Dahua DHPFM800E PFM800-E – Transceiver Pair – Kenya
KSh10,000.00
Dahua DHPFM800E PFM800-E – Transceiver Pair
Model PFM800-E
Properties
Transmission Signal 1 channel
Transmission Distance HDCVI
720P: max.400m(1312.34ft)
1080P: max.250m(820.21ft)
Category Type UTP CAT 5E/6
Video Transmission Properties And Port
Coaxial Video Connector BNC-M
Twisted-pair Video Connector Push-terminal
Compatible Format HDCVI/AHD/TVI/CVBS
Resolution 720P/1080P
Anti-interference **60db
Protection
ESD 1a contact discharge electricity level 3
1b air discharge electricity level 3
Per: IEC61000-4-2
Coaxial Cable Connector 2KV(common-code) Per: IEC1000-4-5
UTP Cable Connector 2KV(different-code), 4KV(common-code), Per: IEC1000-4-5
Impedance
BNC Male 75 ohms
UTP Cable 100 ohms
Physical Properties
Dimension(L*W*H) 180mm*19mm*16mm(7.09”x0.75”x0.63”)
Shell ABS
Color Black
N.W. 42g/pair (0.09lb)
Stability
MTBF **10000h
Environmental
Operating Temperature -10**~+55**(14**~131**)
Storage Temperature -20**~+70**(-4**~158**)
Humidity 0~95%(non-condensing)
Dahua DHPFM800E PFM800-E – Transceiver Pair
Model PFM800-E
Properties
Transmission Signal 1 channel
Transmission Distance HDCVI
720P: max.400m(1312.34ft)
1080P: max.250m(820.21ft)
Category Type UTP CAT 5E/6
Video Transmission Properties And Port
Coaxial Video Connector BNC-M
Twisted-pair Video Connector Push-terminal
Compatible Format HDCVI/AHD/TVI/CVBS
Resolution 720P/1080P
Anti-interference ?60db
Protection
ESD 1a contact discharge electricity level 3
1b air discharge electricity level 3
Per: IEC61000-4-2
Coaxial Cable Connector 2KV(common-code) Per: IEC1000-4-5
UTP Cable Connector 2KV(different-code), 4KV(common-code), Per: IEC1000-4-5
Impedance
BNC Male 75 ohms
UTP Cable 100 ohms
Physical Properties
Dimension(L*W*H) 180mm*19mm*16mm(7.09”x0.75”x0.63”)
Shell ABS
Color Black
N.W. 42g/pair (0.09lb)
Stability
MTBF ?10000h
Environmental
Operating Temperature -10?~+55?(14?~131?)
Storage Temperature -20?~+70?(-4?~158?)
Humidity 0~95%(non-condensing)
