Blind cover T.0X Televes
KSh3,634.00
T.0X Blind embellishing plate. 50mm – 5U. Front panel in white in 19″ format. Televes 5673
T.0X Blind embellishing plate. Televes 5673
Features
50mm – 5U
Front panel in white in 19″ format.
