Distributor 3 outputs (easy clema connection) ESS 3 Triax
KSh1,896.00
Three-way distributor with quick-connect terminal connectors ..
Features
Casing made of zinc.
Lightweight and compact
Clone connectors.
Low insertion loss.
Current passage in all output ports to the input port: max. 1A, 30V.
Specifications
BLINDAJE
Blindaje efectivo VHF/UHF > 85.0 dB
RANGO DE FRECUENCIA
Rango Frecuencia 5…2400 MHz
P?RDIDA
[P?rdida inserci?n (entrada-salida)] 1000-1750 Mhz < 10.0 dB
[P?rdida inserci?n (entrada-salida)] 1750-2150 Mhz < 11.0 dB
[P?rdida inserci?n (entrada-salida)] 2150-2400 Mhz < 11.5 dB
[P?rdida inserci?n (entrada-salida)] 40-1000 Mhz < 8.0 dB
[P?rdida inserci?n (entrada-salida)] 5-40 Mhz < 7.5 dB
AISLAMIENTO
[Aislamiento (salida-derivaci?n)] 1000-1750 MHz > 20.0 dB
[Aislamiento (derivaci?n-derivaci?n)] 1750-2150 MHz > 20.0 dB
[Aislamiento (derivaci?n-derivaci?n)] 2150-2400 MHz > 20.0 dB
[Aislamiento (derivaci?n-derivaci?n)] 40-1000 MHz > 21.0 dB
[Aislamiento (derivaci?n-derivaci?n)] 5-40 MHz > 20.0 dB
P?RDIDA DE RETORNO
[P?rdida de retorno (entrada-salida)] 1000-1750 MHz > 10.0 dB
[P?rdida de retorno (entrada-salida)] 1750-2150 MHz > 10.0 dB
[P?rdida de retorno (entrada-salida)] 2150-2400 MHz > 10.0 dB
[P?rdida de retorno (entrada-salida)] 40-1000 MHz > 11.0 dB
[P?rdida de retorno (entrada-salida)] 5-40 MHz > 10.0 dB
DATOS EL?CTRICOS
Impedancia 75 ?
OPERACIONAL
Paso DC S? (30VDC / 1A directed – OUT to IN)
CONECTORES
Tipo de Conector Saddle & Clamp (S&C)
N?mero de salidas 3
MEC?NICO
Profundidad 19 mm
Peso Total 0,092 kg
Peso Neto 0,092 kg
Anchura 82 mm
Altura 31 mm
