Dahua DH-IPC- HDBW4631EP-ASE 6MP Mini Dome Network Camera – Kenya
KSh14,000.00
Dahua DH-IPC- HDBW4631EP-ASE 6MP Mini Dome Network Camera
1/2.9** 6Megapixel progressive scan STARVIS™ CMOS. H.265 & H.264 triple-stream encoding. 20fps@6MP(3072×2048). 25/30fps®4MP(2688xl520). Smart Detection supported. WDR(l20dB). Day/Night(ICR). 3DNR. AWB.AGC.BLC. Multiple network monitoring: Web viewer. MS(DSS/PSS) & DMSS. 2.8mm fixed lens. 1/1 Alarm in/out. 1/1 Audio in/out. Max. lR LEDs Length 30m. Micro SD memory. IP67. IKlO. ePoE
Key Features
1/2.9” 6Megapixel progressive scan STARVIS™ CMOS
H.265&H.264 triple-stream encoding
20fps@6MP(3072×2048), 25/30fps@4MP(2688×1520)
Smart Detection supported
WDR(120dB), Day/Night(ICR), 3DNR,AWB,AGC,BLC
Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
2.8mm fixed lens (3.6mm optional)
1/1 Alarm in/out, 1/1 audio in/out
Max. IR LEDs Length 30m
Micro SD memory, IP67, IK10, PoE
Dahua DH-IPC- HDBW4631EP-ASE 6MP Mini Dome Network Camera
1/2.9? 6Megapixel progressive scan STARVIS™ CMOS. H.265 & H.264 triple-stream encoding. 20fps@6MP(3072×2048). 25/30fps®4MP(2688xl520). Smart Detection supported. WDR(l20dB). Day/Night(ICR). 3DNR. AWB.AGC.BLC. Multiple network monitoring: Web viewer. MS(DSS/PSS) & DMSS. 2.8mm fixed lens. 1/1 Alarm in/out. 1/1 Audio in/out. Max. lR LEDs Length 30m. Micro SD memory. IP67. IKlO. ePoE
Key Features
1/2.9” 6Megapixel progressive scan STARVIS™ CMOS
H.265&H.264 triple-stream encoding
20fps@6MP(3072×2048), 25/30fps@4MP(2688×1520)
Smart Detection supported
WDR(120dB), Day/Night(ICR), 3DNR,AWB,AGC,BLC
Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
2.8mm fixed lens (3.6mm optional)
1/1 Alarm in/out, 1/1 audio in/out
Max. IR LEDs Length 30m
Micro SD memory, IP67, IK10, PoE
