Alcad AL-245 Power supply 12/13/18 vdc 400 ma
KSh7,402.00
Alcad AL-245 – Serie 903: Power supply 12/13/18 vdc 400 ma.
Power supply unit for mast amplifier with SAT multiplexing. Voltage supply 12Vdc. If LNB control signal is received it powers both the amplifier and the LNB with the control signal comming from the SAT receiver. The output voltage is injected into the coaxial cable to power the amplifier and the LNB. The signal coming from the antenna is distributed to its two outputs. Protected against overloads and short circuits.
Applications
Individual terrestrial ans satellite TV installations, digital and analogue, where mast amplifiers with SAT multiplexing are used.
Characteristics
Shielded zamak chassis, covered by an ABS plastic box. Power supply unit insulated from the high frequency circuit, complying with safety standards for both the installer and the user. Fixed to the wall by means of supplied wallplugs and screws. F type connectors.
Downloads
Technical specification
Technical specification
Manuals
AL-245 HN pdf 824.47 KB
AL-245 Manual pdf 991.42 KB
Catalogues
CATALOGUE_ALCAD_EN_MULTIMEDIA_TV pdf 5.42 MB
Certificates
CE Declaration – AL-245 pdf 71 KB
Technical specifications
Related products
-
Add to cartHigh gain mast amplifier (LTE700, 2nd Digital Dividend). 1 input: FM/BIII/DAB/UHF. Mast-mounted amplifier to amplify terrestrial television signals from an antenna. It consists of a single input with amplification in several bands. The amplifier is powered at 24Vdc through the output coaxial cable.
-
Add to cartDomestic amplifier with 6 outputs, to extend the terrestrial television domestic network.
Equipped with LTE700 4G/5G filtering.
Highlights
Low-impact visual design and limited size
Integrated high-performance switched-mode power supply (40% less than a standard amplifier )
Fully automated manufacturing subject to the most stringent quality controls
Features
Manual gain control, protected by a folding cover
Can be wall-mounted using screws
?F? connectors
Specifications
VHF/UHF
Frequency band MHz 47-68/174-400 470-694
Inputs 6 (F) 6 (F)
Gain G dB 6 14
Gain regulation margin marg – AUTO
Output level (Vout) DIN 45004B? dB?V 104 102
IMD3(2tones, -35dB) 97 95
10CH DVB-T – 83
Noise figure N.F. dB – 0 … 12 -
-
Add to cartMast installation amplifier to amplify terrestrial television signals from various antennas. It has 3 inputs with amplification in all bands. The amplifier is powered at 12Vdc through the output coaxial cable. NETWORK compliant.
-
Alcad CMO-703 Ipal flush box for pdk-20003
KSh2,832.00Add to cartAlcad CMO-703 – Serie 974: Ipal flush box for pdk-20003.
To embed an entrance panel to the wall, it is necessary to previously place a flush-mount box where we will later fix the plate. This box is made of aluminum. It has some plates that allow to hold the entrance panel during installation, thus facilitating the work of connection and start-up of the different elements of the system.
Downloads
Technical specification
Technical specification
Catalogues
CATALOGUE_ALCAD_EN_DES pdf 5.85 MB
