360 degrees SX-360Z Motion Sensor – Kenya

Name: 360 degrees SX-360Z Motion Sensor - Kenya | +254720548999
SKU: 80f59adbeb2a
Price: 15000.00 KES
Availability: InStock

KSh15,000.00

360 degrees SX-360Z Motion Sensor Mtech

360 degrees SX-360Z Motion Sensor provides 360° of detection performance at any ceiling height up to 16** high. By simply twisting the unit’s domed lens, SX-360Z Motion Sensor detection pattern can be easily adjusted at any installation height, thereby making it a flexible ceiling detector. The 276 dense zones provide a 60** diameter detection area at any installation height from 8 to 16** with no dead spots. This, combined with its compact design,

SX-360Z 360 degrees Motion Sensor Specification
Technology Passive infrared
Installation Commercial, industrial, residential
Zones Interior
Detection Zones: 276
Coverage Ø 60** (Ø 18 m), 360° zoom
Mounting Ceiling Height: 8.0 to 16.0** (2.4 to 5.0 m)
Sensitivity 3.0°F (-16°C) at 2.0 ft/sec (0.6 m/sec)
Sensitivity Adjustment Low:** 30 to 40** (** 9 to 12 m)

Medium:

** 40 to 50** (** 12 to 15 m)

High:

** 50 to 60** (** 15 to 18 m)

Speed Detectable: 1 to 6 ft/sec ( 0.3 to 1.8 m/sec)
Indicators LED: Blinks during warm-up period
alarm condition
Alarm Period: 2.0 ±0.5 sec
Output: N.C, 28 VDC, 02.A maximum
Switch Tamper: N.C, opens when cover removed
Count Period Pulse: 2.0 ±5 sec, 1,2 or 4
Warm-Up Period Approximately 20 sec (LED blinks)
Wiring Wire Size:AWG22 (0.33 mm2)

At 12 V: 1,070** (320 m)

At 14 V: 2,140** (650 m)

AWG20 (0.52 mm2)

At 12 V: 1,700** (510 m)

At 14 V: 3,400** (1,020 m)
AWG18 (0.83 mm2)

At 12 V: 2,700** (820 m)

At 14 V: 5,300** (1,600 m)

Power Input 6 to 18 VDC
Current Draw 13 mA (normal), 18mA (maximum)
RF Interference No alarm 30 V/m
Humidity 95% maximum
Operating Temperature -4 to 122°F (-20 to 50°C)
Diameter 5.04** (128.00 mm)
Depth 2.46 to 2.88** (67.00 to 73.00 mm)
Weight 8 oz (224 g)

Optex SX-360Z 360° Ceiling Mount Indoor Passive Infrared Detector
SX-360Z 360 degrees Motion Sensor
Optex SX-360Z | 360 degree Ceiling-Mount PIR Detector

Description
Meta Information

360 degrees SX-360Z Motion Sensor Mtech

360 degrees SX-360Z Motion Sensor provides 360° of detection performance at any ceiling height up to 16? high. By simply twisting the unit’s domed lens, SX-360Z Motion Sensor detection pattern can be easily adjusted at any installation height, thereby making it a flexible ceiling detector. The 276 dense zones provide a 60? diameter detection area at any installation height from 8 to 16? with no dead spots. This, combined with its compact design,

SX-360Z 360 degrees Motion Sensor Specification
Technology Passive infrared
Installation Commercial, industrial, residential
Zones Interior
Detection Zones: 276
Coverage Ø 60? (Ø 18 m), 360° zoom
Mounting Ceiling Height: 8.0 to 16.0? (2.4 to 5.0 m)
Sensitivity 3.0°F (-16°C) at 2.0 ft/sec (0.6 m/sec)
Sensitivity Adjustment Low:? 30 to 40? (? 9 to 12 m)

Medium:

? 40 to 50? (? 12 to 15 m)

High:

? 50 to 60? (? 15 to 18 m)

At 12 V: 1,070? (320 m)

At 14 V: 2,140? (650 m)

AWG20 (0.52 mm2)

At 12 V: 1,700? (510 m)

At 14 V: 3,400? (1,020 m)
AWG18 (0.83 mm2)

At 12 V: 2,700? (820 m)

At 14 V: 5,300? (1,600 m)

Power Input 6 to 18 VDC
Current Draw 13 mA (normal), 18mA (maximum)
RF Interference No alarm 30 V/m
Humidity 95% maximum
Operating Temperature -4 to 122°F (-20 to 50°C)
Diameter 5.04? (128.00 mm)
Depth 2.46 to 2.88? (67.00 to 73.00 mm)
Weight 8 oz (224 g)

Optex SX-360Z 360° Ceiling Mount Indoor Passive Infrared Detector
SX-360Z 360 degrees Motion Sensor
Optex SX-360Z | 360 degree Ceiling-Mount PIR Detector

SKU: 80f59adbeb2a Category: Solutions Tag: 360 degrees SX-360Z Motion Sensor - Kenya Brand: Hikvision, SECOLINK, SECUGEN, Zkteco
