APC 5000VA Smart UPS, 230V Rackmount 4.0KWatts 5.0kVA UPS – Kenya
KSh501,190.00
APC Smart UPS 5000VA 230V Rackmount 4.0KWatts 5.0kVA
The APC 5000VA Smart-UPS is a rackmount uninterruptible power supply (UPS) designed to deliver reliable backup power and surge protection for critical electronic devices.
5000VA UPS specifications of this UPS:
Model: APC 5000VA Smart-UPS
Capacity: 5000 VA / 4000 Watts
Input Voltage: 230V
Output Voltage: 230V
UPS Topology: Online Double Conversion
Waveform Type: Sine wave
Transfer Time: 0 ms (Online mode)
Nominal Input/Output Frequency: 50/60 Hz
Input Connection: Hardwire
Output Connections: 4 x IEC 320 C19, 2 x IEC 320 C13
Battery Type: Maintenance-free sealed lead-acid battery with suspended electrolyte
Typical Recharge Time: 3 hours
Communication Ports: USB, Serial, SmartSlot
LED Indicators: Online, On-battery, Replace Battery, Overload, and Bypass
LCD Display: Provides real-time UPS status and parameters
Audible Alarms: Battery Backup, Low Battery, Overload, and Fault
Surge Energy Rating: 540 Joules
Operating Temperature: 0°C to 40°C (32°F to 104°F)
Dimensions (H x W x D): 222 mm x 483 mm x 660 mm (8.74** x 19.02** x 25.98**)
Conclusion
The APC 5000VA Smart-UPS offers advanced features such as online double conversion technology for constant power protection, a large battery capacity for extended runtime, and multiple communication ports for easy connectivity and management
APC Smart UPS 5000VA 230V Rackmount 4.0KWatts 5.0kVA
The APC 5000VA Smart-UPS is a rackmount uninterruptible power supply (UPS) designed to deliver reliable backup power and surge protection for critical electronic devices.
5000VA UPS specifications of this UPS:
Model: APC 5000VA Smart-UPS
Capacity: 5000 VA / 4000 Watts
Input Voltage: 230V
Output Voltage: 230V
UPS Topology: Online Double Conversion
Waveform Type: Sine wave
Transfer Time: 0 ms (Online mode)
Nominal Input/Output Frequency: 50/60 Hz
Input Connection: Hardwire
Output Connections: 4 x IEC 320 C19, 2 x IEC 320 C13
Battery Type: Maintenance-free sealed lead-acid battery with suspended electrolyte
Typical Recharge Time: 3 hours
Communication Ports: USB, Serial, SmartSlot
LED Indicators: Online, On-battery, Replace Battery, Overload, and Bypass
LCD Display: Provides real-time UPS status and parameters
Audible Alarms: Battery Backup, Low Battery, Overload, and Fault
Surge Energy Rating: 540 Joules
Operating Temperature: 0°C to 40°C (32°F to 104°F)
Dimensions (H x W x D): 222 mm x 483 mm x 660 mm (8.74? x 19.02? x 25.98?)
Conclusion
The APC 5000VA Smart-UPS offers advanced features such as online double conversion technology for constant power protection, a large battery capacity for extended runtime, and multiple communication ports for easy connectivity and management
