Amplifier FM/DAB TAS 240 40dB Triax
KSh11,268.00
This module allows the FM and DAB signals to be amplified separately. The gain can be regulated from 0 – 20 dB in each frequency band.
Specifications
**Model ** TAS 240**
Code ** **324848
Frequency band MHz
FM: 87.5 – 108**
DAB: 195 – 223
Gain dB 40**
Attenuation dB 0 – 20**
Output level dB**V
110
(DIN B – 35dB)**
Feeding
VCD 12 to 24**
Consumption mA 150**
Connectors ** F female
Impedance ** 75
Dimensions** mm. 225 x 65 x 30
Example of chassis mounting
