognition of vehicle and people)
Intelligent Search
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos
Video
Video Compression
H.265; H.264; H.264H; H.264B; MJPEG(only supported by the sub stream)
Smart Codec
Smart H.265+/ Smart H.264+
Video Frame Rate
Main stream (2688 × 1520 @ 1–25/30 fps)
sub stream (704 × 576 @ 1–25/704 × 480 @ 1-30 fps)
third stream (1280 × 720 @ 1–25/30 fps)Stream Capability
3 streams
Resolution
4M (2688 × 1520); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
Bit Rate Control
CBR; VBR
Video Bit Rate
H.264: 3 kbps–8192 kbps
H.265: 3 kbps–8192 kbpsDay/Night
Color/B/W
BLC
Yes
WDR
120 dB
White Balance
Auto/natural/street lamp/outdoor/manual/regional custom
Gain Control
Auto/Manual
Noise Reduction
3D DNR
Motion Detection
OFF/ON (4 areas, rectangular)
Region of Interest (RoI)
Yes (4 areas)
Smart Illumination
Yes
Image Rotation
0°/90°/180°/270° (Support 90°/270° with 1920 × 1080 resolution and lower.)
Mirror
Yes
Privacy Masking
4 areas
Audio
Built-in MIC
Yes
Audio Compression
G.711a; G.711Mu; G726
Alarm
Alarm Event
No SD card; SD card full; SD card error; less service time of SD card (smart card supports); network disconnection; IP conflict; illegal access; voltage detection; security exception; motion detection; video tampering; scene changing; input abnormal; intensity change; tripwire; intrusion; SMD
Network
Network
RJ-45 (10/100 Base-T)
SDK and API
Yes
Protocol
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; SNMP
Cyber Security
Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade
Interoperability
ONVIF(Profile S/Profile G/Profile T);CGI;P2P;Milestone;
Genetec
Scene self-adaptation (SSA)
Yes
User/Host
20 (Total bandwidth: 64M.)
Storage
FTP; SFTP; Micro SD Card (support max. 256 G); NAS
Browser
IE: IE8; IE9; IE11
Chrome
FirefoxManagement Software
Smart PSS; DSS; DMSS
Mobile Phone
IOS; Android
Certification
Certifications
CE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07Port
Audio Input
1 channel (RCA port)
Audio Output
1 channel (RCA port)
Alarm Input
1 channel in: 5mA 3V–5V DC
Alarm Output
1 channel out: 300mA 12V DC
Power
Power Supply
12V DC/PoE
Power Consumption
< 8.4W Environment Operating Conditions -40°C to +60°C (-40°F to +140°F)/less than 95% Storage Conditions -40°C to +60°C (-40°F to +140°F) Protection Grade IP67 Structure Casing Metal Dimensions 192.7 mm × 70.5 mm × 66.4 mm (7.6”×2.8”×2.6”) (L × W × H) Net Weight 590 g (1.3 lb) Gross Weight 780 g (1.7 lb)
-
Add to cartDahua DH-IPC-HFW3841-EP-AS 8MP WizSense network camera
Camera
Image Sensor
1/2.8”8Megapixel progressive CMOS
Max. Resolution
3840 (H) × 2160 (V)
ROM
128 MB
RAM
512 MB
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual 1/3 s–1/100,000 s
Min. Illumination
0.007 Lux@F1.4 (Color, 30IRE)
0.0007 Lux@F1.4 (B/W, 30IRE)
0 Lux (Illuminator on)
S/N Ratio
> 56 dB
Illumination Distance
30 m (98.4 ft)
Illuminator On/Off Control
Auto/Manual
Illuminator Number
1 (IR LED)
Pan/Tilt/Rotation Range
Pan: 0°–360°
Tilt: 0°–90°
Rotation: 0°–360°Lens
Lens Type
Fixed-focal
Mount Type
M12
Focal Length
2.8 mm; 3.6 mm
Max. Aperture
F1.4
Field of View
2.8 mm: Horizontal 108° × Vertical 58° × Diagonal 127°
3.6 mm: Horizontal 85° × Vertical 45° × Diagonal 100°Iris Type
Fixed
Close Focus Distance
2.8 mm: 1.4 m (4.6 ft)
3.6 mm: 2.4 m (7.9 ft)DORI Distance
Lens
Detect
Observe
Recognize
Identify
2.8 mm
85.5 m (280.5 ft)
34.2 m
(112.2 ft)
17.1 m
(56.1 ft)
8.6 m
(28.2 ft)
3.6 mm
110.3 m (361.9 ft)
44.1 m
(144.7 ft)
22.1 m
(72.5 ft)
11.0 m
(36.1 ft)
Professional, intelligent
Perimeter Protection
Tripwire; intrusion (support the classification and accurate detection of vehicle and human)
Intelligent Search
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos.
Video
Video Compression
H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream)
Smart Codec
Smart H.265+/ Smart H.264+
Video Frame Rate
Main stream:
3840 × 2160 @(1–20 fps by default)
3840 × 2160 @(1–25/30 fps when AI function disabled)
sub stream:
704 × 576 @(1–25 fps)/704 × 480 @ (1–30 fps)
third stream:
1920 × 1080 @(1–25/30 fps)
Stream Capability
3 streams
Resolution
8M (3840 × 2160); 6M (3072 × 2048); 5M (3072 × 1728/2592 × 1944); 4M (2688 × 1520); 3M (2048 × 1536/2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1(704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
Bit Rate Control
CBR/VBR
Video Bit Rate
H.264: 3 kbps–8192 kbps
H.265: 3 kbps–8192 kbps
Day/Night
Auto (ICR)/Color/B/W
BLC
Yes
HLC
Yes
WDR
120 dB
Scene Self-adaptation (SSA)
Yes
White Balance
Auto/natural/street lamp/outdoor/manual/regional custom
Gain Control
Auto/Manual
Noise Reduction
3D DNR
Motion Detection
OFF/ON (4 areas, rectangular)
Region of Interest (RoI)
Yes (4 areas)
Smart Illumination
Yes
Image Rotation
0°/90°/180°/270° (Support 90°/270° with 1080p resolution and lower.)
Mirror
Yes
Privacy Masking
4 areas
Audio
Built-in MIC
Yes
Audio Compression
G.711a; G.711Mu; G726
Alarm
Alarm Event
– AS:
No SD card; SD card full; SD card error; service life warning (only supported by Dahua card); network disconnection; IP conflict; illegal access; motion detection; video tampering; intrusion; tripwire; scene changing; audio detection; voltage detection; external alarm; SMD; safety exception
-SA:
No SD card; SD card full; SD card error; service life warning (only supported by Dahua card); network disconnection; IP conflict; illegal access; motion detection; video tampering; intrusion; tripwire; scene changing; audio detection; voltage detection; SMD; safety exceptionNetwork
Network
RJ-45 (10/100 Base-T)
SDK and API
Yes
Protocol
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP
Cyber Security
Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade
Interoperability
ONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone; Genetec
User/Host
20 (Total bandwidth: 72 M)
Storage
FTP; SFTP; Micro SD card (support max. 256 G); NAS
Browser
IE: IE8; IE9; IE11
Chrome
FirefoxManagement Software
Smart PSS; DSS; DMSS
Mobile Phone
IOS; Android
Certification
Certifications
CE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07Port
Audio Input
1 channel (RCA port) (Only – AS supports)
Audio Output
1 channel (RCA port) (Only – AS supports)
Alarm Input
1 channel in: 5mA 3V–5V DC (Only – AS supports)
Alarm Output
1 channel out: 300mA 12V DC (Only – AS supports)
Power
Power Supply
12V DC/PoE (802.3af)
Power Consumption
Basic power consumption: 3W (12V DC); 3.5W (PoE)
Max. power consumption (WDR + H.265 + IR LED intensity): 5.5W (12V DC); 6.3W (PoE)
Environment
Operating Conditions
–40°C to +60°C (–40°F to +140°F)/Less than 95% RH
Storage Conditions
–40°C to +60°C (–40°F to +140°F)
Protection Grade
IP67
Structure
Casing
Metal
Dimensions
192.7 mm × 70.5 mm × 66.4 mm (7.6** × 2.8** × 2.6**) (L × W × H)
Net Weight
590 g (1.3 lb)
Gross Weight
780 g (1.7 lb)
-
Add to cart
Dahua DH-IPC-HFW3841-EP-AS 8MP WizSense network camera
Camera
Image Sensor
1/2.8”8Megapixel progressive CMOS
Max. Resolution
3840 (H) × 2160 (V)
ROM
128 MB
RAM
512 MB
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual 1/3 s–1/100,000 s
Min. Illumination
0.007 Lux@F1.4 (Color, 30IRE)
0.0007 Lux@F1.4 (B/W, 30IRE)
0 Lux (Illuminator on)
S/N Ratio
> 56 dB
Illumination Distance
30 m (98.4 ft)
Illuminator On/Off Control
Auto/Manual
Illuminator Number
1 (IR LED)
Pan/Tilt/Rotation Range
Pan: 0°–360°
Tilt: 0°–90°
Rotation: 0°–360°Lens
Lens Type
Fixed-focal
Mount Type
M12
Focal Length
2.8 mm; 3.6 mm
Max. Aperture
F1.4
Field of View
2.8 mm: Horizontal 108° × Vertical 58° × Diagonal 127°
3.6 mm: Horizontal 85° × Vertical 45° × Diagonal 100°Iris Type
Fixed
Close Focus Distance
2.8 mm: 1.4 m (4.6 ft)
3.6 mm: 2.4 m (7.9 ft)DORI Distance
Lens
Detect
Observe
Recognize
Identify
2.8 mm
85.5 m (280.5 ft)
34.2 m
(112.2 ft)
17.1 m
(56.1 ft)
8.6 m
(28.2 ft)
3.6 mm
110.3 m (361.9 ft)
44.1 m
(144.7 ft)
22.1 m
(72.5 ft)
11.0 m
(36.1 ft)
Professional, intelligent
Perimeter Protection
Tripwire; intrusion (support the classification and accurate detection of vehicle and human)
Intelligent Search
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos.
Video
Video Compression
H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream)
Smart Codec
Smart H.265+/ Smart H.264+
Video Frame Rate
Main stream:
3840 × 2160 @(1–20 fps by default)
3840 × 2160 @(1–25/30 fps when AI function disabled)
sub stream:
704 × 576 @(1–25 fps)/704 × 480 @ (1–30 fps)
third stream:
1920 × 1080 @(1–25/30 fps)
Stream Capability
3 streams
Resolution
8M (3840 × 2160); 6M (3072 × 2048); 5M (3072 × 1728/2592 × 1944); 4M (2688 × 1520); 3M (2048 × 1536/2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1(704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
Bit Rate Control
CBR/VBR
Video Bit Rate
H.264: 3 kbps–8192 kbps
H.265: 3 kbps–8192 kbps
Day/Night
Auto (ICR)/Color/B/W
BLC
Yes
HLC
Yes
WDR
120 dB
Scene Self-adaptation (SSA)
Yes
White Balance
Auto/natural/street lamp/outdoor/manual/regional custom
Gain Control
Auto/Manual
Noise Reduction
3D DNR
Motion Detection
OFF/ON (4 areas, rectangular)
Region of Interest (RoI)
Yes (4 areas)
Smart Illumination
Yes
Image Rotation
0°/90°/180°/270° (Support 90°/270° with 1080p resolution and lower.)
Mirror
Yes
Privacy Masking
4 areas
Audio
Built-in MIC
Yes
Audio Compression
G.711a; G.711Mu; G726
Alarm
Alarm Event
– AS:
No SD card; SD card full; SD card error; service life warning (only supported by Dahua card); network disconnection; IP conflict; illegal access; motion detection; video tampering; intrusion; tripwire; scene changing; audio detection; voltage detection; external alarm; SMD; safety exception
-SA:
No SD card; SD card full; SD card error; service life warning (only supported by Dahua card); network disconnection; IP conflict; illegal access; motion detection; video tampering; intrusion; tripwire; scene changing; audio detection; voltage detection; SMD; safety exceptionNetwork
Network
RJ-45 (10/100 Base-T)
SDK and API
Yes
Protocol
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP
Cyber Security
Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade
Interoperability
ONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone; Genetec
User/Host
20 (Total bandwidth: 72 M)
Storage
FTP; SFTP; Micro SD card (support max. 256 G); NAS
Browser
IE: IE8; IE9; IE11
Chrome
FirefoxManagement Software
Smart PSS; DSS; DMSS
Mobile Phone
IOS; Android
Certification
Certifications
CE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07Port
Audio Input
1 channel (RCA port) (Only – AS supports)
Audio Output
1 channel (RCA port) (Only – AS supports)
Alarm Input
1 channel in: 5mA 3V–5V DC (Only – AS supports)
Alarm Output
1 channel out: 300mA 12V DC (Only – AS supports)
Power
Power Supply
12V DC/PoE (802.3af)
Power Consumption
Basic power consumption: 3W (12V DC); 3.5W (PoE)
Max. power consumption (WDR + H.265 + IR LED intensity): 5.5W (12V DC); 6.3W (PoE)
Environment
Operating Conditions
–40°C to +60°C (–40°F to +140°F)/Less than 95% RH
Storage Conditions
–40°C to +60°C (–40°F to +140°F)
Protection Grade
IP67
Structure
Casing
Metal
Dimensions
192.7 mm × 70.5 mm × 66.4 mm (7.6** × 2.8** × 2.6**) (L × W × H)
Net Weight
590 g (1.3 lb)
Gross Weight
780 g (1.7 lb)
Popular Products
-
Starlink In Person Verification Services In Kenya
KSh3,000.00
-
Starlink Gen 3 Case Compatible with Starlink Gen 3, Waterproof Starlink Standard Case, Shockproof Starlink Carrying Bag for Satellite Dish Accessories, Travel Bag for Camping and RV
-
STARLINK Gen3 Portable Accessory Storage Bag, Outdoor Camping, Portable Handbag, Made Of Polyester Material.
-
Carrying Bag For Starlink V4 Satellite Portable RV Outdoor Travel Bag Rectangular Storage Handbag For Starlink Gen3 Accessory
-
IsatPhone Link 50 Units - 30 Days
Validity
Products
-
Starlink In Person Verification Services In Kenya
KSh3,000.00
-
Starlink Gen 3 Case Compatible with Starlink Gen 3, Waterproof Starlink Standard Case, Shockproof Starlink Carrying Bag for Satellite Dish Accessories, Travel Bag for Camping and RV
-
STARLINK Gen3 Portable Accessory Storage Bag, Outdoor Camping, Portable Handbag, Made Of Polyester Material.
-
Carrying Bag For Starlink V4 Satellite Portable RV Outdoor Travel Bag Rectangular Storage Handbag For Starlink Gen3 Accessory
-
IsatPhone Link 50 Units - 30 Days
Validity
